Sharp AY-XP24LR Service Manual

AYXPC18LR
10
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
3-21 DSGY-E030JBKZ BR PFC Control Board Uni
3-24 PRDAFA239JBEZ BQ Haet Sink
3-25 PSPA-A150JBZZ AF PWB Spacer
3-26 QW-IZA141JBZZ AW Comp. Cord (QM101(U,V,W) - COMP)
3-36 RFIL-A064JBE0 AF Ferrite Core
3-37 RTRN-A300JBZZ BK Active Coil
3-38 LBNDKA151JBWZ AM Capacitor Clamp
3-39 LHLD-B096JBFA AY Heat Sink Holder
3-40 LHLDWA039JBEZ AC Wire H0Lder
3-41 LHLDWA040JBEZ AC Wire H0Lder
3-42 PSHE-A313JBEZ AK Protect Sheet
3-44 PSPA-A082JBE0 AB Spacer
3-45 PSPA-A173JBEZ AE Pwb Spacer
3-50 RC-AZA046JBE0 BE Electrolytic Cap.
3-51 RC-EZA250JBZZ BG Electrolytic Capa.
3-53 PCOV-B724JBWZ AT Control Box Cover
3-54 RH-HXA140JBZZ BC Thermistor Assembly
3-58 TLABCC720JBRZ AK Wiring Diagram
3-59 PSEL-E183JBEZ AH Cont. Box Cover Seal
3-61 PSEL-E136JBEZ AK Cont. Box Angle Seal
[8] OTHER OUTDOOR PARTS
3-10 QW-VZG402JBZZ AK Lead Wire (TBN -T2)
3-11 QW-VZG403JBZZ AK Lead Wire (TBL -T1)
3-12 QW-VZG446JBZZ AK Lead Wire (TB -CN6)
3-14 QW-VZG438JBZZ AK Lead Wire (TBE -BOX)
3-27 QW-VZG499JBZZ AN Lead Wire (MRY1 OUT - DB1 AC1)
3-28 QW-VZG500JBZZ AN Lead Wire (T6 - DB1 AC2)
3-29 QW-VZG396JBZZ AL Lead Wire (PFCM (TNF) - C(-))
3-30 QW-VZG397JBZZ AK Lead Wire (C10(+) - IPM(TP))
3-31 QW-VZG398JBZZ AK Lead Wire (C10(-) - IPM(TN))
3-32 QW-VZG399JBZZ AL Lead Wire (PFCM (TPF) - C(+))
3-33 QW-VZG406JBZZ AK Lead Wire (CN14 - CN114)
3-34 QW-VZG407JBZZ AK Lead Wire (PFCM (TL1) - Coil)
3-35 QW-VZG408JBZZ AK Lead Wire (PFCM (TL2) - Coil)
3-46 QW-VZE603JBZZ AP Lead Wire (C9(+) - C10(+))
3-47 QW-VZE624JBZZ AP Lead Wire (T5 - MRY1)
3-48 QW-VZG213JBZZ AK Lead Wire (C9(-) - C10(-))
3-49 QW-VZG405JBZZ AK Lead Wire (T4 - BOX)
6-5 XCPS740P25000 AD Tapping Screw
6-6 XBPS730P14JS0 AA Tapping Screw
6-9 XBPS740P20J00 AF Machine Screw
6-10 LX-BZA075JBE0 AA Special Screw
6-11 XJTS740P10000 AC Tap Tight Screw
6-12 XTPS730P12XS0 AF Tapping Screw
6-14 XBPS740P08K00 AK Machine Screw
6-15 PSEL-E136JBEZ AK Cont. Box Ang Seal
6-16 PSEL-E137JBEZ AM Cont. Box Cover Seal
[7] CONTROL BOX PARTS
