Sharp CD-MPS1000 User Manual

CD-MPS1000
2 – 32
MOTOR SCREWING HOLE
13.8 + 0.2
-0
12.2
APPLY GREASE
MUST HAVE GAP
REFERENCE ONLY
MOTOR GEAR HEIGHT FROM
MAIN BASE 12.2
1.5 + 0.5
-0
SCREW TORQUE
AFTER SCREW MOTOR,CONFIRM THE
ARRANGEMENT AS IN FIGURE 2
FIGURE 2
M1,2
801
28
+
-
0.1
+
-
0.1
