AH-A129E
AU-A129E
3
EXTERNAL DIMENSIONS
297
186
897
Length unit (mm)
Remote controller
58
19.5
182
Figure E-1. INDOOR UNIT
430
720
775
143
55
245
535
278
236
228
20˚
58
Figure E-2. OUTDOOR UNIT
