Sharp AY-XP07ER User Manual

ENGLISH
PART NAMES
1 Inlet (Air)
2 PLASMACLUSTER Lamp
(blue, green)
3 DEODORANT DUST COL-
LECTION FILTER
(non-washable)
4 Open Panel
5 Air Filters
6 AUX. Button
7 Indicator
8 Power Supply Cord
9 Vertical Adjustment Louvres
0 Horizontal Adjustment
Louvres
q Outlet (Air)
w RECEIVER Window
e Remote Control
r OUTDOOR Temp. Lamp
(green )
t ROOM Temp. Lamp
(green )
y TEMPERATURE INDICATOR
u TIMER Lamp (orange )
i OPERATION Lamp (red )
OUTDOOR UNIT
NOTE: Actual units might vary slightly from those shown above.
INDOOR UNIT
o Inlet (Air)
p Refrigerant Tube and
Interconnecting Cord
a Drainage Hose
s Outlet (Air)
E-3
1
2
3
4
5
6
7
8
9
0
q
w
e
r
t
y
u
i
(Open Panel Closed)
o
p
a
s
AY-XP07ER_Eng P6.5 03.12.11, 8:50 AM5
