Sharp CD-C3400 User Manual

PRICE
RANK
DESCRIPTIONNO. PART CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-C472/C3400/C3400C/C3800/C3800C
C703 VCCSMN1HL150J J AA 15 pF,50V
C704 VCCSMN1HL180J J AA 18 pF,50V
C705 VCKYMN1HB102K J AA 0.001 µF,50V
C706 VCTYMN1CY103N J AA 0.01 µF,16V
C707 VCEAZA1HW335M J 3.3 µF,50V,Electrolytic
C708 VCTYMN1CY103N J AA 0.01 µF,16V
C709 VCEAZA1AW107M J 100 µF,10V,Electrolytic
C710 VCEAZA1AW227M J 220 µF,10V,Electrolytic
C711 VCEAZA1EW476M J 47 µF,25V,Electrolytic
C712,713 VCEAZA1HW105M J 1 µF,50V,Electrolytic
C715 VCKZPA1HF223Z J AA 0.022 µF,50V
C716 VCEAZA1EW476M J 47 µF,25V,Electrolytic
C720 VCKYBT1HB151K J AA 150 pF,50V
C721~723 VCKYMN1HB151K J AA 150 pF,50V
C724 VCKYBT1HB102K J AA 0.001 µF,50V
C725 VCTYBT1EF223Z J AA 0.022 µF,25V
C730 VCEAZA1HW106M J 10 µF,50V,Electrolytic
C731 RC-EZY476AF1E J AB 47 µF,25V,Electrolytic
C732 VCTYBT1EF223Z J AA 0.022 µF,25V
C801 VCEAZW1VW228M J 2200 µF,35V,Electrolytic
C802 VCEAZA1VW107M J 100 µF,35V,Electrolytic
C803,804 VCEAZA1HW476M J 47 µF,50V,Electrolytic
C805~810 VCQYKA1HM473K J AB 0.047 µF,50V,Mylar
C811 VCEAZA1HW476M J 47 µF,50V,Electrolytic
C812,813 VCEAZA1HW107M J 100 µF,50V,Electrolytic
C817 VCEAZA1HW475M J 4.7 µF,50V,Electrolytic
C820 VCTYBT1EF223Z J AA 0.022 µF,25V
C823 VCEAZA1EW476M J 47 µF,25V,Electrolytic
C824 VCKZPA1HF223Z J AA 0.022 µF,50V
C825 VCEAZA1EW226M J 22 µF,25V,Electrolytic
C826~828 VCEAZA1EW476M J 47 µF,25V,Electrolytic
C829 VCEAZW1EW478M J 4700 µF,25V,Electrolytic
C831 VCEAZA1HW106M J 10 µF,50V,Electrolytic
C901 VCEAZA1HW105M J 1 µF,50V,Electrolytic
C902 VCCSPA1HL221J J 220 pF,50V
C903 VCEAZA1HW105M J 1 µF,50V,Electrolytic
C904 VCEAZA1HW106M J 10 µF,50V,Electrolytic
C905 VCCSPA1HL221J J AA 220 pF,50V
C906 VCEAZA1HW105M J 1 µF,50V,Electrolytic
C907 VCEAZA1HW106M J 10 µF,50V,Electrolytic
C908 VCKYPA1HB102K J AA 0.001 µF,50V
C909,910 VCEAZW1HW228M J 2200 µF,50V,Electrolytic
C911,912 VCEAZA1HW107M J 100 µF,50V,Electrolytic
C915 VCCSBT1HL470J J AA 47 pF,50V
C916 VCCSPA1HL150J J AA 15 pF,50V
C917,918 VCEAZA1HW476M J 47 µF,50V,Electrolytic
C919,920 VCTYPA1EX152K J AA 0.0015 µF,25V
C921,922 VCEAZA1HW105M J 1 µF,50V,Electrolytic
C923 VCCSBT1HL470J J AA 47 pF,50V
C924 VCCSPA1HL150J J AA 15 pF,50V
C925 VCEAZA1HW476M J 47 µF,50V,Electrolytic
C926 VCCSBT1HL470J J AA 47 pF,50V
C927,928 VCEAZA1VW476M J 47 µF,35V,Electrolytic
C929 VCCSPA1HL150J J AA 15 pF,50V
C930,931 VCCSPA1HL470J J AA 47 pF,50V
C933 VCEAZA1VW227M J 220 µF,35V,Electrolytic
C935 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
C937 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
C938 VCEAZA1VW476M J 47 µF,35V,Electrolytic
C940 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
C941 VCKZPA1HF223Z J AA 0.022 µF,50V
C942,943 VCEAZA1HW476M J 47 µF,50V,Electrolytic
C944 VCEAZV1EW108M J 1000 µF,25V,Electrolytic
C945 VCEAZV1EW228M J 2200 µF,25V,Electrolytic
C949 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
C959 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
C976 VCEAZA1EW226M J 22 µF,25V,Electrolytic
C977 VCEAZA0JW108M J 1000 µF,6.3V,Electrolytic
C978 VCEAZA1HW476M J 47 µF,50V,Electrolytic
C979 VCEAZA1HW106M J 10 µF,50V,Electrolytic
RESISTORS
VRD-MN2BD000C J AA 0 ohm,Jumper,ø1.4x3.5mm,Ivory
R1 VRD-MN2BD220J J AA 22 ohms,1/8W
R2 VRD-MN2BD102J J AA 1 kohm,1/8W
R8 VRD-MN2BD153J J AA 15 kohms,1/8W
R9 VRD-MN2BD104J J AA 100 kohm,1/8W
R10 VRD-MN2BD222J J AA 2.2 kohms,1/8W
R11 VRD-ST2CD682J J AA 6.8 kohms,1/6W
R12 VRD-MN2BD101J J AA 100 ohm,1/8W
R13 VRD-MN2BD102J J AA 1 kohm,1/8W
R14 VRD-MN2BD273J J AA 27 kohms,1/8W
R15 VRD-MN2BD123J J AA 12 kohms,1/8W
R16 VRD-MN2BD332J J AA 3.3 kohms,1/8W
R17 VRD-MN2BD333J J AA 33 kohms,1/8W
R18 VRD-MN2BD153J J AA 15 kohms,1/8W
R19,20 VRD-ST2CD102J J AA 1 kohm,1/6W
R21,22 VRD-MN2BD223J J AA 22 kohms,1/8W
R23 VRD-MN2BD103J J AA 10 kohm,1/8W
R24 VRD-MN2BD473J J AA 47 kohms,1/8W
R25 VRD-MN2BD152J J AA 1.5 kohms,1/8W
R26 VRD-MN2BD823J J AA 82 kohms,1/8W
R27 VRD-MN2BD393J J AA 39 kohms,1/8W
R28 VRD-MN2BD103J J AA 10 kohm,1/8W
R29 VRD-MN2BD563J J AA 56 kohms,1/8W
R30 VRD-MN2BD682J J AA 6.8 kohms,1/8W
R31 VRD-MN2BD122J J AA 1.2 kohms,1/8W
R32 VRD-MN2BD103J J AA 10 kohm,1/8W
R33 VRD-MN2BD122J J AA 1.2 kohms,1/8W
R34 VRD-MN2BD223J J AA 22 kohms,1/8W
R35,36 VRD-MN2BD224J J AA 220 kohms,1/8W
R37 VRD-ST2CD823J J AA 82 kohms,1/6W
R38 VRD-MN2BD471J J AA 470 ohms,1/8W
R39 VRD-MN2BD102J J AA 1 kohm,1/8W
R40 VRD-MN2BD562J J AA 5.6 kohms,1/8W
R41,42 VRD-MN2BD473J J AA 47 kohms,1/8W
R43 VRD-MN2BD563J J AA 56 kohms,1/8W
R44 VRD-MN2BD333J J AA 33 kohms,1/8W
R45 VRD-MN2BD472J J AA 4.7 kohms,1/8W
R46 VRD-MN2BD561J J AA 560 ohms,1/8W
R47,48 VRD-MN2BD103J J AA 10 kohm,1/8W
R50 VRD-MN2BD681J J AA 680 ohms,1/8W
R51 VRD-ST2CD335J J AA 3.3 Mohms,1/6W
R52 VRD-MN2BD273J J AA 27 kohms,1/8W
R53 VRD-MN2BD122J J AA 1.2 kohms,1/8W
R55 VRD-MN2BD151J J AA 150 ohms,1/8W
R57 VRD-MN2BD102J J AA 1 kohm,1/8W
R58,59 VRD-ST2CD102J J AA 1 kohm,1/6W
R60~62 VRD-MN2BD102J J AA 1 kohm,1/8W
R63 VRD-ST2CD102J J AA 1 kohm,1/6W
R64 VRD-MN2BD220J J AA 22 ohms,1/8W
R66 VRD-MN2BD221J J AA 220 ohms,1/8W
R71,72 VRD-MN2BD272J J AA 2.7 kohms,1/8W
R73,74 VRD-MN2BD391J J AA 390 ohms,1/8W
R81 VRD-MN2BD272J J AA 2.7 kohms,1/8W
R82 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R83 VRD-ST2EE3R9J J AA 3.9 ohms,1/4W
R85 VRD-RT2HD560J J AA 56 ohms,1/2W
R86 VRD-MN2BD222J J AA 2.2 kohms,1/8W
R87 VRD-MN2BD103J J AA 10 kohm,1/8W
R88~90 VRD-ST2CD102J J AA 1 kohm,1/6W
R93 VRD-MN2BD221J J AA 220 ohms,1/8W
R101 VRD-MN2BD102J J AA 1 kohm,1/8W
R102 VRD-ST2CD102J J AA 1 kohm,1/6W
R103,104 VRD-MN2BD222J J AA 2.2 kohms,1/8W
R105,106 VRD-MN2BD332J J AA 3.3 kohms,1/8W
R107,108 VRD-MN2BD473J J AA 47 kohms,1/8W
R109 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R110 VRD-MN2BD472J J AA 4.7 kohms,1/8W
R111,112 VRD-ST2CD103J J AA 10 kohm,1/6W
R113,114 VRD-MN2BD103J J AA 10 kohm,1/8W
R115 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R117,118 VRD-ST2CD102J J AA 1 kohm,1/6W
R119,120 VRD-ST2CD560J J AA 56 ohms,1/6W
R121,122 VRD-MN2BD104J J AA 100 kohm,1/8W
R123,124 VRD-MN2BD392J J AA 3.9 kohms,1/8W
R125,126 VRD-MN2BD562J J AA 5.6 kohms,1/8W
R131,132 VRD-MN2BD333J J AA 33 kohms,1/8W
R134 VRD-MN2BD683J J AA 68 kohms,1/8W
R135,136 VRD-MN2BD222J J AA 2.2 kohms,1/8W
R137,138 VRD-ST2CD682J J AA 6.8 kohms,1/6W
R139,140 VRD-MN2BD561J J AA 560 ohms,1/8W
R141,142 VRD-MN2BD560J J AA 56 ohms,1/8W
R145,146 VRD-MN2BD103J J AA 10 kohm,1/8W
R153,154 VRD-ST2CD103J J AA 10 kohm,1/6W
R155 VRD-ST2CD151J J AA 150 ohms,1/6W
R158 VRD-ST2EE221J J AA 220 ohms,1/4W
R160 VRD-ST2EE151J J AA 150 ohms,1/4W
R162 VRD-MN2BD473J J AA 47 kohms,1/8W
R164 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R166 VRD-MN2BD473J J AA 47 kohms,1/8W
R167 VRD-MN2BD104J J AA 100 kohm,1/8W
R168 VRD-MN2BD120J J AA 12 ohms,1/8W
– 3 –
