Sharp CD-DK2600V - Page 10

CD-DK2600V
– 10 –
CP-DK2600
1 Front Panel 1. Front Panel ............ (A1) x1 10-3
2 Woofer 1. Screw ..................... (B1) x4 10-4
4 Tweeter 1. Screw ..................... (C1) x2 10-4
5 Super Tweeter 1. Screw ..................... (D1) x2 10-4
STEP REMOVAL PROCEDURE FIGURE
CP-DK2600
Figure 10-4
(P2) x3
(P1) x1
(Q1) x5
(P1) x1
Loading
Motor
PWB
CD
Mechanism
Woofer
(B1)x4
Ø4x12mm
(C1)x2
Ø3x10mm
(D1)x2
Ø3x10mm
Figure 10-1
Figure 10-2
(N3) x2
(N2) x2
(N3) x2
CD Video
PWB
CD Player
Base
(N1)x1
ø3x8mm
Screw Driver
(A1)x1
Figure 10-3
