PRICE
RANK
DESCRIPTIONNO.
PARTS CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-C811W/821W
R760 VRD-ST2CD562J J AA 5.6 kohms,1/6W [811W]
R761 VRD-ST2CD821J J AA 820 ohms,1/6W [811W Only]
R762 VRD-ST2CD122J J AA 1.2 kohms,1/6W [811W]
R762~767 VRD-MN2BD102J J AA 1 kohm,1/8W [821W]
R763 VRD-MN2BD821J J AA 820 ohms,1/8W [811W]
R764 VRD-ST2CD821J J AA 820 ohms,1/6W [811W]
R765 VRD-ST2CD122J J AA 1.2 kohms,1/6W [811W]
R766 VRD-MN2BD122J J AA 1.2 kohms,1/8W [811W]
R767 VRD-ST2CD152J J AA 1.5 kohms,1/6W [811W]
R768 VRD-MN2BD152J J AA 1.5 kohms,1/8W [811W]
R768 VRD-ST2CD102J J AA 1 kohm,1/6W [821W]
R769 VRD-MN2BD102J J AA 1 kohm,1/8W [821W Only]
R770~772 VRD-MN2BD102J J AA 1 kohm,1/8W [821W]
R770,771 VRD-ST2CD182J J AA 1.8 kohms,1/6W [811W]
R772 VRD-RT2HD3R3J J AA 3.3 ohms,1/2W [811W]
R773,774 VRD-ST2CD222J J AA 2.2 kohms,1/6W [811W Only]
R775 VRD-MN2BD102J J AA 1 kohm,1/8W
R776~778 VRD-MN2BD102J J AA 1 kohm,1/8W [821W]
R776,777 VRD-ST2CD332J J AA 3.3 kohms,1/6W [811W]
R778 VRD-ST2CD822J J AA 8.2 kohms,1/6W [811W]
R780 VRD-MN2BD392J J AA 3.9 kohms,1/8W [811W]
R780 VRD-ST2CD103J J AA 10 kohm,1/6W [821W]
R781 VRD-ST2CD103J J AA 10 kohm,1/6W [821W Only]
R782 VRD-ST2CD473J J AA 47 kohms,1/6W [811W Only]
R783 VRD-ST2CD104J J AA 100 kohm,1/6W [811W Only]
R785 VRD-ST2CD472J J AA 4.7 kohms,1/6W [811W Only]
R786 VRD-ST2CD101J J AA 100 ohm,1/6W [811W Only]
R791 VRD-MN2BD102J J AA 1 kohm,1/8W [811W Only]
R792 VRD-ST2CD330J J AA 33 ohms,1/6W [811W Only]
R793 VRD-ST2CD274J J AA 270 kohms,1/6W [811W Only]
R794 VRD-ST2CD103J J AA 10 kohm,1/6W [821W Only]
R795 VRD-ST2CD473J J AA 47 kohms,1/6W [821W Only]
R797 VRD-ST2CD104J J AA 100 kohm,1/6W [821W Only]
R798 VRD-ST2CD101J J AA 100 ohm,1/6W [821W Only]
R800 VRD-RT2HD100J J AA 10 ohm,1/2W [811W Only]
R901 VRD-MN2BD103J J AA 10 kohm,1/8W [821W]
R901 VRD-ST2CD103J J AA 10 kohm,1/6W [811W]
R902 VRD-RT2HD221J J AA 220 ohms,1/2W
R903 VRD-ST2CD123J J AA 12 kohms,1/6W
R904 VRD-RT2HD221J J AA 220 ohms,1/2W
R905 VRD-ST2CD101J J AA 100 ohm,1/6W
R906 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R908 VRD-ST2CD221J J AA 220 ohms,1/6W
R910,911 VRD-ST2EE2R2J J AA 2.2 ohms,1/4W [821W Only]
RD01 VRD-ST2CD821J J AA 820 ohms,1/6W [821W Only]
RD02 VRD-ST2CD122J J AA 1.2 kohms,1/6W [821W Only]
RD03 VRD-ST2CD152J J AA 1.5 kohms,1/6W [821W Only]
RD04 VRD-ST2CD182J J AA 1.8 kohms,1/6W [821W Only]
RD05 VRD-ST2CD103J J AA 10 kohm,1/6W [821W Only]
RD06 VRD-MN2BD682J J AA 6.8 kohms,1/8W [821W Only]
RD10 VRD-ST2CD821J J AA 820 ohms,1/6W [821W Only]
RD11 VRD-ST2CD122J J AA 1.2 kohms,1/6W [821W Only]
RD12 VRD-ST2CD152J J AA 1.5 kohms,1/6W [821W Only]
RD13 VRD-ST2CD182J J AA 1.8 kohms,1/6W [821W Only]
RD14 VRD-ST2CD562J J AA 5.6 kohms,1/6W [821W Only]
RD15 VRD-ST2CD392J J AA 3.9 kohms,1/6W [821W Only]
RD21 VRD-ST2CD821J J AA 820 ohms,1/6W [821W Only]
RD22 VRD-ST2CD122J J AA 1.2 kohms,1/6W [821W Only]
RD23 VRD-ST2CD152J J AA 1.5 kohms,1/6W [821W Only]
RD24 VRD-ST2CD182J J AA 1.8 kohms,1/6W [821W Only]
RD25 VRD-ST2CD222J J AA 2.2 kohms,1/6W [821W Only]
RD26 VRD-ST2CD332J J AA 3.3 kohms,1/6W [821W Only]
OTHER CIRCUITRY PARTS
BI401/CNS401 QCNWN1380AWZZ J AF Connector Ass’y,6/6Pin
BI701/CNS701 QCNWN1381AWZZ J AL Connector Ass’y,15/15Pin
BI702/CNS702 QCNWN0907AWZZ J AC Connector Ass’y,8/12Pin
BIM5/CNS10/CNS5 QCNWN1184AWZZ J AL Connector Ass’y,6/10/2Pin
CNP1 92LCONE5P53253 J AB Plug,5Pin
CNP2 QCNCM705HAFZZ J AB Plug,8Pin
CNP3 92LCONE6P53253 J AC Plug,6Pin
CNP3A 92LCONE6P53254 J AC Plug,6Pin
CNP10 QCNCM705KAWZZ J AC Plug,10Pin
CNP11 QCNCM704FAWZZ J AC Plug,6Pin
CNP12 QCNCM704QAWZZ J AG Plug,15Pin
CNP303 QCNCW010JAWZZ J Plug,10Pin
CNP501 92LCONE3P5267X J AB Plug,3Pin
CNP502 92LCONE7P5267X J AC Plug,7Pin
CNP901 QCNCM036EAWZZ J AF Plug,5Pin
CNP902 QCNCM035FAWZZ J AC Plug,6Pin
CNPM1 QCNCM932MAFZZ J AE Plug,12Pin
CNPM2 QCNCM030BAWZZ J AB Pin Header,2Pin
CNS1A/B QCNWN1181AWZZ J AK Connector Ass’y,5/5Pin
CNS2A/B QCNWN1182AWZZ J AH Connector Ass’y,8/8Pin
CNS3A/B QCNWN1183AWZZ J AG Connector Ass’y,6/6Pin
CNS101 QCNWN0895AWZZ J AE Connector Ass’y,3Pin
CNS102 QCNWN0896AWZZ J AG Connector Ass’y,8Pin
CNS303 QCNCM010JAWZZ J Socket,10Pin
! F901 92LFUSET252E J AD Fuse,T2.5A L 250V [811W]
! F901 92LFUSET312E J AD Fuse,T3.15A L 250V [821W]
! F902 92LFUSE-T162-E J AD Fuse,T1.6A L 250V
! F903 92LFUSE-T501E J AD Fuse,T500mA L 250V
FE301 RTUNS0008AWZZ J AN FM Front End
FL701 VVKSVA9MS13-1 J AZ FL Display
FW601 QCNWN1249AWZZ J AE Flat Wire,5Pin
FW701 QCNWN1457AWZZ J AD Flat Wire,9Pin
FW702 QCNWN1476AWZZ J AE Flat Wire,11Pin [821W Only]
FW703 QCNWN0713AWZZ J AF Flat Wire,3Pin [821W]
FW703 QCNWN1458AWZZ J AD Flat Wire,10Pin [811W]
FW705 QCNWN0713AWZZ J AF Flat Wire,3Pin [811W Only]
FWM1 QCNWN1274AWZZ J AC Flat Wire,2Pin
FWM2 QCNWN0338AWZZ J AD Flat Wire,2Pin
JK601 QJAKM0004AWZZ J AK Jack,Headphones
M1 92LMTR1854CASY J AS Motor with Chassis [Spindle]
M2 92LMTR1854BASY J AP Motor with Gear [Sled]
M3 92LMTR3022AS1 J AU Motor with Worm
[Turntable Up/Down/Loading]
MM1 RMOTV0006AWM1 J AR Motor with Pulley [Tape]
PHM1 VHPI31535CD-1 J AG Phote Interrupter
! RL901 RRLYD0011AWZZ J AE Relay
RX701 VHLN63H380A-1 J AK Remote Sensor,N63H380A
SO301 QTANC0301AWZZ J AH Terminal,Antenna
SO601 QTANA0412AWZZ J AF Terminal,Speaker [811W]
SO601 QTANA0801AWZZ J AK Terminal,Speaker [821W]
! SO901 QSOCA0204AWZZ J AF Socket,AC Input
SOLM1 RPLU-0002AWZZ J AH Solenoid Ass’y
SOLM2 RPLU-0002AWZZ J AH Solenoid Ass’y
SW1 QSW-P0004AWZZ J AE Switch,Push Type [Open/Close]
SW2 QSW-F0001AWZZ J AD Switch,Leaf/Skeleton Type
[Mecha Up]
SW3 QSW-P0005AWZZ J AD Switch,Push Type [Disc Number]
SW4 QSW-F9001AW01 J AD Switch,Push Type [Pickup In]
SW401 QSW-S0024AWZZ J AE Switch,Slide Type
[Span Selector]
SW701 92LSWICH-1401A J AC Switch,Key Type [On/Stand-by]
SW702 92LSWICH-1401A J AC Switch,Key Type [Clock]
SW703 92LSWICH-1401A J AC Switch,Key Type [Timer/Sleep]
[811W]
SW703 92LSWICH-1401A J AC Switch,Key Type [Clock] [821W]
SW704 92LSWICH-1401A J AC Switch,Key Type [Timer/Sleep]
[821W Only]
SW706 92LSWICH-1401A J AC Switch,Key Type [Disc Skip]
[821W Only]
SW707 92LSWICH-1401A J AC Switch,Key Type [Disc Skip]
[811W]
SW707 92LSWICH-1401A J AC Switch,Key Type [Open/Close]
[821W]
SW708 92LSWICH-1401A J AC Switch,Key Type [Open/Close]
[811W Only]
SW709 92LSWICH-1401A J AC Switch,Key Type [Fast Forward]
[811W Only]
SW710 92LSWICH-1401A J AC Switch,Key Type [Record Pause]
[811W]
SW710 92LSWICH-1401A J AC Switch,Key Type [Fast Forward]
[821W]
SW711 92LSWICH-1401A J AC Switch,Key Type [Memory Set]
[811W]
SW711 92LSWICH-1401A J AC Switch,Key Type [Record Pause]
[821W]
SW712 92LSWICH-1401A J AC Switch,Key Type [Stop] [811W]
SW712 92LSWICH-1401A J AC Switch,Key Type [Memory/Set]
[821W]
SW713 92LSWICH-1401A J AC Switch,Key Type [Tuner (Band)]
[811W]
SW713 92LSWICH-1401A J AC Switch,Key Type [Stop] [821W]
SW714 92LSWICH-1401A J AC Switch,Key Type [Tape]
[811W Only]
SW714 92LSWICH-1401A J AC Switch,Key Type [Tuner (Band)]
[821W]
SW715 92LSWICH-1401A J AC Switch,Key Type [CD] [811W]
SW715 92LSWICH-1401A J AC Switch,Key Type [Tape] [821W]
SW716 92LSWICH-1401A J AC Switch,Key Type [Rewind]
[811W]
– 5 –
