Connecting to External Equipment
Connecting an Audio Amplifi er
■
When using optical fi ber cable:
It is possible to output audio through the DIGITAL AUDIO OUTPUT terminal. (See page 28 for details.) PCM audio
outputs from the terminal.
DIGITAL AUDIO INPUT
OPTICAL
Back panel
vertical inputs
Optical fiber cable
• Depending on the connected equipment, audio will not output from the DIGITAL AUDIO OUTPUT terminal in HDMI
connection. In this case, set the audio formats of the connected equipment to PCM, 32/44.1/48 kHz.
■
When using audio cable:
ANALOG AUDIO IN
Back panel
vertical inputs
Audio cable
• See page 29 for details on the Output Select function.
