NO.
PRICE
RANK
DESCRIPTION
PARTS CODENO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-DK2600V
RS716 VRD-MN2BD102J J AA 1 kohm,1/8W
RS717,718 VRD-ST2CD102J J AA 1 kohm,1/6W
RS720 VRD-MN2BD221J J AA 220 ohms,1/8W
RS721~723 VRD-ST2CD102J J AA 1 kohm,1/6W
RS724~726 VRD-MN2BD103J J AA 10 kohm,1/8W
RS727~733 VRD-ST2CD102J J AA 1 kohm,1/6W
RV1 VRS-TV2AB103J J AA 10 kohm,1/10W
RV2 VRS-TV2AB102J J AA 1 kohm,1/10W
RV11 VRS-TV2AB102J J AA 1 kohm,1/10W
RV15 VRS-TV2AB102J J AA 1 kohm,1/10W
RV20 VRS-TV2AB102J J AA 1 kohm,1/10W
RV22 VRS-TV2AB102J J AA 1 kohm,1/10W
RV37 VRS-TV2AB102J J AA 1 kohm,1/10W
RV38~43 VRS-TV2AB392J J AA 3.9 kohms,1/10W
RV44~47 VRS-TV2AB392J J AA 3.9 kohms,1/10W
RV48~50 VRS-TV2AB392J J AA 3.9 kohms,1/10W
RV59 VRS-TV2AB103J J AA 10 kohm,1/10W
RV60 VRS-TV2AB101J J AA 100 ohm,1/10W
RV61 VRS-TV2AB104J J AA 100 kohm,1/10W
RV62,63 VRS-TV2AB151J J AA 150 ohms,1/10W
RV64 VRS-TV2AB470J J AA 47 ohms,1/10W
RV84 VRS-TV2AB472J J AA 4.7 kohms,1/10W
RV85 VRS-TV2AB103J J AA 10 kohm,1/10W
RV86 VRS-TV2AB472J J AA 4.7 kohms,1/10W
RV93,94 VRS-TV2AB103J J AA 10 kohm,1/10W
RV95 VRS-TV2AB682J J AA 6.8 kohms,1/10W
RV96 VRS-TV2AB333J J AA 33 kohms,1/10W
OTHER CIRCUITRY PARTS
BI4/CNS4 QCNWN1572AWZZ J AF Connector Ass’y,6/6Pin
BI401/CNS401 QCNWN1540AWZZ J AF Connector Ass’y,5/5Pin
BI501/CNSV3 QCNWN1617AWZZ J Connector Ass’y,2/2Pin
BI701/CNS701 QCNWN1578AWZZ J Connector Ass’y,12/12Pin
BI702/CNS702 QCNWN1607AWZZ J AG Connector Ass’y,9/9Pin
BIK1/CNSK1 QCNWN1573AWZZ J Connector Ass’y,11/11Pin
CNP1 QCNCM704GAWZZ J AC Plug,7Pin
CNP2 QCNCM704HAWZZ J AC Plug,8Pin
CNP3 92LCONE6P53253 J AC Plug,6Pin
CNP3A 92LCONE6P53254 J AC Plug,6Pin
CNP4 QCNCM705FAFZZ J AB Plug,6Pin
CNP11 92LCONE5P53254 J AB Plug,5Pin
CNP12 QCNCM932MAFZZ J AE Plug,12Pin
CNP101 QCNCM705CAFZZ J AA Plug,3Pin
CNP102/CNS102
QCNWN1609AWZZ J Connector Ass’y,7/6Pin
CNP301 92LCONE2P5268 J AB Plug,2Pin
CNP401 92LCONEBP53253 J AC Plug,11Pin
CNP501 QCNCM010NAWZZ J AC Plug,13Pin
CNP601 92LCONE5P52287 J AC Socket,5Pin
CNP602 QCNCWZG25AWZZ J AE Socket,25Pin
CNP701 QCNCWZF25AWZZ J AE Socket,25Pin
CNP702 QCNCWZF13AWZZ J AC Plug,13Pin
! CNP801 QCNCM049EAWZZ J AD Plug,9Pin
CNP802 92LCONE8P5267X J AD Plug,8Pin
CNP803 QCNWM050CAWZZ J Plug,3Pin
CNP804 92LCONE9P53253 J AC Plug,9Pin
CNP805 QCNCW010NAWZZ J AC Socket,13Pin
CNP806 92LCONE2P53253 J AB Plug,2Pin
CNPV3 92LCONE2P53254 J AB Plug,2Pin
CNS1A/B QCNWN1537AWZZ J AG Connector Ass’y,7/7Pin
CNS2A/B QCNWN1538AWZZ J AG Connector Ass’y,8/8Pin
CNS3A/B QCNWN1539AWZZ J AE Connector Ass’y,6/6Pin
CNS100 QCNWN1417AWZZ J Lead Wire with Lug
CNS806 QCNWN1542AWZZ J AC Connector Ass’y,2Pin
CNS907 QCNWN1610AWZZ J AD Flat Wire,5Pin
! F801,802 92LFUSET502E J AC Fuse,T5A L 250V
! F803,804 92LFUSET402E J AD Fuse,T4A L 250V
! F805 92LFUSET202E J AC Fuse,T2A L 250V
FC701 QCNWN1568AWZZ J AG Flat Cable,25Pin
FC702 QCNWN1544AWZZ J AE Flat Cable,13Pin
FL701 VVKBJ744GNK-1 J BD FL Display,BJ744GNK
JK1 QJAKJ0007AWZZ J AF Jack,Mic 1
JK2 QJAKJ0007AWZZ J AF Jack,Mic 2
JK201 QSOCJ0409AWZZ J AF Jack,Video In
JK501 QSOCJ0112AWZZ J Jack,Video Out
JK601 QJAKM0004AWZZ J AK Jack,Headphones
M1 92LMTR2790CASY J BB Motor with Chassis [Spindle]
M2 92LMTR1854BASY J AP Motor with Gear [Sled]
M3 92LTWMEN7E6Y J AR Motor with Worm Pulley
[T/T Up/Down Loading]
M901 RMOTV0027AWZZ J AM Motor,Air Cooling Fan
RL901,902 RRLYD0014AWZZ J AK Relay
RX701 VHLN63H380A-1 J AK Remote Sensor,N63H380A
SO301 QTANC0206AWZZ J Terminal,Antenna
SO901 QTANA1003AWZZ J AH Terminal,Speaker
SW1 SWMPU10780MLB J AH Switch,Push Type [Open/Close]
SW2 SWMPU11470MLB J AE Switch,Push Type [Clamp]
SW3 SWMPU11470MLB J AE Switch,Push Type [Disc Number]
SW4 QSW-F9001AW01 J AD Switch,Leaf Type [Pickup In]
SW701 92LSWICH1401AT J AC Switch,Key Type [CD]
SW702 92LSWICH1401AT J AC Switch,Key Type [TAPE]
SW703 92LSWICH1401AT J AC Switch,Key Type
[TUNING DOWN]
SW704 92LSWICH1401AT J AC Switch,Key Type
[MEMORY/SET]
SW705 92LSWICH1401AT J AC Switch,Key Type [REV]
SW706 92LSWICH1401AT J AC Switch,Key Type [FF]
SW707 92LSWICH1401AT J AC Switch,Key Type [PLAY]
SW708 92LSWICH1401AT J AC Switch,Key Type [STOP]
SW709 92LSWICH1401AT J AC Switch,Key Type
[MEMORY/SET]
SW710 92LSWICH1401AT J AC Switch,Key Type [REC]
SW711 92LSWICH1401AT J AC Switch,Key Type [TUNING UP]
SW712 92LSWICH1401AT J AC Switch,Key Type [VIDEO]
SW713 92LSWICH1401AT J AC Switch,Key Type [TUNER]
SW714 92LSWICH1401AT J AC Switch,Key Type [DIMMER]
SW715 92LSWICH1401AT J AC Switch,Key Type [X-BASS]
SW716 92LSWICH1401AT J AC Switch,Key Type [EQUAL]
SW717 92LSWICH1401AT J AC Switch,Key Type [NORMAL]
SW718 92LSWICH1401AT J AC Switch,Key Type [PHANTOM]
SW719 92LSWICH1401AT J AC Switch,Key Type [BY-PASS]
SW720 92LSWICH1401AT J AC Switch,Key Type
[ON/STAND-BY]
SW721 92LSWICH1401AT J AC Switch,Key Type [CLOCK]
SW722 92LSWICH1401AT J AC Switch,Key Type [TIMER]
SW723 92LSWICH1401A J AD Switch,Slide Type
[KARAOKE MODE]
SW724 92LSWICH1401A J AD Switch,Slide Type [P.B.C]
SW725 92LSWICH1401A J AD Switch,Slide Type [OSD]
SW726 92LSWICH1401A J AD Switch,Slide Type [DIGEST]
SW727 92LSWICH1401A J AD Switch,Slide Type
[BOOK MARK]
SW728 92LSWICH1401AT J AC Switch,Key Type [DISC 1]
SW729 92LSWICH1401AT J AC Switch,Key Type [DISC 2]
SW730 92LSWICH1401AT J AC Switch,Key Type [DISC 3]
SW731 92LSWICH1401AT J AC Switch,Key Type [DISC SKIP]
SW732 92LSWICH1401AT J AC Switch,Key Type
[OPEN/CLOSE]
SW733 92LSWICH1401AT J AC Switch,Key Type
[Reverse Mode]
SW799 QSW-S0024AWZZ J AE Switch,Slide Type
[SPAN SELECTOR]
! SW801 QSOCE0008AWZZ J AH Switch,Slide Type,Voltage
Selector
CD MECHANISM PARTS
301 NGERH0011AWZZ J AC Gear,Middle
302 NGERH0012AWZZ J AC Gear,Drive
303 MLEVP0080AWZZ J AC Rail,Guide
304 NSFTM0020AWFW J AD Shaft,Guide
305 92LM-CUSN1524A J AC Cushion
! 306 92LHPC1LXASY J BD Pickup Unit Ass’y
306- 1 ———— — Pickup Unit
(Not Replacement Item)
306- 2 NGERR0043AFZZ J AC Gear,Rack
306- 3 MSPRC0961AFZZ J AA Spring,Rack
701 XBSSD26P06000 J AA Screw,ø2.6×6mm
702 XHBSD20P05000 J AA Screw,ø2×5mm
703 XBBSD20P03000 J AA Screw,ø2×3mm
704 LX-WZ1070AFZZ J AA Washer,ø1.5×3.8×0.25mm
M1 92LMTR2790CASY J BB Motor with Chassis [Spindle]
M2 92LMTR1854BASY J AP Motor with Gear [Sled]
SW4 QSW-F9001AW01 J AD Switch,Leaf Type [Pickup In]
CABINET PARTS
XEBSD26P08000 J AA Screw,ø2.6×8mm
201 92LCAB3311AASY J Front Panel Ass’y
201- 1 ———— — Front Panel
(Not Replacement Item)
201- 2 92LBADGE1671A J AC Badg,SHARP
201- 3 GCOVA1251AWSA J AH Cover,Cassette Holder,Tape 1
201- 4 GCOVA1256AWSA J AB Indicator,PRESET
– 6 –
