BEFORE USING THE MACHINE
15
2
Adjust guide plates A and B by
squeezing their lock levers and sliding
them to match the longitudinal and
transversal dimensions of the paper to
be loaded.
The guide plates A and B are slidable. Slide each guide
plate while squeezing its lock lever to adjust to the paper
size.
Do not load the paper as shown below.
A non-standard size of paper can only be loaded in tray 4. A non-standard size of paper cannot be loaded in tray 3.
3
Fan the paper.
Fan the paper well before loading it. If the paper is not
fanned, multiple sheets may feed at once and cause a
misfeed.
4
Insert the paper into the tray.
Load the paper with the print side facing up. The stack must
not be higher than the indicator line (maximum of 500
sheets).
5
Gently push the paper tray into the
machine.
Push the tray firmly all the way into the machine slowly.
Forcefully inserting the paper may cause skewed feeding
and paper misfeeds.
To Next Page
