Quick Reference Guide: AR-M355U/M455U
Simulation List (Pg. 8 of 11)
Simulation List (Main/Sub) (cont’d)
55 1 Used to set the specifications of the engine control operations. (PCU-PWB).
2 Used to set the specifications of the scanner control operations. (Scanner control PWB).
3 Used to set the specifications of the controller operations. (MFP control PWB).
56 1 Used to transfer the MFP controller data. (Used to repair the PWB.)
60 1 Used to check the MFP control (DRAM) operations (read/write).
61 1 Used to check the operation of the scanner (write) unit (LSU).
2 Used to adjust the laser power (absolute value) in the copy mode.
3 Used to adjust the laser power (absolute value) in the FAX mode.
4 Used to adjust the laser power (absolute value) in the printer mode.
62 1 Used to format the hard disk.
2 Used to check the operation of the hard disk (read/write). (Only in the model with a disk installed). (Partial check.)
3 Used to check the operations of the hard disk (read/write). (All areas check.)
6 Used to check the operations of the hard disk. (The self-diag operation of the SMART function I executed.
7 Used to check the operation soft the hard disk. (/The result of the self-diag operation of the SMART function is printed out.)
8 Used to format the hard disk (the system area excluded).
10 Used to delete a job complete list (also to delete job log data).
11 Used to delete document filing data. (The management area (standard folder, user folder) is cleared.)
63 1 Used to check the result of shading correction. (The shading correction data are displayed.)
2 Used to execute shading.
7 Used to adjust the white plate scan start position for shading. (Document table mode.)
64 1 Used to check the operation of the printer section (self-print operation). (The print pattern, the paper feed mode, the print mode,
the print quantity, and the density can be optionally set).
13
