Sharp CD-C606

NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-C606/1900,CP-C606/1900
– 4 –
R717~719 VRD-MN2BD102J J AA 1 kohm,1/8W
R721~725 VRD-MN2BD102J J AA 1 kohm,1/8W
R726 VRD-ST2CD102J J AA 1 kohm,1/6W
R727 VRD-MN2BD102J J AA 1 kohm,1/8W
R728,729 VRD-ST2CD102J J AA 1 kohm,1/6W
R730~734 VRD-MN2BD102J J AA 1 kohm,1/8W
R735~738 VRD-ST2CD102J J AA 1 kohm,1/6W
R739,740 VRD-MN2BD103J J AA 10 kohm,1/8W
R741 VRD-ST2CD104J J AA 100 kohm,1/6W
R742 VRD-MN2BD103J J AA 10 kohm,1/8W
R743 VRD-ST2CD122J J AA 1.2 kohms,1/6W
R745 VRD-MN2BD103J J AA 10 kohm,1/8W
R746,747 VRD-ST2CD103J J AA 10 kohm,1/6W
R748 VRD-MN2BD103J J AA 10 kohm,1/8W
R749 VRD-ST2CD103J J AA 10 kohm,1/6W
R750~754 VRD-MN2BD103J J AA 10 kohm,1/8W
R755 VRD-MN2BD332J J AA 3.3 kohms,1/8W
R756,757 VRD-ST2CD103J J AA 10 kohm,1/6W
R758 VRD-ST2CD182J J AA 1.8 kohms,1/6W
R761 VRD-ST2CD821J J AA 820 ohms,1/6W
R762 VRD-ST2CD122J J AA 1.2 kohms,1/6W
R763 VRD-MN2BD821J J AA 820 ohms,1/8W
R764 VRD-ST2CD821J J AA 820 ohms,1/6W
R765 VRD-ST2CD122J J AA 1.2 kohms,1/6W
R766 VRD-MN2BD122J J AA 1.2 kohms,1/8W
R767 VRD-ST2CD152J J AA 1.5 kohms,1/6W
R768 VRD-MN2BD152J J AA 1.5 kohms,1/8W
R770,771 VRD-ST2CD182J J AA 1.8 kohms,1/6W
R772 VRD-RT2HD3R3J J AA 3.3 ohms,1/2W
R773,774 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R775 VRD-MN2BD102J J AA 1 kohm,1/8W
R776,777 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R778 VRD-ST2CD822J J AA 8.2 kohms,1/6W
R780 VRD-MN2BD392J J AA 3.9 kohms,1/8W
R782 VRD-ST2CD473J J AA 47 kohms,1/6W
R783 VRD-ST2CD104J J AA 100 kohm,1/6W
R785 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R786 VRD-ST2CD101J J AA 100 ohm,1/6W
R791 VRD-MN2BD102J J AA 1 kohm,1/8W
R792 VRD-ST2CD330J J AA 33 ohms,1/6W
R800 VRD-RT2HD100J J AA 10 ohm,1/2W
R901 VRD-ST2CD103J J AA 10 kohm,1/6W
R902 VRD-RT2HD221J J AA 220 ohms,1/2W
R903 VRD-ST2CD123J J AA 12 kohms,1/6W
R904 VRD-RT2HD221J J AA 220 ohms,1/2W
R905 VRD-ST2CD101J J AA 100 ohm,1/6W
R906 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R908 VRD-ST2CD221J J AA 220 ohms,1/6W
R921,922 VRD-ST2EE2R2J J AA 2.2 ohms,1/4W
OTHER CIRCUITRY PARTS
BI401/CNS401 QCNWN1380AWZZ J AF Connector Ass’y,6/6Pin
BI701/CNS701 QCNWN1381AWZZ J AL Connector Ass’y,15/15Pin
BI702/CNS702 QCNWN0907AWZZ J AC Connector Ass’y,8/12Pin
BIM5/CNS10/CNS5 QCNWN1184AWZZ J AL Connector Ass’y,6/10/2Pin
CNP1 92LCONE5P53253 J AB Plug,5Pin
CNP2 QCNCM705HAFZZ J AB Plug,8Pin
CNP3 92LCONE6P53253 J AC Plug,6Pin
CNP3A 92LCONE6P53254 J AC Plug,6Pin
CNP10 QCNCM705KAWZZ J AC Plug,10Pin
CNP11 QCNCM704FAWZZ J AC Plug,6Pin
CNP12 QCNCM704QAWZZ J AG Plug,15Pin
CNP301 92LCONE-3P5268 J AC Plug,3Pin
CNP501 92LCONE-3P5267 J AB Plug,3Pin
CNP502 92LCONE-7P5267 J AC Plug,7Pin
CNP901 QCNCM036BAWZZ J AC Plug,2Pin
CNP902 QCNCM035FAWZZ J AC Plug,6Pin
CNPM1 QCNCM932MAFZZ J AE Plug,12Pin
CNPM2 QCNCM030BAWZZ J AB Pin Header,2Pin
CNS1A/B QCNWN1181AWZZ J AK Connector Ass’y,5/5Pin
CNS2A/B QCNWN1182AWZZ J AH Connector Ass’y,8/8Pin
CNS3A/B QCNWN1183AWZZ J AG Connector Ass’y,6/6Pin
CNS101 QCNWN0895AWZZ J AE Connector Ass’y,3Pin
CNS102 QCNWN0896AWZZ J AG Connector Ass’y,8Pin
FL701 VVKSVA9MS13-1 J AZ FL Display
FW601 QCNWN1249AWZZ J AE Flat Wire,5Pin
FW701 QCNWN1457AWZZ J AD Flat Wire,9Pin
FW703 QCNWN1458AWZZ J AD Flat Wire,10Pin
FW705 QCNWN0713AWZZ J AF Flat Wire,3Pin
FWM1 QCNWN1274AWZZ J AC Flat Cable,2Pin
FWM2 QCNWN0338AWZZ J AD Flat Cable,2Pin
JK601 QJAKM0004AWZZ J AK Jack,Headphones
M1 92LMTR1854CASY J AS Motor with Chassis [Spindle]
M2 92LMTR1854BASY J AP Motor with Gear [Sled]
M3 92LMTR3022AS1 J AU Motor with Worm
[Turntable Up/Down/Loading]
MM1 RMOTV0006AWM1 J AR Motor with Pulley [Tape]
PHM1 VHPI31535CD-1 J AG Phote Interrupter
! RL901 RRLYD0011AWZZ J AE Relay
RX701 VHLN63H380A-1 J AK Remote Sensor,N63H380A
SO601 QTANA0412AWZZ J AF Terminal,Speaker
! SO901 QSOCA0209AWZZ J AH Socket,AC Input
SOLM1 RPLU-0002AWZZ J AH Solenoid Ass’y
SOLM2 RPLU-0002AWZZ J AH Solenoid Ass’y
SW1 QSW-P0004AWZZ J AE Switch,Push Type [Open/Close]
SW2 QSW-F0001AWZZ J AD Switch,Leaf/Skeleton Type
[Mecha Up]
SW3 QSW-P0005AWZZ J AD Switch,Push Type [Disc Number]
SW4 QSW-F9001AW01 J AD Switch,Push Type [Pickup In]
SW701 92LSWICH-1401A J AC Switch,Key Type [Power]
SW702 92LSWICH-1401A J AC Switch,Key Type [Clock]
SW703 92LSWICH-1401A J AC Switch,Key Type [Timer/Sleep]
SW707 92LSWICH-1401A J AC Switch,Key Type [Disc Skip]
SW708 92LSWICH-1401A J AC Switch,Key Type [Open/Close]
SW709 92LSWICH-1401A J AC Switch,Key Type [Rewind]
SW710 92LSWICH-1401A J AC Switch,Key Type [Record/Pause]
SW711 92LSWICH-1401A J AC Switch,Key Type [Memory/Set]
SW712 92LSWICH-1401A J AC Switch,Key Type [Stop]
SW713 92LSWICH-1401A J AC Switch,Key Type [Tuner/Band]
SW714 92LSWICH-1401A J AC Switch,Key Type [Tape]
SW715 92LSWICH-1401A J AC Switch,Key Type [CD]
SW716 92LSWICH-1401A J AC Switch,Key Type [Fast Forward]
SW717 92LSWICH-1401A J AC Switch,Key Type [Tuning Up]
SW718 92LSWICH-1401A J AC Switch,Key Type [Tuning Down]
SW719 92LSWICH-1401A J AC Switch,Key Type [Play]
SW720 92LSWICH-1401A J AC Switch,Key Type [Volume Down]
SW721 92LSWICH-1401A J AC Switch,Key Type [Volume Up]
SW722 92LSWICH-1401A J AC Switch,Key Type
[X-BASS/Demo]
SWM3 92LM-SW1676A J AC Switch,Leaf Type [Fool Proof]
SWM4 QSW-F9003AWZZ J AG Switch,Leaf Type [F.A.S.]
SWM5 92LM-SW1658A J AB Switch,Leaf Type [CAM]
CD MECHANISM PARTS
301 NGERH0011AWZZ J AC Gear,Middle
302 NGERH0012AWZZ J AC Gear,Drive
303 MLEVP0080AWZZ J AC Rail,Guide
304 NSFTM0002AWFW J AE Shaft,Guide
305 92LMCUSN1524A J AD Cushion
! 306 92LHPC1MASY J BG Pickup Unit Ass’y
306- 1 ———— — Pickup Unit
(Not Replacement Item)
306- 2 NGERH0010AWZZ J AB Gear,Rack
306- 3 MSPRC0961AFZZ J AA Spring,Rack
701 XBSSD26P06000 J AA Screw,ø2.6×6mm
702 XHBSD20P05000 J AA Screw,ø2×5mm
703 XBBSD20P03000 J AA Screw,ø2×3mm
704 LX-WZ1070AFZZ J AA Washer,ø1.5×ø3.8×0.25mm
M1 92LMTR1854CASY J AS Motor with Chassis [Spindle]
M2 92LMTR1854BASY J AP Motor with Gear [Sled]
SW4 QSW-F9001AW01 J AD Switch,Push Type [Pickup In]
CABINET PARTS
201 92LCAB3041AS1 J BA Front Panel Ass’y [CD-C606]
201 92LCAB3042AS1 J AZ Front Panel Ass’y [CD-C1900]
201- 1 ———— — Front Panel
(Not Replacement Item)
201- 2 HDECQ0459AWSA J AH Panel,Display [CD-C606]
201- 2 HDECQ0468AWSA J AH Panel,Display [CD-C1900]
201- 3 HDECQ0460AWSA J AH Panel,Operation
201- 4 HDECQ0461AWSA J AC Ring,Operation
201- 5 HDECQ0462AWSA J AC Cap,Operation Center
201- 6 HDECQ0469AWSA J AE Panel,Center Cap
201- 7 JKNBZ0603AWSA J AG Button,Stop/Play/Repeat
201- 8 JKNBZ0604AWSA J AF Button,Function Selector
201- 9 JKNBZ0605AWSA J AF Button,Volume Up/Down
201-10 JKNBZ0606AWSA J AE Button,Power
201-11 JKNBZ0607AWSA J AE Button,X-BASS/Demo
201-12 JKNBZ0608AWSA J AC Button,Timer/Sleep/Clock
201-13 JKNBZ0610AWSA J AM Button,Disc Skip/Open/Close
201-14 PCUSG0022AWZZ J AB Cushion,Leg
