Sharp CD-C606

PRICE
RANK
DESCRIPTION
NO.
PARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-C606/1900,CP-C606/1900
– 1 –
CD-C606/1900
INTEGRATED CIRCUITS
IC1 VHILA9241M/-1 J AS Servo Amp.,LA9241M
IC2 VHILC78622N-1 J AY Servo/Signal Control,LC78622N
IC3 VHIM63001FP-1 J AX Focus/Tracking/Spin/Slide
Driver,M63001FP
IC301 VHITA7358AP-1 J AG FM Front End,TA7358AP
IC302 VHILC72131/-1 J AP PLL Controller,LC72131
IC303 VHILA1805//-1 J AM FM IF DET./FM MPX./AM IF,
LA1805
IC401 VHIM62439SP-1 J AG Audio Processor,M62439SP
IC501 VHIAN7345K/-1 J AM Playback and Record/Playback
Amp.,AN7345K
IC601 VHILA4282//-1 J AM Power Amp.,LA4282
IC701 RH-IX0282AWZZ J AP System Microcomputer,
IX0282AW
IC702 VHIKIA7042P-1 J AG Reset,KIA7042P
IC901 VHIAN78L05/-1 J AE Constant Voltage Regulator,
AN78L05
IC902 VHIKIA7806P-1 J AG Voltage Regulator,KIA7806P
IC903 VHIKIA7812P-1 J AE Voltage Regulator,KIA7812P
IC904 VHIAN78L05/-1 J AE Constant Voltage Regulator,
AN78L05
TRANSISTORS
Q1 VS2SA1318//-1 J AC Silicon,PNP,2SA1318
Q51 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q52 VSKTC3203Y/-1 J AC Silicon,NPN,KTC3203 Y
Q301 VSKTC3194Y/-1 J AD Silicon,NPN,KTC3194 Y
Q351 VSKRA102M//-1 J AC Digital,PNP,KRA102 M
Q381 VSKRA109M//-1 J AC Digital,PNP,KRA109 M
Q401,402 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q501 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q502~505 VS2SC2389SE-1 J AD Silicon,NPN,2SC2389 SE
Q506,507 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q508,509 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q512,513 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q514 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q515 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q516 VSKTC3203Y/-1 J AC Silicon,NPN,KTC3203 Y
Q631,632 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q701 VSKTA1273Y/-1 J AE Silicon,PNP,KTA1273 Y
Q702 VSKTA1271Y/-1 J AC Silicon,PNP,KTA1271 Y
Q703 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
Q704 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q901 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q902 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
DIODES
D1 VHD1SS133//-1 J AA Silicon,1SS133
D81,82 VHD1SS133//-1 J AA Silicon,1SS133
D91~93 VHD1SS133//-1 J AA Silicon,1SS133
D301 VHDDS1SS133-1 J AB Silicon,DS1SS133
D303,304 VHDDS1SS133-1 J AB Silicon,DS1SS133
D381 VHDDS1SS133-1 J AB Silicon,DS1SS133
D701~705 VHDDS1SS133-1 J AB Silicon,DS1SS133
D707,708 VHDDS1SS133-1 J AB Silicon,DS1SS133
D743 VHDDS1SS133-1 J AB Silicon,DS1SS133
D901~904 VHDDS1SS133-1 J AB Silicon,DS1SS133
D905~909 VHD1N4004S/-1 J AB Silicon,1N4004S
D910,911 VHDRL203F//-1 J AE Silicon,RL203F
D912,913 VHD1N4004S/-1 J AB Silicon,1N4004S
D914,915 VHDRL203F//-1 J AE Silicon,RL203F
D916,917 VHD1N4004S/-1 J AB Silicon,1N4004S
D918~920 VHDDS1SS133-1 J AB Silicon,DS1SS133
D921~925 VHD1SS133//-1 J AA Silicon,1SS133
LED701 VHPSLI342UCJ1 J AC LED,Red,SLI342UCJ1
VD301,302 VHCSVC211C/-1 J AG Variable,Capacitance,SVC211C
VD303 VHDSVC348S/-1 J Silicon,SVC348S
ZD61 VHEMTZJ5R6B-1 J AD Zener,5.6V,MTZJ5.6B
ZD351 VHEDZ5R1BSB-1 J AC Zener,5.1V,DZ5.1BSB
ZD401,402 VHEDZ2R4BSB-1 J AB Zener,2.4V,DZ2.4BSB
ZD901 VHEDZ6R2BSA-1 J AB Zener,6.2V,DZ6.2BSA
ZD902 VHEDZ300BSB-1 J AB Zener,30V,DZ300BSB
FILTERS
BF301 RFILR0008AWZZ J AE Band Pass Filter
CF301 RFILF0124AFZZ J AD FM IF,10.7 MHz
CF351 92LFILTA1768A J AE AM IF
TRANSFORMERS
! PT901 RTRNP0253AWZZ J BA Power
! PT902 RTRNP0239AWZZ J AP Power
T301 RCILB0060AWZZ J AC FM Oscillation
T302 RCILI0012AWZZ J AD FM IF
T331 RCILA0052AWZZ J AE AM Antenna
T333 RCILB0058AWZZ J AC AM Oscillation
T381 RCILI0016AFZZ J FM Detection
T382 RCILI0015AWZZ J AE AM IF
COILS
L61 VP-XHR82K0000 J AC 0.82 µH,Choke
L312 RCILR0029AWZZ J AA FM RF
L317 VP-DH101K0000 J AB 100 µH,Choke
L503 VP-MK331K0000 J AB 330 µH,Choke
L701 VP-DH101K0000 J AB 100 µH,Choke
VARIABLE RESISTOR
VR381 RVR-M0025AWZZ J AC 6.8 kohms (B),Semi-VR [VCO]
VIBRATORS
XL1 92LCRSTL1746AT J AH Crystal,16.93 MHz
XL353 RCRSP0002AWZZ J AH Crystal,4.5 MHz
XL701 RCRSP0003AWZZ J AH Crystal,4.19MHz
CAPACITORS
C1 VCEAZA1CW476M J AB 47 µF,16V,Electrolytic
C2 VCKYTV1HB103K J AA 0.01 µF,50V
C3 VCEAZA1HW105M J AB 1 µF,50V,Electrolytic
C4 VCEAZA1HW104M J AB 0.1 µF,50V,Electrolytic
C5,6 VCTYPA1CX333K J AA 0.033 µF,16V
C7 VCEAZA1HW104M J AB 0.1 µF,50V,Electrolytic
C8 VCTYPA1CX683K J AA 0.068 µF,16V
C9 VCTYPA1CX473K J AA 0.047 µF,16V
C10 VCCSTV1HL181J J AA 180 pF,50V
C11,12 VCTYPA1CX104K J AB 0.1 µF,16V
C13 VCKYTV1HB331K J AA 330 pF,50V
C14,15 VCKYTV1HB103K J AA 0.01 µF,50V
C16 VCKYTV1HB472K J AA 0.0047 µF,50V
C17 VCKYTV1HB102K J AA 0.001 µF,50V
C18 VCEAZA1HW474M J AB 0.47 µF,50V,Electrolytic
C19 VCEAZA1HW105M J AB 1 µF,50V,Electrolytic
C20 VCEAZA1CW476M J AB 47 µF,16V,Electrolytic
C21 VCKYTV1HB332K J AA 0.0033 µF,50V
C22 VCCSPA1HL221J J AA 220 pF,50V
C23 VCKYTV1HB272K J AA 0.0027 µF,50V
C24 VCCSTV1HL2R2C J AB 2.2 pF,50V
C25 VCCSTV1HL270J J AA 27 pF,50V
C26 VCTYPA1CX333K J AA 0.033 µF,16V
C27 VCKYTV1HB102K J AA 0.001 µF,50V
C28 VCTYPA1CX104K J AB 0.1 µF,16V
C29 VCEAZA1HW475M J AB 4.7 µF,50V,Electrolytic
C30 VCEAZA1HW104M J AB 0.1 µF,50V,Electrolytic
C31 VCEAZA0JW227M J AC 220 µF,6.3V,Electrolytic
C32 VCKYTV1HB103K J AA 0.01 µF,50V
C33 VCEAZA1HW474M J AB 0.47 µF,50V,Electrolytic
C34 VCEAZA1HW334M J AB 0.33 µF,50V,Electrolytic
C35 VCEAZA1HW105M J AB 1 µF,50V,Electrolytic
C36 VCEAZA1CW107M J AC 100 µF,16V,Electrolytic
C37 VCKZPA1HF223Z J AA 0.022 µF,50V
C38 VCKYTV1HB103K J AA 0.01 µF,50V
C39,40 VCTYPA1CX473K J AA 0.047 µF,16V
C43 VCEAZA0JW337M J AC 330 µF,6.3V,Electrolytic
C44~47 VCCCTV1HH101J J AA 100 pF (CH),50V
C48 VCCSPA1HL101J J AA 100 pF,50V
C49 VCCCTV1HH101J J AA 100 pF (CH),50V
C50 VCKYTV1EF223Z J AA 0.022 µF,25V
C51,52 VCEAZA1CW107M J AC 100 µF,16V,Electrolytic
C54 VCKYTV1HB102K J AA 0.001 µF,50V
