26
AH-X079E/X099E
AY-X079E/X099E
Indoor side
Standard conditions: 
Dry-bulb Temp. (˚C) Relative Humidity (%)
27Cooling 47
Outdoor side
Dry-bulb Temp. (˚C) Relative Humidity (%)
35 40
AH-X079E / AH-X099E
Temperature at each part and pressure in 3-way valve
Operation 
mode
Cool
(Max.)
Cool
1
2
3
4
3-way valve
pressure
(kg/cm
2
G)
90˚C
41˚C
10˚C
3˚C
4.4
78˚C
41˚C
11˚C
7˚C
5.2
69 50 settle
AH-X099E
Operation 
mode
Cool
(Max.)
Cool
1
2
3
4
3-way valve
pressure
(kg/cm
2
G)
96˚C
39˚C
12˚C
5˚C
4.4
80˚C
40˚C
13˚C
7˚C
5.5
75 50 settle
AH-X079E
No.
Hz
No.
Hz
Capillary tube
O.D I.D. L
ø2.7 ø1.5 800
Capillary tube
O.D I.D. L
ø2.7 ø1.5 700
AH-X079E
AH-X099E
Dimension of Capillary tube
