Sharp CD-PC671H

PRICE
RANK
DESCRIPTIONNO.
PARTS CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-PC671H/651H
– 1 –
INTEGRATED CIRCUITS
IC1 VHILA9241M/-1 J AS Servo Amp.,LA9241M
IC2 VHILC78622N-1 J AY Servo/Signal
Control,LC78622NE
IC3 VHIM63001FP-1 J AX Focus/Trackig/Spin/Slide Driver,
M63001FP
IC101 VHIAN7345K/-1 J AM Playback and Record/Playback
Amp.,AN7345K
IC302 VHILC72131/-1 J AP PLL (Tuner),LC72131
IC303 VHILA1832//-1 J AR FM/AM IF MPX.,LA1832
IC401 VHILC75396N-1 J AX Audio Processor,LC75396N
IC471 VHIKIA4558P-1 J AC Ope Amp.,KIA4558P
[PC671H Only]
IC501 VHILV1035M/-1 J BC Dolby Pro Logic Decorder,
LV1035M
IC601 VHINJM4560D-1 J AH Ope Amp.,NJM4560D
IC650,651 VHIKIA4558P-1 J AC Ope Amp.,KIA4558P
IC701 RH-IX0281AWZZ J AZ System Control Microcomputer,
IX0281AW
IC702,703 VHIBU2092F/-1 J AM Input/Output Expander,BU2092F
IC704 VHIKIA7042AP1 J AC Reset,KIA7042AP
IC803 VHIAN78L05/-1 J AE Constant Voltage Regulator,
AN78L05
IC804 VHIKIA7812P-1 J AE Voltage Regulator,KIA7812P
[PC671H Only]
IC805 VHIKIA7806P-1 J AG Voltage Regulator,KIA7806P
[PC671H Only]
IC806 VHIAN78L05/-1 J AE Constant Voltage Regulator,
AN78L05
IC901 VHISTK40704-1 J AZ Power Amp.,STK40704
[PC651H]
IC901 VHISTK40724-1 J BD Power Amp.,STK40724
[PC671H]
IC951 VHILA4451//-1 J AN Power Amp.,LA4451
[PC671H Only]
ICT21 VHILC72720/-1 J AW RDS Decorder,LC72720
TRANSISTORS
Q1 VS2SA1318//-1 J AC Silicon,PNP,2SA1318
Q51 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q52 VSKTC3203Y/-1 J AC Silicon,NPN,KTC3203 Y
Q103~106 VS2SC2389SE-1 J AD Silicon,NPN,2SC2389 SE
Q107,108 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q109 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q110,111 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q121,122 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q124 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q126 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q128 VSKTC3203Y/-1 J AC Silicon,NPN,KTC3203 Y
Q301 VS2SC380-O/-1 J AC Silicon,NPN,2SC380 O
Q353,354 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q360 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q361 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
Q371 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q401~404 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q405 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q601~604 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q702 VSKTA1273Y/-1 J AE Silicon,PNP,KTA1273 Y
Q703 VSKTA1271Y/-1 J AC Silicon,PNP,KTA1271 Y
Q704 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q705~707 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q801 VSKTA1274Y/-1 J AE Silicon,PNP,KTA1274 Y
Q802 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
Q903 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
Q904 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
[PC671H Only]
Q905 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q906 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
Q907 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
[PC671H Only]
Q908 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
QT21 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
DIODES
D1 VHD1SS133//-1 J AA Silicon,1SS133
D81,82 VHD1SS133//-1 J AA Silicon,1SS133
D91~93 VHD1SS133//-1 J AA Silicon,1SS133
D101,102 VHDDS1SS133-1 J AB Silicon,DS1SS133
D301~304 VHDDS1SS133-1 J AB Silicon,DS1SS133
D351~353 VHDDS1SS133-1 J AB Silicon,DS1SS133
D401~403 VHDDS1SS133-1 J AB Silicon,DS1SS133
D515,516 VHD1N4004S/-1 J AB Silicon,1N4004S
D651~654 VHDDS1SS133-1 J AB Silicon,DS1SS133
D702 VHDDS1SS133-1 J AB Silicon,DS1SS133
[PC651H Only]
D704 VHDDS1SS133-1 J AB Silicon,DS1SS133
[PC671H Only]
D715~722 VHDDS1SS133-1 J AB Silicon,DS1SS133
! D801,802 VHDTS6B04GM-1 J AP Silicon,TS6B04GM
D803~809 VHD1N4004S/-1 J AB Silicon,1N4004S
D810 VHDDS1SS133-1 J AB Silicon,DS1SS133
D811~814 VHD1N4004S/-1 J AB Silicon,1N4004S
D817~819 VHDDS1SS133-1 J AB Silicon,DS1SS133
D821~825 VHDDS1SS133-1 J AB Silicon,DS1SS133
D901 VHDDS1SS133-1 J AB Silicon,DS1SS133
[PC671H Only]
D902 VHD1SS133//-1 J AA Silicon,1SS133
D903 VHDDS1SS133-1 J AB Silicon,DS1SS133
D904~907 VHD1N4004S/-1 J AB Silicon,1N4004S
D908 VHDDS1SS133-1 J AB Silicon,DS1SS133
D909 VHDDS1SS133-1 J AB Silicon,DS1SS133
[PC671H Only]
LED701 VHPL1154GT4-1 J AB LED,Green,L1154GT4
LED702 VHPSLI342YCB1 J AC LED,Orange,SLI342YCB
LED703 VHPSLI342DCB1 J AC LED,Yellow,SLI342DCB
LED704 VHPSLI342UCB1 J AC LED,Red,SLI342UCB
LED705 VHPSLI342DCB1 J AC LED,Orange,SLI342UCB
LED706 VHPSLI342YCB1 J AC LED,Yellow,SLI342YCB
LED707 VHPL1154GT4-1 J AB LED,Green,L1154GT4
LED711~713 VHPSLI342YCJ1 J AC LED,Yellow,SLI342YCJ
LED716,717 VHPSLI342YCJ1 J AC LED,Yellow,SLI342YCJ
LED718 VHPSLI325YC-1 J AB LED,Yellow,SLI325YC
[PC671H Only]
LED719,720 VHPSLI342YCE1 J AC LED,Yellow,SLI342YCE
[PC671H Only]
LED721 VHPSLI342YCJ1 J AC LED,Yellow,SLI342YCJ
[PC671H Only]
LED722 VHPSLI342UCJ1 J AC LED,Red,SLI342UCJ
LED723,724 VHPSLI342YCJ1 J AC LED,Yellow,SLI342YCJ
[PC671H Only]
VD301 VHCSVC348S/-1 J AK Variable Capacitance,SVC348S
ZD61 VHEMTZJ5R6B-1 J AD Zener,5.6V,MTZJ5.6B
ZD351 VHEDZ5R1BSB-1 J AC Zener,DZ5R1BSB
ZD352 VHEDZ3R9BSB-1 J AC Zener,3.9V,DZ3.9BSB
ZD651 VHEDZ6R2BSC-1 J AB Zener,DZ6R2BSC
ZD801 VHEDZ6R2BSA-1 J AB Zener,DZ6R2BSA
ZD802 VHEDZ300BSB-1 J AB Zener,DZ300BSB
ZD803 VHEDZ130BSB-1 J AB Zener,DZ130BSB
ZDT21 VHEDZ5R1BSB-1 J AC Zener,5.1V,DZ5.1BSB
FILTERS
CF301 RFILF0072AFZZ J AG FM IF
CF302 RFILF0072AFZZ J AG FM IF
CF351 RFILF0003AWZZ J AK FM IF
CF352 RFILA0009AWZZ J AE AM IF
TRANSFORMERS
! PT801 RTRNP0249AWZZ J BH Power
! PT802 RTRNP0239AWZZ J AP Power
T302 RCILA1064AFZZ J AD AM Tracking
T306 RCILB1074AFZZ J AC AM,OSC
T351 RCILI0011AWZZ J AD AM IF
COILS
L99 VP-DH2R2K0000 J AB 2.2 mmH,Peaking
L101 VP-XH2R2K0000 J AB 2.2 µH,Choke
L102 VP-XH2R2K0000 J AB 2.2 µH,Choke
L104 VP-MK331K0000 J AB 330 µH,Choke
L341 RBLN-0001AWZZ J AD Balun
L342 VP-DH2R2K0000 J AB 2.2 mmH,Peaking
L351 VP-DH101K0000 J AB 100 µH,Choke
L352 VP-DH101K0000 J AB 100 µH,Choke
L353 VP-DH102K0000 J AB 1 mH,Choke
L354 RFILL0001AWZZ J AE Low Pass Filter
L601 VP-DH101K0000 J AB 100 µH,Choke
L702 VP-DH101K0000 J AB 100 µH,Choke
