Sharp AX-1500J User Manual

AX1500J(S)
4
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
8-88 PZETPA001WRFZ AG Inverter sheald plate
8-94 PCUS-A234WREZ AC Cushion
8-100 LANGKB394WRPZ AL Steam duct ag
8-101 PCOV-A142WRFZ AK Steam duct cover ORG
8-102 PCUS-A222WREZ AC Cushion
8-104 PCUS-A237WREZ AC Cushion
8-107 PCUS-A261WREZ AF Cushion
8-108 PDUC-B136WRFZ AM Joint duct Front
8-109 PDUC-B137WRFZ AM Joint duct Rear
8-110 PPAC-A112WREZ AD Duct packing
8-113 PPAC-A136WREZ AD Joint duct packing L
8-114 PPAC-A137WREZ AD Joint duct packing S
* 8-121 LANGKB459WRFZ AM Latch base angle
8-122 MLEVPA290WRFZ AG Door switch lever
8-123 LANGKB426WRPZ AR Duct divide plate
8-131 LBND-A033WREZ AC Hose band
8-132 LBND-A047WREZ AF Hose band
8-134 PSLDHA296WRPZ AF Motor reflector
8-140 FSFTTA060WRFZ AM Shaft assembly
8-141 PPIPUA030WREZ AF TT spacer
8-146 PSPAFA002WREZ AF Spacer
8-148 PCUS-A256WREZ AF Cushion
8-149 LANGQA791WRPZ AF Lamp angle
8-150 PCUS-A266WREZ AC Cushion
8-153 PSHEPB361WREZ AF Insulator sheet
SCREW, WASHER AND NUT
9-2 XOTS740P08000 AA Screw; 4mm x 8mm
9-4 XEBS730P10000 AA Screw; 3mm x 10mm
9-6 XHPS740P08K00 AB Screw;;4mm x 8mm
9-7 XETS740P08000 AA Screw; 4mm x 8mm
9-9 XCPS740P20000 AK Screw : 4mm x 20mm
9-11 XETS740P10000 AA Screw; 4mm x 10mm
9-12 XNEUW40-32000 AA Nut
9-13 LX-NZA002WRE0 AC Nut
9-14 XOTWW40P06000 AC Screw; 4mm x 6mm
9-15 XOTWW40P08000 AB Screw; 4mm x 8mm
9-16 XCBS730P08000 AB Screw; 3mm x 8mm
9-17 XBPS740P06K00 AC Screw : 4mm x 6mm
9-18 XREUW40-06000 AA E ring
9-19 XWHUW48-15120 AB Washer
9-20 XWHUW40-08000 AA Washer
9-21 XWSUW40-10000 AA Spring washer
9-23 XEPS740P40000 AB Screw; 4mm x 40mm
9-24 XEPS740P10000 AA Screw ;4mm x 10mm
9-25 XEPS740P14000 AB Screw; 4mm x 14mm
9-27 LX-NZA057WREZ AG Special nut
9-29 XWHS700-05180 AC Washer
9-32 LX-CZA088WREZ AB Special screw (Knock type)
9-33 XNES740-32000 AC Nut
9-39 XUBS740P36000 AC Screw; 4mm x 36mm
9-40 LX-BZA171WREZ AA Special screw
9-41 LX-CZA084WREZ AB Special screw
9-43 LX-BZA202WREZ AE Special screw
9-45 LX-BZA144WREZ AB Special screw
9-46 LX-CZ0052WRE0 AA Special screw
9-47 LX-WZ7005XCZZ AD Washer
9-42 XFPWW30P06000 AD Screw : 3mm x 6mm
[1] OVEN PARTS
