Sharp CD-MPS1000 - Page 27

CD-MPS1000
2 – 22
ASSY REVERSELY N.G
WHEN FIX & AFTER FIX TO BASE CHASSIS
AFTER ASSY CONFIRM THE FREE DROP
APPLY GREASE
BIG SLOT MUST FACING OUT
GEAR POSITION DURING FIXING
CONFIRM BOTH GEAR SIT PROPELY & LOCKED
18
114
135
136
