NO.
PRICE
RANK
DESCRIPTION
PARTS CODENO. PART CODE
PRICE
RANK
DESCRIPTION
CD-MPS1000
611 LX-LZA002AWZZ J AD Push Rivet
612 LX-LZ0002AW00 J AC Snap Rivet
613 LX-JZ0037AWFD J AB Screw,ø3×18mm
614 LX-JZ0044AWFF J AB Screw,ø3×10mm
615 XWHSD32-10080 J AA Washer,ø3.2×ø8×1mm
616 XHBSD30P06000 J AA Screw,ø3×6mm
618 LX-JZ0036AWFD J AB Screw,Special
ACCESSORIES/PACKING PARTS
QANTL0005AWZZ J AG AM Loop Antenna
SPAKAA010AWZZ J AL Packing Add.,Left/Right
SPAKAA013AWZZ J AM Packing Add.,Top/Bottom
SPAKCA101AWZZ J Packing Case
SPAKP0032AWZZ J AF Polyethylene Bag,Unit
SPAKZA007AWZZ J AH Spacer
SPAKZA010AWZZ J AF Sheet,Protection
SPAKZA050AWZZ J AE Pad,Support
SSAKH0053AWZZ J AC Polyethylene Bag,Speaker
TINSEA045AWZZ J AG Operation Manual
TLABZA113AWSA J AB Energy Star Label (Set)
TLABZA100AWZZ J Label,Feature
92LBAG1460C1 J AB Polyethylene Bag,Accessories
92LFANT1746A J AD FM Antenna
RRMCG0395AWSA J AU Remote Control
GFTAT1017AWSA J AG Lid,Remote Control
P.W.B. ASSEMBLY (Not Replacement Item)
PWB-A1~3 92LPWB5736MANS J –– Main/Display/Spacer
(Combined Ass’y)
1 PWB-B1,2 92LPWB5529PWRS J –– Power/Game Input
(Combined Ass’y)
PWB-C 92LPWB5612CDUS J –– CD Servo
PWB-D(209-3) ———— –– Tape Mechanism
PWB-E QPWBF1055AWZZ J AE 5-Changer Motor (PWB Only)
PWB-F QPWBF0027AWZZ J AD CD Motor (PWB Only)
OTHER SERVICE PARTS
UDSKA0004AFZZ J AZ CD Pickup Lens Cleaner
SPEAKER BOX PARTS
901 GBOXLA009AWSB J BF Speaker Box Ass’y,Left
902 GBOXRA009AWSB J BF Speaker Box Ass’y,Right
903 CPNLSA005AW01 J BD Front Panel Ass’y,Left
904 CPNLSA006AW01 J BD Front Panel Ass’y,Right
905 HPNLSA007AWSA J AX Side Panel,Left
906 HPNLSA008AWSA J AX Side Panel,Right
907 TSPC-A128AWZZ J Label,Specifications
908 PFLT-0046AWZZ J AC Felt
909 QCNWNA001AWZZ J AY Speaker Cord Ass’y
910 XJBSD40P16000 J AB Screw,ø4×16mm
911 XJBSD30P12000 J AA Screw,ø3×12mm
912 XMPSF40P35000 J AC Screw,ø4×35mm
913 XMBSF40P16000 J AC Screw,ø4×16mm
914 PCUSG0147AWZZ J AC Leg Cushion
915 PFLT-0079AWZZ J AC Felt
SP1,2 RSP-ZA006AWZZ J BC Woofer
SP3,4 RSP-ZA007AWZZ J AS Tweeter
SP5,6 RSP-ZA008AWZZ J AS Passive Radiator
SP7~10 LHLDZA006AWM1 J AS Super Tweeter Ass’y
151 NGERH0204AWZZ J AB Tray Reduction Gear E
152 NSFTT0084AWFD J AD Shaft,Main Base
801 LX-BZA006AWFD J AB Screw,Special
803 XEBSD20P10000 J AA Screw,ø2×10mm
804 XEBSD30P10000 J AA Screw,ø3×10mm
M1 92LMTR5529AASY J AD Motor with Gear [Tray]
M2 92LMTR5529AASY J AD Motor with Gear [Main Cam]
SW1 QSW-P9003AWZZ J AD Switch,Push Type [CLAMP]
SW2 QSW-P9003AWZZ J AD Switch,Push Type [TRAY SW1]
SW3 QSW-P9003AWZZ J AD Switch,Push Type [TRAY SW2]
SW4 QSW-P9006AWZZ J AF Switch,Push Type [DISC]
CABINET PARTS
201 CCABA5736AW01 J Front Panel Ass’y
201- 1 ———— –– Front Panel
(Not Replacement Item)
201- 2 GCOVA1521AWSA J AK Cover,Cassette [Tape 1]
201- 3 GCOVA1522AWSA J AK Cover,Cassette [Tape 2]
201- 4 GDORF0127AWSA J AE Holder,Cassette [Tape 1]
201- 5 GDORF0128AWSA J AE Holder,Cassette [Tape 2]
201- 6 HDECQ1108AWSA J AE Panel,Cassette [Tape 1]
201- 7 HDECQ1109AWSA J AE Panel,Cassette [Tape 2]
201- 8 JKNBZ0982AWSA J AE Button,Disc Number
201- 9 MLIF-A001AWZZ J AD Damper
201-10 JKNBZA023AWSD J AM Button,Operation A
201-11 JKNBZA024AWSD J AM Button,Operation B
201-12 JKNBZ0985AWSA J AE Button,Function
201-13 JKNBZ0986AWSA J AE Button,Memory
201-14 JKNBZ0987AWSA J AE Button,Tuning
201-15 JKNBZ0991AWSA J AF Button,Power
201-16 GCOVA1533AWSA J AC Cover,Timer
201-17 HBDGB1007AWSA J AD Badge,SHARP
201-18 MSPRDA002AWFJ J AB Spring,Cassette [Tape 1]
201-19 MSPRDA003AWFJ J AB Spring,Cassette [Tape 2]
201-20 HDECQA039AWSA J AH Volume Knob Ring,A
201-21 HDECQ1106AWSA J AF Volume Knob Ring,B
201-22 HDECQA053AWSA J AK Decoration Plate,Amp.
201-23 MLOKC0014AWZZ J AC Lock,Cassette [Tape 1]
201-24 MLOKC0015AWZZ J AC Lock,Cassette [Tape 2]
201-25 MSPRD0196AWFJ J AB Spring,Cassette Lock [Tape 1]
201-26 MSPRD0197AWFJ J AC Spring,Cassette Lock [Tape 2]
201-27 JKNBZA058AWSA J AH Button,MP3 Navigation,A
201-28 JKNBZ0989AWSA J AE Button,MP3 Navigation,B
202 GCAB-3101AWSA J AY Cabinet,Top/Side
203 PCUSG0022AWZZ J AB Cushion,Leg
204 GITARA112AWSA J AK Rear Panel,B
205 GCOVA1520AWSA J AG Cover,CD Tray
206 LCHSZ0025AWZZ J AM Chassis,Changer
207 PSLDMA009AWFW J AG Shield,Dust Cover
208 92LNBAND1318A J AA Nylon Band,80mm
209 KMECBA001AWZZ J BC Tape Mechanism Ass’y
210 HDECQ1110AWSA J AF Panel,Edge Light
212 QCNWN1860AWZZ J AC Lug Wire
213 JKNBK0103AWSA J AD Knob,Volume
214 HDECQ1104AWSA J AL Cover,Volume Knob
216 92LCSPR1431C J AA Spring,Ring
217 LCHSM0201AWFW J AR Chassis,Main
218 GITAR1273AWSA J AP Rear Panel,A
219 LBND-1011AWZZ J AA Nylon Band
1 220 QACCD0022AWZZ J AM AC Power Supply Cord
221 LBSHC0005AWZZ J AD Bushing,AC Power Supply Cord
222 NFANP0001AWZZ J AD Rotary Fan
223 LANGK0437AWFW J AE Bracket,Fan Support A
1 224 QFSHD0001AWZZ J AB Holder,Fuse
225 PRDAR0320AWFW J AV Heat Sink
226 LHLDZ9024AWZZ J AD Holder,Edge Light
227 LANGT0042AWFW J AC Bracket,PWB Support
228 PSHEPA010AWZZ J AE Shield Sheet,Main PWB
229 LHLDZA004AWZZ J AC Holder,Rib Support
230 LANGK0435AWFW J AF Bracket,Heat Sink Support
231 PFLT-A006AWZZ J AB Felt
601 XJBSD30P10000 J AA Screw,ø3×10mm
602 XEBSD30P10000 J AA Screw,ø3×10mm
603 LX-EZ0005AWFD J AA Screw,ø2.6×10mm
604 XEBSD26P10000 J AA Screw,ø2.6×10mm
605 XESSD30P10000 J AA Screw,ø3×10mm
606 XJSSD30P08000 J AA Screw,ø3×8mm
607 LX-EZ0010AWFD J AA Screw,Special
609 XBBSD20P04000 J AA Screw,ø2×4mm
610 LX-JZ0010AFFD J AA Screw,ø3×10mm
– 6 –
CP-MPS1000
