CD-M4000W/CP-M4000
– 1 –
INTEGRATED CIRCUITS
IC1 VHILC78645E-1 J AY CD Servo,LC78645E
IC2 VHIM63001FP-1 J AX Focus/Tracking/Spin/Sled Driver,
M63001FP
IC101 VHIAN7345K/-1 J AM Playback and Record/Playback
Amp.,AN7345K
IC301 VHITA7358AP-1 J AG FM Front End,TA7358AP
IC302 VHILC72131/-1 J AP PLL (Tuner),LC72131
IC303 VHILA1832S/-1 J AN FM IF Det./FM Mpx./AM IF,
LA1832S
IC601 VHILC75341/-1 J AM Audio Processor,LC75341
IC701 RH-IX0460AWZZ J System Microcomputer,
IX0460AW
IC702 VHIBU2092F/-1 J AM Input/Output Expander,BU2092F
IC703,704 VHIKIA4558P-1 J AC Ope Amp.,KIA4558P
IC860 VHIKIA4558P-1 J AC Ope Amp.,KIA4558P
IC901 VHISTK41203-1 J Power Amp.,STK41203
ICK1 VHIM65856SP-1 J AX Mic Amp.,M65856SP
ICK2 VHIKIA4558P-1 J AC Ope Amp.,KIA4558P
TRANSISTORS
Q1 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q2 VSKTC3203Y/-1 J AC Silicon,NPN,KTC3203 Y
Q3 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q103~106 VS2SC1845F/-1 J AC Silicon,NPN,2SC1845 F
Q107,108 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q109 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q110,111 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q121,122 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q124 VS2SA1015GR-1 J AB Silicon,PNP,2SA1015 GR
Q126 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q128 VSKTC3203Y/-1 J AC Silicon,NPN,KTC3203 Y
Q302 VSKTC3194Y/-1 J AD Silicon,NPN,KTC3194 Y
Q360 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q603~606 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q701~703 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q704,705 VSKTA1273Y/-1 J AE Silicon,PNP,KTA1273 Y
Q708 VSKTA1273Y/-1 J AE Silicon,PNP,KTA1273 Y
Q709 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q803 VSKTA1274Y/-1 J AE Silicon,PNP,KTA1274 Y
Q850 VSKTC2026//-1 J AF Silicon,NPN,KTC2026
Q851 VHIKIA7810AP1 J AF Voltage Regulator,KIA7810AP
Q852 VHIKIA7805AP1 J AF Constant Voltage Regulator,
KIA7805AP
Q862,863 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q864 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q865 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q901~904 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q905 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
Q907 VSKTC3203Y/-1 J AC Silicon,NPN,KTC3203 Y
QK1 VSKTC3203Y/-1 J AC Silicon,NPN,KTC3203 Y
DIODES
D1,2 VHDDS1SS133-1 J AB Silicon,DS1SS133
D301,302 VHDDS1SS133-1 J AB Silicon,DS1SS133
D305 VHDDS1SS133-1 J AB Silicon,DS1SS133
D701~704 VHDDS1SS133-1 J AB Silicon,DS1SS133
D712,713 VHDDS1SS133-1 J AB Silicon,DS1SS133
D718 VHDDS1SS133-1 J AB Silicon,DS1SS133
D720~723 VHDDS1SS133-1 J AB Silicon,DS1SS133
D809 VHDTS6B04GM-1 J AP Silicon,TS6B04GM
D810 VHDD10XB60F-1 J AL Silicon,D10XB60F
D811~816 VHDDS1N404S-1 J AB Silicon,DS1N404S
D818 VHDDS1N404S-1 J AB Silicon,DS1N404S
D861~863 VHDDS1SS133-1 J AB Silicon,DS1SS133
D864 VHDDS1N404S-1 J AB Silicon,DS1N404S
D901,902 VHDDS1N404S-1 J AB Silicon,DS1N404S
D907~909 VHDDS1SS133-1 J AB Silicon,DS1SS133
D911~913 VHDDS1SS133-1 J AB Silicon,DS1SS133
DK1,2 VHDDS1SS133-1 J AB Silicon,DS1SS133
DT701 VHDDS1SS133-1 J AB Silicon,DS1SS133
DT703 VHDDS1SS133-1 J AB Silicon,DS1SS133
LED701,702 VHP4204UYT7-1 J AD LED,Yellow,4204UYT7
LED703,704 VHP31URT21+-1 J AD LED,Red,31URT21
LED705 VHP4204UYT7-1 J AD LED,Yellow,4204UYT7
LED706~708 VHP4204UGT7-1 J AD LED,Green,4204UGT7
LED722 VHP4204SRT7-1 J AD LED,Red,4204SRT7
ZD1 VHEDZ3R3BSB-1 J AB Zener,3.3V,DZ3.3BSB
ZD2 VHEDZ3R9BSB-1 J AC Zener,3.9V,DZ3.9BSB
ZD351 VHEDZ5R1BSB-1 J AC Zener,5.1V,DZ5.1BSB
ZD701 VHEMTZJ6R2C-1 J AC Zener,6.2V,MTZJ6.2C
ZD801 VHEDZ300BSB-1 J AB Zener,30V,DZ30BSB
ZD802 VHEDZ6R2BSA-1 J AB Zener,6.2V,DZ6.2BSA
ZD804 VHEDZ110BSB-1 J AB Zener,11V,DZ11BSB
ZD851 VHEDZ3R9BSB-1 J AC Zener,3.9V,DZ3.9BSB
ZD901,902 VHEDZ120BSB-1 J AB Zener,12V,DZ12BSB
ZD951 VHEDZ130BSB-1 J AB Zener,13V,DZ13BSB
ZDK1 VHEMTZJ5R6B-1 J AD Zener,5.6V,MTZJ5.6B
FILTERS
BF301 RFILR0008AWZZ J AE Band Pass Filter
CF303 RFILF0124AFZZ J AD FM IF,10.7 MHz
CF351 RFILF0003AWZZ J AK FM IF
CF352 RFILA0009AWZZ J AE AM IF
TRANSFORMERS
T301 RCILB0065AWZZ J AC FM,OSC
T302 RCILI0017AWZZ J AB FM IF
T303 RCILA0052AWZZ J AE AM Tracking
T306 RCILB0067AWZZ J AD AM,OSC
T351 RCILI0019AWZZ J AD AM IF
1 T801 RTRNP0365AWZZ J Power
COILS
L1 VP-XHR82K0000 J AC 0.82 µH
L104 VP-MK331K0000 J AB 330 µH,Choke
L312 RCILR0056AWZZ J AB FM RF
L351,352 VP-DH101K0000 J AB 100 µH,Choke
L901,902 RCILZ0137AFZZ J AA 0.29 µH
VARIABLE RESISTOR
VRK1 92LVRR1674A J AF 20 kohms (B) [Mic Volume]
VARIABLE CAPACITORS
VD301 VHCSVC348S/-1 J AK Variable Capacitance,SVC348S
VD302,303 VHCKDV147B/-1 J AH Variable Capacitance,KDV147B
VIBRATORS
X351 92LCRSTL1425A J AF Crystal,456 kHz
X352 RCRSP0019AWZZ J AF Crystal,4.5 MHz
XL1 RCRM-0041AWZZ J AF Ceramic,33.8688 MHz
XL701 RCRSP0003AWZZ J AH Crystal,4.1943 MHz
CAPACITORS
C1 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C2 VCTYMN1CY103N J AA 0.01 µF,16V
C3 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C4 VCKYMN1HB102K J AA 0.001 µF,50V
C5 VCQYKA1HM473J J AB 0.047 µF,50V,Mylar
C6 VCTYPA1CX104K J AB 0.1 µF,16V
C8 VCTYMN1CX472K J AA 0.0047 µF,16V
C9 VCEAZA1AW107M J AB 100 µF,10V,Electrolytic
C10 VCEAZA1HW106M J AB 10 µF,50V,Electrolytic
C11 VCEAZA1HW224M J AB 0.22 µF,50V,Electrolytic
C12 VCCSPA1HL101J J AA 100 pF,50V
C13 VCTYMN1EF223Z J AA 0.022 µF,25V
C14 RC-EZY107AF1A J AB 100 µF,10V,Electrolytic
C16 VCEAEA0JW337M J AD 330 µF,6.3V,Electrolytic
C18 VCEAZA1AW107M J AB 100 µF,10V,Electrolytic
C23,24 RC-EZY106AF1H J AB 10 µF,50V,Electrolytic
C25,26 VCTYMN1CX152K J AA 0.0015 µF,16V
C27 VCTYMN1EF223Z J AA 0.022 µF,25V
C28 VCKYMN1HB101K J AA 100 pF,50V
C30 VCKYMN1HB101K J AA 100 pF,50V
C32~34 VCKYMN1HB101K J AA 100 pF,50V
C35 VCQYKA1HM473J J AB 0.047 µF,50V,Mylar
C36 VCEAZA1HW225M J AB 2.2 µF,50V,Electrolytic
C37 VCTYPA1CX104K J AB 0.1 µF,16V
C38 VCTYMN1CY103N J AA 0.01 µF,16V
C39 VCEAZA1AW107M J AB 100 µF,10V,Electrolytic
C40 VCEAZA0JW227M J AC 220 µF,6.3V,Electrolytic
