AFS120FX
1 – 2
2. AF-R80FX
Cooling Capacity BTU/h 8000
Moisture Removal Pint/h 2.1
Electrical Data
Phase Single
Rared frequency Hz 60
Rated voltage Volts 115
Rated current Amps 7.6
Rated input Watts 820
Power factor % 96
EER BTU/Wh 9.8
Compressor
Type (Hermetically sealed rotary type)
Model, Motor Output 39R191CD-05s, 760
REFRIGERANT SYSTEM
Evaporator Louver fin, Grooved tube, 7mm, hair pin
Condenser Louver fin, Grooved tube, 7mm, hair pin
Control O.D. x I.D x Length x Q'ty(mm) Capil-
lary Tube
2.5 x 1.1 x 1000 x 2
Refrigerant Volume R-22 (OZ) Factory Charge 16.9
NET DIMENSIONS
Width Height Depth Inch (mm) 18.5" (470) x 12.6" (320) x 16.3" (415)
Net Weight Lbs 46.3
GROSS DIMENSIONS
Width Height Depth Inch (mm) 22.0" (560) x 14.8" (375) x 18.7" (472)
Gross Weight Lbs 50.7
FAN SYSTEM
Indoor side (Evaporator) Centrifugal fan
Outdoor side (Condenser) Propeller fan
Air Flow rate (Indoor side) CFM High / Med / Low
700/630/560
OTHERS
Safety devices Compressor: Over load
Fan motor: Internal thermal protector
Air filter Polypropylene net
Power cord length ft 6.0
Power plug type 125V, 15A
