GB-2
PART NAMES
INDOOR UNIT
1 AUX Button
2 Inlet (Air)
3 Open Panel
4 Air Purifying Filter
5 Air Filters
6 Receiver Window
7 Vertical Adjustment Louvre
8 Horizontal Adjustment Louvre
9 Outlet (Air)
10 Remote Control
11 PLASMACLUSTER Lamp (blue)
12 TEMPERATURE INDICATOR
13 OUTDOOR Temp. Lamp (green
)
14 ROOM Temp. Lamp (green )
15 FULL POWER Lamp (green
)
16 TIMER Lamp (orange )
17 OPERATION Lamp (red
)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
NOTE:
Actual units might vary slightly from those shown above.
To Next Page
