Sharp CD-E600 User Manual

PRICE
RANK
DESCRIPTIONNO. PART CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-E600/CD-E66
202 92LCAB4906BASY J AN Side Panel Ass’y,Left [CD-E66]
202- 1 ———— –– Side Panel,Left
(Not Replacement Item)
202- 2 PCUSG0022AWZZ J AB Cushion,Leg
203 92LCAB4905CASY J AN Side Panel Ass’y,Right
[CD-E600]
203 92LCAB4906CASY J AN Side Panel Ass’y,Right [CD-E66]
203- 1 ———— –– Side Panel,Right
(Not Replacement Item)
203- 2 PCUSG0022AWZZ J AB Cushion,Leg
204 GCAB-1197AWZZ J AM Loading Tray
205 GCAB-1215AWSA J AT Top Cabinet [CD-E600]
205 GCAB-1215AWSB J AR Top Cabinet [CD-E66]
206 GCOVA1486AWSA J AK Cover,CD Tray [CD-E600]
206 GCOVA1469AWSB J AK Cover,CD Tray [CD-E66]
207 GITAR1122AWSA J AM Rear Panel [CD-E600 for U.S.A.]
207 GITAR1175AWSA J AM Rear Panel [CD-E66 for U.S.A.]
207 GITAR1190AWSA J AM Rear Panel [CD-E600 for
Canada]
207 GITAR1191AWSA J AM Rear Panel [CD-E66 for Canada]
208 KMECB0032AWZZ J BD Tape Mechanism Ass’y
208- 1 92LF513-894 J Head Plate Block [Tape 2]
208- 2 92LF525-357 J Motor with Pulley [Tape]
208- 3 92LF567-719 J –– Tape Mechanism PWB Ass’y
208- 4 92LF522-063 J AZ Clutc Ass’y Block [Tape 2]
208- 5 92LFF20D-12 J Belt,Main [Tape 2]
208- 6 92LF514-131 J Pinch Roller
208- 7 92LFF19S-31 J AL Belt,FF/REW [Tape 1]
208- 8 92LFF20B-13 J Belt,Main [Tape 1]
208- 9 92LF522-061 J Clutc Ass’y Block [Tape 1]
208-10 92LF19S-52 J AH Belt,FF/REW [Tape 2]
208-11 92LF513-895 J Head Plate Block [Tape 1]
209 LANGK0110AWFW J AE Bracket,Cassette Lock,Tape 1
210 LANGK0111AWFW J AE Bracket,Cassette Lock,Tape 2
211 LANGK0381AWFW J AE Bracket,Fan Support
212 LBSHC0005AWZZ J AD Bushing,AC Power Supply Cord
213 LCHSM0176AWFW J AN Chassis,Main
214 LCHSM0155AWZZ J AS Chassis,Loading
215 LHLDM1018AWZZ J AE Stabilizer
216 LHLDZ1455AWZZ J AF Holder,CD Mechanism
217 LHLDZ1358AWZZ J AF Stabilizer Holder
218 LHLDZ1433AWZZ J AD Holder,Gear
219 LHLDZ1458AWZZ J AD Holder,FL Display
220 LHLDZ1412AWZZ J AC Holder,LED
221 MCAMP0010AWZZ J AE Gear,Can Upper
222 MCAMP0011AWZZ J AE Gear,Can Lower
223 MLEVP0109AWZZ J AB Lever,Cam Lock
224 MLEVP0110AWZZ J AB Lever,Switch A
225 MLEVP0111AWZZ J AB Lever,Switch B
226 MLEVP0112AWZZ J AB Turntable Actuator
227 MLOKC0003AWZZ J AD Lock Lever,Cassette,Tape 1
228 MLOKC0004AWZZ J AD Lock Lever,Cassette,Tape 2
229 MSPRC0033AWFJ J AB Spring,Friction
230 MSPRD0109AWFJ J AB Spring,Cassette Lock,Tape 1
231 MSPRD0110AWFJ J AB Spring,Cassette Lock,Tape 2
232 MSPRP0057AWFW J AC Spring,Tray Lock
233 MSPRP0068AWFW J AB Spring,Motor Gear
234 NFANP0001AWZZ J AD Rotary Fan
235 NGERH0152AWZZ J AC Gear,Turntable Drive
236 NGERH0153AWZZ J AC Gear,Drive
237 NGERW0020AWZZ J AC Gear,Center
238 NGERW0021AWZZ J AC Gear,Idler
239 NGERW0022AWZZ J AD Gear,Worm
240 NGERW0023AWZZ J AC Motor Gear
241 NTNT-0022AWZZ J AK Turntable
242 PCUSG0022AWZZ J AB Cushion,Leg
243 PMAGF0007AWZZ J AD Magnet
244 PRDAR0269AWFW J AY Heat Sink
1 245 QACCD0022AWZZ J AM AC Power Supply Cord
246 QCNWN1860AWZZ J AC Lug Wire
1 247 QFSHD0001AWZZ J AB Holder,Fuse
248 92LCSPR1431C J AA Spring,Ring
249 92LMT0304302 J AB Plate,Metal
250 92LNBAND1318A J AA Nylon Band,80mm
251 92LPT0303002 J AB Roller
253 HDECQ0964AWSA J AF Panel,Edge Light
254 LHLDZ1451AWZZ J AC Holder,Edge Light
257 PSHEP0122AWZZ J AD Sheet,Edge Light
258 MLEVF0117AWFW J AC Plate,Support
601 XHBSD30P06000 J AA Screw,ø3×6mm
602 XEBSD30P12000 J AA Screw,ø3×12mm
603 LX-EZ0010AWFD J AA Screw,Special
604 XEBSD30P10000 J AA Screw,ø3×10mm
605 LX-HZ0009AWFD J AC Screw,Special
606 XHBSD26P04000 J AA Screw,ø2.6×4mm
607 92LSC0314WBZI J AB Screw,ø3×14mm
608 XJBSD20P05000 J AA Screw,ø2×5mm
609 XHBSD40P08000 J AA Screw,ø4×8mm
610 XBBSD20P04000 J AA Screw,ø2×4mm
611 XJBSF30P10000 J AA Screw,ø3×10mm
612 XJSSD30P10000 J AA Screw,ø3×10mm
613 XESSD30P10000 J AA Screw,ø3×10mm
615 LX-JZ0036AWFD J AB Screw,Special
616 LX-JZ0037AWFD J AB Screw,ø3×18mm
618 XJBSD26P08000 J AA Screw,ø2.6×8mm
619 XJBSD30P10000 J AA Screw,ø3×10mm
620 92LSC0310RBZT J Screw,ø3×10mm
621 XJBSD30P08000 J AA Screw,ø3×8mm
PACKING PARTS (Except for U.S.A.)
SPAKA0417AWZZ J AL Packing Add.
SPAKC1594AWZZ J AT Packing Case
[CD-E66 for Canada]
SPAKC1595AWZZ J AT Packing Case
[CD-E600 for Canada]
SPAKP0032AWZZ J AF Polyethylene Bag,Unit
SPAKZ0895AWZZ J AD Pad,Support
92LBAG1460C1 J AB Polyethylene Bag,Accessories
ACCESSORIES
QANTL0007AWZZ J AK AM/FM Loop Antenna
TINSE0493AWZZ J AE Operation Manual [For U.S.A.]
TINSK0147AWZZ J AF Operation Manual [For Canada]
TINSZ0881AWZZ J AB Quick Guide [For U.S.A. Only]
TLABR1296AWZZ J AB Label,Bar Code
[CD-E66 for Canada Only]
TLABR1297AWZZ J AB Label,Bar Code
[CD-E600 for Canada Only]
TLABZ0593AWZZ J AB Energy Star Label (Set)
TLABZ1322AWZZ J AC Label,Feature [Tape 2]
TLABZ1332AWZZ J AC Label,Feature [Tape 1]
RRMCG0358AWSA J AR Remote Control
GFTAT1017AWSA J AK Battery Lid,Remote Control
P.W.B. ASSEMBLY (Not Replacement Item)
PWB-A1~5 92LPWB4905MANS J –– Main/Display/Headphones/LED
A/LED B (Combined Ass’y)
1 PWB-B1,2 92LPWB4905PWRS J –– Power/Transformer
(Combined Ass’y)
PWB-C 92LPWB4896CDUS J –– CD Servo
PWB-D QPWBF0027AWZZ J AD CD Motor (PWB Only)
PWB-E QPWBF0749AWZZ J AD CD Loading Motor (PWB Only)
PWB-F 92LF567-719 J –– Tape Mechanism
OTHER SERVICE PARTS
UDSKA0004AFZZ J AZ CD Pickup Lens Cleaner
SPEAKER BOX PARTS
901 GBOXS2025AWSA J Speaker Box Ass’y,Right
[CP-E600]
901 GBOXS2025AWSB J Speaker Box Ass’y,Right
[CP-E66]
901 GBOXS4025AWSA J Speaker Box Ass’y,Left
[CP-E600]
901 GBOXS4025AWSB J Speaker Box Ass’y,Left [CP-E66]
902 CPNLS1080AW01 J AX Front Panel Ass’y,Left [CP-E600]
902 CPNLS1080AW02 J AX Front Panel Ass’y,Left [CP-E66]
902 CPNLS1081AW01 J AX Front Panel Ass’y,Right
[CP-E600]
902 CPNLS1081AW02 J AC Front Panel Ass’y,Right
[CP-E66]
903 HPNLS1082AWSA J AT Side Panel,Left [CP-E600]
– 5 –
CP-E600/CP-E66
