AH-A129E
AU-A129E
23
REF. NO. PART NO. DESCRIPTION Q'TY CODE
REPLACEMENT PARTS LIST [AH-A129E]
CABINET AND UNIT PARTS
1- 1 CMOT-A271JBK0 Fan motorr sub ass’y 1 BN
1- 2 NFANCA041JBE0 Cross flow fan 1 BG
1- 3 CSRA-A445JBK0 Drain pan ass’y 1 BN
1- 4 MJNTPA035JBFF Louver link 3 AE
1- 5 MLOV-A115JBFE Horizontal adjustment louver A 9 AB
1- 6 MLOV-A116JBFF Horizontal adjustment louver B 3 AD
1- 7 MLOV-A171JBFE Horizontal louver 1 AN
1- 8 PHOS-A015JBE0 Drain hose 1 AL
1- 9 PPACGA002JBE0 O ring 1 AA
1-10 LHLD-A279JBF0 Shaft holder 1 AC
1-11 GGAD-A042JBEA Wire guard 1 AN
1-12 LHLD-A092JBFZ Louver holder 2 AC
1-13 RMOT-A073JBE0 Louver motor 1 AU
1-14 CHLD-A067JBK0 Bearing ass’y 1 AL
1-15 PFPFPB038JBE0 Seal 1 AB
1-16 LHLDW0365JBE0 Wire holder 1 AA
1-17 PGUMMA056JBE0 Motor cushion 1 AN
1-18 PGUMMA082JBE0 Motor cushion 1 AD
1-19 DCHS-A356JBK0 Cabinet ass’y 1 BD
1-20 DWAK-A780JBK0 Panel ass’y 1 AZ
1-21 PFILMA065JBEF Air filter 2 AN
1-22 HDEC-B021JBEA Decoration panel 1 AL
1-23 GCOVAA006JBFE Front panel cover 1 AD
1-24 HBDG-A059JBEA Badge 1 AF
1-25 HPNL-A119JBTB Open panel 1 AX
1-26 MARMPA006JBFA Open arm L 1 AC
1-27 MARMPA007JBFA Open arm R 1 AC
1-28 GWAK-A178JBFC Front panel 1 AX
1-29 LHLD-A194JBF0 Panel center holder 1 AC
1-30 MARMPA008JBFA Arm L 1 AC
1-31 MARMPA009JBFA Arm R 1 AC
1-32 PGUMSA113JBE0 Damper rubber 1 AE
1-33 PCOV-A207JBE0 Drain cover 1 AC
1-34 PFPFPA905JBE0 Panel insulator A 1 AA
1-35 PFPFPA774JBE0 Cabinet insulator 1 AC
1-36 PGUMSA135JBE0 Damper rubber 2 AB
1-37 CPNL-A307JBK0 Open panel ass’y 1 AY
1-38 PCUS-A026JBE0 Cushion 12 1 AC
1-39 LHLD-A278JBE0 Guard holder 4 AD
1-40 LHLD-A181JBFA Pipe holder 1 AC
1-41 LHLD-A161JBF0 Pipe holder 1 AD
1-42 QW-VZC636JBE0 Fan motor lead 1 AG
1-43 PSEL-B778JBE0 Aluminum tape 1 AC
1-44 PSEL-B779JBE0 Aluminum tape 1 AB
1-45 PSEL-B780JBE0 Aluminum tape 1 AD
1-46 PSEL-B863JBE0 Aluminum tape 1 AC
1-47 TSPC-C986JBRA Name label 1 AD
1-48 TLABCB257JBR0 Wiring diagram 1 AD
CONTROL BOX PARTS
2- 1 DSGY-A878JBK0 Display unit 1 AS
2- 2 DPWBFA047JBK0 Switch board unit 1 AP
2- 3 QACC-A194JBE0 Power supply cord 1 AU
2- 4 QTAN-A127JBE0 Terminal board(3p) 1 AN
2- 5 QTAN-A088JBE0 Terminal board(3p) 1 AP
2- 6 DPWBFA154JBK0 COntrol board unit 1 BN
2- 7 PSEL-B777JBE0 Aluminun tape 1 AC
2- 8 RTRN-A182JBE0 Transformer 1 AY
2- 9 RC-HZA286JBE0 Fan motor capacitor 1 AY
2-10 RTHM-A296JBE0 Thermistor 1 AN
2-11 LHLD-A095JBF0 Thermistor holder 1 AC
2-12 PBOX-A133JBF0 Control box 1 AG
2-13 HPNLCA564JBF0 Control cover 1 AG
2-14 HPNLCA565JBEA Operation panel 1 AG
2-15 LHLD-A141JBFA Cord holder 1 AC
2-16 PSEL-B859JBE0 Aluminun tape 1 AC
2-17 PSHE-A072JBE0 Protect paper 1 AB
2-18 PSHE-A095JBE0 Protect sheet 1 AB
2-19 LHLD-A224JBFE Cord clamp 1 AG
2-20 RH-IXA519JBE0 Microcomputer(IC1) 1 AX
2-21 RH-IZA149JBE0 Integrated circuit(IC2) 1 AE
2-22 RIC--A022BDE0 TIntegrated circuit(IC3) 1 AE
2-23 RIC--A025BDE0 Integrated circuit(IC4) 1 AE
