NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-C811W/821W
SW716 92LSWICH-1401A J AC Switch,Key Type [CD] [821W]
SW717 92LSWICH-1401A J AC Switch,Key Type [Tuning Up]
[811W Only]
SW718 92LSWICH-1401A J AC Switch,Key Type [Tuning Down]
[811W Only]
SW719 92LSWICH-1401A J AC Switch,Key Type [Play]
[811W Only]
SW720 92LSWICH-1401A J AC Switch,Key Type [Volume Down]
[811W Only]
SW721 92LSWICH-1401A J AC Switch,Key Type [Volume Up]
[811W Only]
SW722 92LSWICH-1401A J AC Switch,Key Type
[X-BASS/DEMO] [811W]
SW722 92LSWICH-1401A J AC Switch,Key Type [Rewind]
[821W]
SW723 92LSWICH-1401A J AC Switch,Key Type [Tuning Up]
[821W Only]
SW724 92LSWICH-1401A J AC Switch,Key Type [Tuning Down]
[821W Only]
SW725 92LSWICH-1401A J AC Switch,Key Type [Play]
[821W Only]
SW726 92LSWICH-1401A J AC Switch,Key Type [Volume Down]
[821W Only]
SW727 92LSWICH-1401A J AC Switch,Key Type [Volume Up]
[821W Only]
SW728 92LSWICH-1401A J AC Switch,Key Type
[X-BASS/DEMO] [821W Only]
! SW902 QSOCE0008AWZZ J AH Switch,Slide Type
[AC Voltage Selector]
SWM3(220-8) 92LM-SW1676A J AC Switch,Leaf Type [Fool Proof]
SWM4(220-9) QSW-F9003AWZZ J AG Switch,Leaf Type [F.A.S.]
SWM5(220-10) 92LM-SW1658A J AB Switch,Leaf Type [CAM]
CD MECHANISM PARTS
301 NGERH0011AWZZ J AC Gear,Middle
302 NGERH0012AWZZ J AC Gear,Drive
303 MLEVP0080AWZZ J AC Rail,Guide
304 NSFTM0002AWFW J AE Shaft,Guide
305 92LMCUSN1524A J AD Cushion
! 306 92LHPC1MASY J BG Pickup Unit Ass’y
306- 1 ———— –– Pickup Unit
(Not Replacement Item)
306- 2 NGERH0010AWZZ J AB Gear,Rack
306- 3 MSPRC0961AFZZ J AA Spring,Rack
701 XBSSD26P06000 J AA Screw,ø2.6×6mm
702 XHBSD20P05000 J AA Screw,ø2×5mm
703 XBBSD20P03000 J AA Screw,ø2×3mm
704 LX-WZ1070AFZZ J AA Washer,ø1.5×ø3.8×0.25mm
M1 92LMTR1854CASY J AS Motor with Chassis [Spindle]
M2 92LMTR1854BASY J AP Motor with Gear [Sled]
SW4 QSW-F9001AW01 J AD Switch,Push Type [Pickup In]
CABINET PARTS
201 92LCAB3046AS1 J AY Front Panel Ass’y [821W]
201 92LCAB3049AS1 J AY Front,Panel Ass’y [811W]
201- 1 ———— –– Front Panel
(Not Replacement Item)
201- 2 HDECQ0490AWSA J Panel,Display (811W)
201- 2 HDECQ0502AWSA J Panel,Display (821W)
201- 3 HDECQ0460AWSA J AH Panel,Operation
201- 4 HDECQ0461AWSA J AC Ring,Operation
201- 5 HDECQ0462AWSA J AC Cap,Operation Center
201- 6 HDECQ0469AWSA J AE Panel,Center Cap
201- 7 JKNBZ0603AWSA J AG Button,Stop/Play/Repeat
201- 8 JKNBZ0604AWSA J AF Button,Function Selector
201- 9 JKNBZ0605AWSA J AF Button,Volume Up/Down
201-10 JKNBZ0629AWSA J AE Button,On/Stand-by
201-11 JKNBZ0607AWSA J AE Button,X-BASS/Demo
201-12 JKNBZ0608AWSA J AC Button,Timer/Sleep/Clock
201-13 JKNBZ0610AWSA J AM Button,Disc Skip/Open/Close
201-14 PCUSG0022AWZZ J AB Cushion,Leg
202 92LCAB3041BS1 J AM Side Panel Ass’y,Left
202- 1 ———— –– Side Panel,Left
(Not Replacement Item)
202- 2 PCUSG0022AWZZ J AB Cushion,Leg
203 92LCAB3041CS1 J AM Side Panel Ass’y,Right
203- 1 ———— –– Side Panel,Right
(Not Replacement Item)
203- 2 PCUSG0022AWZZ J AB Cushion,Leg
204 92LCOV3022AS1 J AM CD Tray Cover Ass’y
204- 1 ———— –– Cover,CD Tray
(Not Replacement Item)
204- 2 GCOVA1224AWSA J AE Cover,CD Tray Panel,Left
204- 3 GCOVA1225AWSA J AE Cover,CD Tray Panel,Right
204- 4 92LBADGE1671A J AC Badge,SHARP
205 GITAR0494AWSA J Back Board [811W]
205 GITAR0500AWSA J Back Board [821W]
206 GDORF0072AWSA J AK Cassette Holder,Tape 1
207 GDORF0073AWSA J AK Cassette Holder,Tape 2
208 HDECQ0463AWSA J AE Panel,Cassette Holder,Tape 1
209 HDECQ0464AWSA J AE Panel,Cassette Holder,Tape 2
210 LANGK0170AWFW J AC Bracket,Headphone Support
211 LANGT0051AWFW J AF Bracket,Heat Sink Support
[821W]
211 LANGT0055AWFW J AD Bracket,Heat Sink [811W]
212 LCHSM0087AWSA J AQ Main Chassis
213 LHLDZ1087AWSA J AC Holder,FL Display
214 MLIFP0003AWZZ J AE Damper,Cassette Holder
215 MSPRD0092AWFJ J AB Spring,Cassette Holder ,Tape 1
216 MSPRD0093AWFJ J AB Spring,Cassette Holder ,Tape 2
218 PRDAR0113AWFW J AV Heat Sink [821W]
218 PRDAR0138AWFW J AH Heat Sink [811W]
220 92LMECHA2823A J BL Tape Mechanism Ass’y
220- 1(MM1) RMOTV0006AWM1 J AR Motor with Pulley [Tape]
220- 2 NBLTK0011AWZZ J AC Belt,Main [Tape 1]
220- 3 NBLTK0012AWZZ J AB Belt,Main [Tape 2]
220- 4 NBLTK0030AWZZ J AC Belt,Sub
220- 5 NROLY0002AWZZ J AF Pinch Roller
220- 6 92LMRPH1746A J AM Head,Record/Playback
[Tape 1/Tape 2]
220- 7 RHEDA0001AWZZ J AG Head,Erase [Tape 2]
220- 8(SWM3) 92LM-SW1676A J AC Switch,Leaf Type [Fool Proof]
220- 9(SWM4) QSW-F9003AWZZ J AG Switch,Leaf Type [F.A.S.]
220-10(SWM5) 92LM-SW1658A J AB Switch,Leaf Type [CAM]
222 92LN-BAND1318A J AA Nylon Band,80mm
223 GCAB-1044AWSA J AM CD Player Base
224 GCAB-1052AWSA J AP Top Cabinet
225 LANGF0032AWZZ J AC Support,Turntable Lock Lever
226 LCHSZ0010AWZZ J AM Chassis,Loading
227 LCHSZ0011AWZZ J AG Chassis,CD Mechanism
228 92LHOLD3022AS1 J AB Stabilizer Ass’y
228- 1 ———— –– Stabilizer
(Not Replacement Item)
228- 2 PMAGF0001AWZZ J AF Magnet,Stabilizer
228- 3 92LSUPT1749D J AA Support,Stabilizer Magnet
229 LHLDZ1140AWZZ J AB Guide
230 LHLDZ1141AWZZ J AB Support,Pitch
231 LHLDZ1204AWSA J AD Support,Stabilizer
232 MLEVP0066AWZZ J AE Lever,Shift
233 MLEVP0067AWZZ J AC Lever,Lock
234 MLEVP0068AWZZ J AB Lever,Change
235 MLEVP0070AWZZ J AB Lever,Turntable Lock
236 MSPRC0020AWFJ J AB Spring,Turntable Lock Lever
237 MSPRC0024AWFW J AB Spring,Solenoid
238 MSPRD0044AWFJ J AB Spring,Lock Lever
239 NBLTK0033AWZZ J AC Belt,Drive
240 NGERH0064AWZZ J AD Gear,Cam
241 NGERH0065AWZZ J AB Gear,Turntable
242 NGERK0003AWZZ J AC Gear,Drive
243 NGERK0004AWZZ J AB Gear,Bevel
244 NGERK0005AWZZ J AB Gear,Loading
245 NGERW0006AWZZ J AC Gear,Worm Wheel
246 NPLYD0002AWZZ J AC Pulley
247 NROLP0009AWZZ J AB Roller
248 NTNT-0018AWSA J AK Turntable
249 PCOVZ1013AWZZ J AB Cover,Wire
! 251 QLUGP0001AWZZ J AC Lug
252 PCUSG0022AWZZ J AB Cushion
253 LHLDZ1230AWZZ J AC Holder,LED
254 LANGT0054AWFW J AE Bracket,Tuner PWB
255 LANGT0049AWFW J AK Bracket,PWB Support
256 92LCAUT1706B J AA Label,Laser
257 92LCAUT1706A1 J AC Label,Class 3A Laser
259 TSPC-0571AWZZ J AC Label,Specifications
[For Thailand] [811W]
259 TSPC-0572AWZZ J AC Label,Specifications [For Taiwan]
259 TSPC-0573AWZZ J AC Label,Specifications
[For Central South America]
[811W]
259 TSPC-0590AWZZ J AC Label,Specifications
[ForThailand][821W]
– 6 –
