Sharp CD-C1W User Manual

NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PART CODE
PRICE
RANK
DESCRIPTION
CD-C1W, CP-C1W
ZD854 VHEMTZJ4R7B-1 J AB Zener,4.7V,MTZJ4.7B
ZD901 VHEMTZJ150A-1 J AA Zener,15V,MTZJ15A
ZD903,904 VHEMTZJ8R2C-1 J AB Zener,8.2V,MTZJ8.2C
ZD998 VHEMTZJ5R1B-1 J AC Zener,5.1V,MTZJ5.1B
ZD999 VHEMTZJ6R2B-1 J AC Zener,6.2V,MTZJ6.2B
FILTERS
BFT01 92LFILTF1759AT J AD FM Band Pass Filter
CF302 RFILF0124AFZZ J AD FM IF,10.7 MHz
CF351 RFILF0003AWZZ J AK FM IF
CF352 RFILA0009AWZZ J AE AM IF
TRANSFORMERS
T302 RCILA1064AFZZ J AD MW Antenna
T303 92LCOILA-1586B J AF SW1 Antenna
T304 RCILA0014AWZZ J AE SW2 Antenna
T306 RCILB1074AFZZ J AC MW Oscillation
T307 RCILB0015AWZZ J AD SW1 Oscillation
T308 RCILB0014AWZZ J AD SW2 Oscillation
T351 RCILI0011AWZZ J AD AM IF
! T851 RTRNP0182AWZZ J BP Power
TT01 RCILI0007AWZZ J AD FM IF
COILS
L61 VP-XH2R2K0000 J AB 2.2 µH,Choke
L102,103 RCILC0094AFZZ J AD 6.8 mH
L104 VP-MK331K0000 J AB 330 µH,Choke
L201 VP-DH2R2M0000 J AB 2.2 µH,Choke
L251,252 RCILL0105AFZZ J AE MPX. Filter
L311 VP-YF561K0000 J AD 560 µH
L351,352 VP-DH101K0000 J AB 100 µH,Choke
L353 VP-DH102K0000 J AB 1 mH,Choke
L356 VP-YF102J0000 J AC 1 mH
L357 VP-YF472J0000 J AC 4.7 mH
L358 VP-YF561K0000 J AD 560 µH
L701 VP-CH2R2M0000 J AB 2.2 µH
L851 VP-DH101K0000 J AB 100 µH,Choke
L901,902 RCILZ0137AFZZ J AA 0.29 µH
L903 VP-XH2R2K0000 J AB 2.2 µH,Choke
LD1~4 RCILC0094AFZZ J AD 6.8 mH
LT1 RCILR0029AWZZ J AA FM RF
LT2 RCILB0045AWZZ J AD FM Oscillation
VARIABLE RESISTORS
VR101 92LVRS223NBMT J AC 22 kohms (B),Semi-VR
[L-CH Bias Current]
VR102 92LVRS223NBMT J AC 22 kohms (B),Semi-VR
[R-CH Bias Current]
VR151 92LVR-S473NB-M J AC 47 kohms (B),Semi-VR
[L-CH Rec/Play Sens.]
VR152 92LVR-S473NB-M J AC 47 kohms (B),Semi-VR
[R-CH Rec/Play Sens.]
VR351 RVR-M0999AFZZ J AB 10 kohm (B),Semi-VR
[FM Mute Level]
VRD01 92LVRS223NBMT J AC 22 kohms (B),Semi-VR
[Tape 1 Play L-CH Sens.]
VRD02 92LVRS223NBMT J AC 22 kohms (B),Semi-VR
[Tape 1 Play R-CH Sens.]
VRD03 92LVRS223NBMT J AC 22 kohms (B),Semi-VR
[Tape 2 Play L-CH Sens.]
VRD04 92LVRS223NBMT J AC 22 kohms (B),Semi-VR
[Tape 2 Play R-CH Sens.]
VRM01 RVR-M0993AFZZ J AB 1 kohm (B),Semi-VR
[Tape Speed]
VARIABLE CAPACITOR
TC302~305 92LTO-1527AT J AF Trimmer,20pF
VIBRATORS
X201 RCRSP0003AWZZ J AH Crystal,4.19MHz
X351 92LCRSTL1425A J AF Crystal,456 kHz
X352 RCRSP0002AWZZ J AH Crystal,4.5 MHz
X701 RCRM-0147AFZZ J AD Ceramic,4.19 MHz
XL1 RCRM-0008AWZZ J AF Ceramic,16.93 MHz
CAPACITORS
C1 RC-GZA476AF1A J AB 47 µF,10V,Electrolytic
C2 VCTYMN1CY103K J AA 0.01 µF,16V
C3 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C4 RC-GZA104AF1H J AB 0.1 µF,50V,Electrolytic
C5,6 VCTYPA1CX333K J AA 0.033 µF,16V
C7 RC-GZA104AF1H J AB 0.1 µF,50V,Electrolytic
C8 VCTYPA1CX683K J AA 0.068 µF,16V
C9 VCTYPA1CX473K J AA 0.047 µF,16V
C10 VCKYMN1HB181K J AA 180 pF,50V
C11,12 VCTYPA1CX104K J AB 0.1 µF,16V
C13 VCKYMN1HB331K J AA 330 pF,50V
C14 VCTYMN1CY103K J AA 0.01 µF,16V
C16 VCTYMN1CX472K J AA 0.0047 µF,16V
C17 VCKYMN1HB102K J AA 0.001 µF,50V
C18 RC-GZA474AF1H J AA 0.47 µF,50V,Electrolytic
C19 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C20 RC-GZA476AF1A J AB 47 µF,10V,Electrolytic
C21 VCTYMN1CX332K J AA 0.0033 µF,16V
C22 VCCSPA1HL221J J AA 220 pF,50V
C23 VCTYMN1CX272K J AA 0.0027 µF,16V
C24 VCCSMN1HL2R2C J AB 2.2 pF,50V
C25 VCCSMN1HL270J J AA 27 pF,50V
C26 VCTYPA1CX333K J AA 0.033 µF,16V
C27 VCKYMN1HB102K J AA 0.001 µF,50V
C28 VCTYPA1CX104K J AB 0.1 µF,16V
C29 RC-GZA475AF1E J AB 4.7 µF,25V,Electrolytic
C30 RC-GZA104AF1H J AB 0.1 µF,50V,Electrolytic
C31 RC-GZA227AF0J J AB 220 µF,6.3V,Electrolytic
C32 VCTYMN1CY103K J AA 0.01 µF,16V
C33 RC-GZA474AF1H J AA 0.47 µF,50V,Electrolytic
C34 RC-GZA334AF1H J AA 0.33 µF,50V,Electrolytic
C35 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C36 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C37 VCTYMN1EF223Z J AA 0.022 µF,25V
C38 VCTYMN1CY103K J AA 0.01 µF,16V
C39 VCTYPA1CX473K J AA 0.047 µF,16V
C40 VCTYPU1CX473K J AA 0.047 µF,16V
C43 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C44~49 VCKYMN1HB101K J AA 100 pF,50V
C51,52 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C53 VCTYMN1EF223Z J AA 0.022 µF,25V
C54 VCKYMN1HB102K J AA 0.001 µF,50V
C55 RC-GZA335AF1C J AB 3.3 µF,16V,Electrolytic
C56 VCTYMN1EF223Z J AA 0.022 µF,25V
C57 VCKYMN1HB102K J AA 0.001 µF,50V
C71,72 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C73,74 VCKYMN1HB221K J AA 220 pF,50V
C80 VCTYMN1EF223Z J AA 0.022 µF,25V
C81,82 RC-GZA476AF1E J AB 47 µF,25V,Electrolytic
C83 VCKYMN1HB102K J AA 0.001 µF,50V
C85 VCTYMN1EF223Z J AA 0.022 µF,25V
C86,87 RC-GZA476AF1E J AB 47 µF,25V,Electrolytic
C101,102 VCKYMN1HB471K J AA 470 pF,50V
C103~106 VCKYMN1HB331K J AA 330 pF,50V
C107,108 VCKYMN1HB821K J AA 820 pF,50V
C109 VCKYPA1HF223Z J AB 0.022 µF,50V
C111~114 VCKYMN1HB331K J AA 330 pF,50V
C115,116 RC-GZA476AF1E J AB 47 µF,25V,Electrolytic
C117,118 VCTYPA1CX333K J AA 0.033 µF,16V
C119,120 VCKYMN1HB561K J AA 560 pF,50V
C121,122 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C123~126 VCTYPA1EX822K J AA 0.0082 µF,25V
C127 VCTYMN1EF223Z J AA 0.022 µF,25V
C128 RC-GZA335AF1H J AB 3.3 µF,50V,Electrolytic
C130 VCKYMN1HB471K J AA 470 pF,50V
C131,132 VCKYMN1HB271K J AA 270 pF,50V
C133,134 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C139,140 VCTYMN1CX332K J AA 0.0033 µF,16V
C141,142 RC-GZA476AF1E J AB 47 µF,25V,Electrolytic
C145 RC-GZA226AF1E J AB 22 µF,25V,Electrolytic
C146 RC-GZA227AF1A J AB 220 µF,10V,Electrolytic
C147 VCTYMN1EF223Z J AA 0.022 µF,25V
C148 RC-GZA107AF1C J AB 100 µF,16V,Electrolytic
C150 VCQPKA2AA822J J AA 0.0082 µF,100V,Polypropylene
C151 RC-QZA393AFYJ J AB 0.039 µF,50V,Mylar
C152 RC-GZA476AF1E J AB 47 µF,25V,Electrolytic
C162 RC-QZA473AFYJ J AB 0.047 µF,50V,Mylar
C167,168 VCTYPA1CY822K J 8200 pF,16V
C169 VCTYPA1EX682K J AA 0.0068 µF,25V
C175~178 VCTYPA1EX682K J AA 0.0068 µF,25V
– 2 –
