Sharp CD-E77 User Manual

NO.
PRICE
RANK
DESCRIPTION
PARTS CODENO. PART CODE
PRICE
RANK
DESCRIPTION
CD-E700/CD-E77
C125,126 VCEAZA1HW226M J AB 22 µF,50V,Electrolytic
C127,128 VCTYPA1CX223K J AA 0.022 µF,16V
C129,130 VCTYMN1CX332K J AA 0.0033 µF,16V
C131,132 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C133 VCEAZA1HW226M J AB 22 µF,50V,Electrolytic
C134 VCEAZA1AW227M J AC 220 µF,10V,Electrolytic
C135 VCTYMN1EF223Z J AA 0.022 µF,25V
C137 VCQYKA1HM473K J AB 0.047 µF,50V,Mylar
C138 VCQPKA2AA822J J AA 0.0082 µF,100V,Polypropylene
C139 VCQYKA1HM393K J AB 0.039 µF,50V,Mylar
C140 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C141 VCEAZA1CW107M J AC 100 µF,16V,Electrolytic
C143 VCEAZA1HW335M J AB 3.3 µF,50V,Electrolytic
C150 VCEAZA1HW476M J AB 47 µF,50V,Electrolytic
C302 VCKYMN1HB102K J AA 0.001 µF,50V
C303 VCCCMN1HH100J J AA 10 pF (CH),50V
C304 VCTYMN1CY103N J AA 0.01 µF,16V
C305 VCCCMN1HH4R7C J AA 4.7 pF (CH),50V
C306 VCTYMN1EF223Z J AA 0.022 µF,25V
C307 VCEAZA1HW106M J AB 10 µF,50V,Electrolytic
C308 VCCCMN1HH4R7C J AA 4.7 pF (CH),50V
C309 VCKYMN1HB102K J AA 0.001 µF,50V
C310 VCCCMN1HH150J J AA 15 pF (CH),50V
C311 VCCSMN1HL180J J AA 18 pF,50V
C312 VCTYMN1EF223Z J AA 0.022 µF,25V
C313 VCCCMN1HH220J J AA 22 pF (CH),50V
C314,315 VCTYMN1CX472K J AA 0.0047 µF,16V
C316 VCTYMN1EF223Z J AA 0.022 µF,25V
C317 VCKYMN1HB102K J AA 0.001 µF,50V
C318 VCKYMN1HB101K J AA 100 pF,50V
C320 VCKYBT1HB102K J AA 0.001 µF,50V
C323 VCTYMN1EF223Z J AA 0.022 µF,25V
C324 VCCUMN1HJ4R7D J AA 4.7 pF (UJ),50V
C330 VCCUMN1HJ150J J AA 15 pF (UJ),50V
C331 VCKZPA1HF473Z J AA 0.047 µF,50V
C332 VCTYMN1EF223Z J AA 0.022 µF,25V
C334 VCCCMN1HH220J J AA 22 pF (CH),50V
C335 VCKYMN1HB561K J AA 560 pF,50V
C338 VCKYMN1HB102K J AA 0.001 µF,50V
C342 VCTYMN1EF223Z J AA 0.022 µF,25V
C350,351 VCTYMN1EF223Z J AA 0.022 µF,25V
C352 VCEAZA1HW106M J AB 10 µF,50V,Electrolytic
C353,354 VCTYMN1EF223Z J AA 0.022 µF,25V
C355 VCCSMN1HL220J J AA 22 pF,50V
C356 VCKYMN1HB102K J AA 0.001 µF,50V
C357 VCEAZA1HW225M J AB 2.2 µF,50V,Electrolytic
C358 VCEAZA1HW105M J AB 1 µF,50V,Electrolytic
C361 VCTYMN1EF223Z J AA 0.022 µF,25V
C362 VCEAZA1HW335M J AB 3.3 µF,50V,Electrolytic
C363 VCTYMN1EF223Z J AA 0.022 µF,25V
C364 VCEAZA1HW225M J AB 2.2 µF,50V,Electrolytic
C365 VCKZPA1HF223Z J AA 0.022 µF,50V
C366 VCKYMN1HB102K J AA 0.001 µF,50V
C367 VCEAZA1HW105M J AB 1 µF,50V,Electrolytic
C368 VCEAZA1HW105M J AB 1 µF,50V,Electrolytic
C369 VCCUMN1HJ270J J AA 27 pF (UJ),50V
C370~372 VCEAZA1HW105M J AB 1 µF,50V,Electrolytic
C373,374 VCTYPA1CX153K J AA 0.015 µF,16V
C380 VCEAZA1HW106M J AB 10 µF,50V,Electrolytic
C381 VCCCMN1HH120J J AA 12 pF (CH),50V
C382 VCCCMN1HH150J J AA 15 pF (CH),50V
C383 VCCSBT1HL470J J AA 47 pF,50V
C384 VCKYMN1HB102K J AA 0.001 µF,50V
C385 VCTYMN1CY103N J AA 0.01 µF,16V
C386 VCKYMN1HB331K J AA 330 pF,50V
C387 VCTYMN1EF223Z J AA 0.022 µF,25V
C388 VCKYMN1HB102K J AA 0.001 µF,50V
C389 VCKYBT1HB102K J AA 0.001 µF,50V
C391 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C392 VCKYMN1HB102K J AA 0.001 µF,50V
C393 VCEAZA1HW105M J AB 1 µF,50V,Electrolytic
C394 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C395 VCTYMN1EF223Z J AA 0.022 µF,25V
C396 VCEAZA1AW107M J AB 100 µF,10V,Electrolytic
C397 VCTYMN1EF223Z J AA 0.022 µF,25V
C398 VCEAZA1AW107M J AB 100 µF,10V,Electrolytic
C399 VCTYMN1EF223Z J AA 0.022 µF,25V
C601 VCEAZA1CW227M J AC 220 µF,16V,Electrolytic
C602 VCKZPA1HF223Z J AA 0.022 µF,50V
C603 VCEAZA1HW226M J AB 22 µF,50V,Electrolytic
C605~608 VCFYHA1HA124J J AB 0.12 µF,50V,Thin Film
C609,610 VCEAZA1HW105M J AB 1 µF,50V,Electrolytic
C611,612 VCTYMN1CX222K J AA 0.0022 µF,16V
C613,614 VCEAZA1HW105M J AB 1 µF,50V,Electrolytic
C615,616 VCEAZA1HW475M J AB 4.7 µF,50V,Electrolytic
C617~624 VCEAZA1HW105M J AB 1 µF,50V,Electrolytic
C625,626 VCTYMN1CX222K J AA 0.0022 µF,16V
C639 VCEAZA1HW105M J AB 1 µF,50V,Electrolytic
C640 VCEAZA1HW226M J AB 22 µF,50V,Electrolytic
C651~653 VCKYMN1HB221K J AA 220 pF,50V
C690,691 VCKYMN1HB391K J AA 390 pF,50V
C701 VCEAZA1HW105M J AB 1 µF,50V,Electrolytic
C702 VCEAZA1AW227M J AC 220 µF,10V,Electrolytic
C704 VCCSMN1HL150J J AA 15 pF,50V
C705 VCCSMN1HL180J J AA 18 pF,50V
C707 VCEAZA1HW105M J AB 1 µF,50V,Electrolytic
C709,710 VCTYMN1CX472K J AA 0.0047 µF,16V
C712 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C714 VCEAZA1HW335M J AB 3.3 µF,50V,Electrolytic
C715 VCTYMN1EF103Z J AB 0.01 µF,25V
C717 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C720,721 VCTYMN1EF223Z J AA 0.022 µF,25V
C801 VCEAZA1VW107M J AC 100 µF,35V,Electrolytic
C802,803 VCEAZA1HW476M J AB 47 µF,50V,Electrolytic
C804 VCEAZA1JW227M J AD 220 µF,63V,Electrolytic
C805 VCEAZA2AW226M J AC 22 µF,100V,Electrolytic
C806~809 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
C810,811 VCQYKU2AM224K J AB 0.22 µF,100V,Mylar
C841 VCEAZA0JW108M J AC 1000 µF,6.3V,Electrolytic
C842 VCEAZA1VW477M J AD 470 µF,35V,Electrolytic
C843 VCQYKA1HM473K J AB 0.047 µF,50V,Mylar
1 C844 RC-KZ002LAWZZ J AC 0.0047 µF,250V,Ceramic
C851 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
C854,855 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
C856 VCEAZW1VW338M J AH 3300 µF,35V,Electrolytic
C858,859 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
C861 VCKZPA1HF223Z J AA 0.022 µF,50V
C863 VCEAZA1HW226M J AB 22 µF,50V,Electrolytic
C864 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
C865 VCEAZA1HW106M J AB 10 µF,50V,Electrolytic
C901,902 VCEAZA1HW104M J AB 0.1 µF,50V,Electrolytic
C903,904 VCKYMN1HB102K J AA 0.001 µF,50V
C905,906 VCEAZA1HW226M J AB 22 µF,50V,Electrolytic
C907 VCKYMN1HB101K J AA 100 pF,50V
C908 VCCCMN1HH3R3C J AA 3.3 pF (CH),50V
C909 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
C910 VCCCMN1HH3R3C J AA 3.3 pF (CH),50V
C911,912 VCEAZA2AW107M J AD 100 µF,100V,Electrolytic
C913 VCKYMN1HB101K J AA 100 pF,50V
C914,915 VCEAZA2AW107M J AD 100 µF,100V,Electrolytic
C916 VCEAZA1HW107M J AC 100 µF,50V,Electrolytic
C917 VCQYKA1HM103K J AA 0.01 µF,50V,Mylar
C918 VCEAZA1HW107M J AC 100 µF,50V,Electrolytic
C919 VCQYKA1HM103K J AA 0.01 µF,50V,Mylar
C920 RC-EZ0029AWZZ J AN 3300 µF,71V,Electrolytic
C921,922 RC-EZ0106AWZZ J AH 4700 µF,35V,Electrolytic
C923 RC-EZ0029AWZZ J AN 3300 µF,71V,Electrolytic
C925 VCEAZA1HW476M J AB 47 µF,50V,Electrolytic
C928,929 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
C931 VCEAZA1HW106M J AB 10 µF,50V,Electrolytic
C946 VCEAZA1HW104M J AB 0.1 µF,50V,Electrolytic
RESISTORS
VRD-MN2BD000C J AA 0 ohm,Jumper,ø1.4×3.5mm,Ivory
R1,2 VRD-MN2BD822J J AA 8.2 kohms,1/8W
R3 VRD-MN2BD223J J AA 22 kohms,1/8W
R4,5 VRD-MN2BD822J J AA 8.2 kohms,1/8W
R6 VRD-MN2BD223J J AA 22 kohms,1/8W
R7 VRD-ST2CD470J J AA 47 ohms,1/6W
R8 VRD-ST2CD103J J AA 10 kohm,1/6W
R9 VRD-MN2BD100J J AA 10 ohm,1/8W
R10 VRD-MN2BD273J J AA 27 kohms,1/8W
R11 VRD-MN2BD103J J AA 10 kohm,1/8W
R12 VRD-MN2BD331J J AA 330 ohms,1/8W
R13 VRD-ST2CD153J J AA 15 kohms,1/6W
R14,15 VRD-MN2BD102J J AA 1 kohm,1/8W
R16 VRD-ST2CD102J J AA 1 kohm,1/6W
R18 VRD-MN2BD102J J AA 1 kohm,1/8W
R19 VRD-ST2CD153J J AA 15 kohms,1/6W
R20 VRD-MN2BD103J J AA 10 kohm,1/8W
R21 VRD-ST2EE1R0J J AA 1 ohm,1/4W
R22 VRD-ST2CD101J J AA 100 ohm,1/6W
– 2 –
