AFS120FX
1 – 3
3. AF-S80FX
Cooling Capacity BTU/h 8000
Moisture Removal Pint/h 2.1
Electrical Data
Phase Single
Rared frequency Hz 60
Rated voltage Volts 115
Rated current Amps 6.8
Rated input Watts 740
Power factor % 94
EER BTU/Wh 10.8
Compressor
Type (Hermetically sealed rotary type)
Model, Motor Output 2R11S3R126A6B, 665
REFRIGERANT SYSTEM
Evaporator Louver fin, Grooved tube, 7mm, hair pin
Condenser Louver fin, Grooved tube, 7mm, hair pin
Control O.D. x I.D x Length x Q'ty(mm) Capil-
lary Tube
2.5 x 1.1 x 1000 x 2
Refrigerant Volume R-22 (OZ) Factory Charge 16.9
NET DIMENSIONS
Width Height Depth Inch (mm) 18.5" (470) x 12.6" (320) x 16.3" (415)
Net Weight Lbs 54.0
GROSS DIMENSIONS
Width Height Depth Inch (mm) 22.0" (560) x 14.8" (375) x 18.7" (472)
Gross Weight Lbs 61.7
FAN SYSTEM
Indoor side (Evaporator) Centrifugal fan
Outdoor side (Condenser) Propeller fan
Air Flow rate (Indoor side) CFM High / Med / Low
700/630/560
OTHERS
Safety devices Compressor: Over load
Fan motor: Internal thermal protector
Air filter Polypropylene net
Power cord length ft 6.0
Power plug type 125V, 15A
