Sharp AY-XPC15PU Service Manual

1 – 2
[2] EXTERNAL DIMENSION
Indoor unit
Length unit : inch (mm)
Remote controller
AY-XPC15PU
38.0 (965)
0.7 (18)
9.8 (250)
8.0 (204)
12.3 (313)
2.2 (57)
skrameRledoMemaN traP
Fan motor
Louver motor
-1 uF
DC motor (CMOT-A561JBKZ)SHA-37CVJ-F440-1
DC12V (RMOT-A223JBZZ)24BYJ48-1373
)V052 A51.3( ZZBJ870AG-SFQ
[3] ELECTRICAL PARTS
[4] WIRING DIAGRM
FAN
MOTOR
DISPLAY
BOARDUNIT
MAIN CONTROL BOARD UNIT
1
2
3
4
5
6
THERMISTOR
(PIPE TEMP.)
THERMISTOR
(ROOM TEMP.)
THERMISTOR
(VALVE TEMP.)
ORANGE
YELLOW
BLACK

Sharp AY-XPC15PU Specifications

General

Brand	Sharp
Model	AY-XPC15PU
Category	Air Conditioner
Language	English
