Sharp CD-PC671H

PRICE
RANK
DESCRIPTIONNO.
PARTS CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-PC671H/651H
! F832 92LFUSE-T501E J AD Fuse,T500mA L 250V
! F901,902 92LFUSET312E J AD Fuse,T3.15A L 250V
! F903 92LFUSET312E J AD Fuse,T3.15A L 250V
[PC671H Only]
FE301 RTUNS0012AWZZ J AV FM Front End
FFC701 QCNWN1461AWZZ J AG Flat Cable,25Pin
FL701 VVKBJ685GNK-1 J AV FL Display
FW601 QCNWN1477AWZZ J AD Flat Cable,5Pin
FW701 QCNWN1092AWZZ J AE Flat Cable,6Pin
FWM1 QCNWN1274AWZZ J AC Flat Cable,2Pin
FWM2 QCNWN0338AWZZ J AD Flat Cable,2Pin
IC99 VHPGP1F32T/-1 J AP Optical Fiber Data
Link,GP1F32T
JK401 QSOCJ0405AWZZ J AH Jack,Video In
JK601 QJAKM0004AWZZ J AK Jack,Headphones
M1 92LMTR1858CASY J AS Motor with Chassis [Spindle]
M2 92LMTR1854BASY J AP Motor with Gear [Sled]
M3 RMOTV0373AFZZ J AL Motor with Worm Pulley
[T/T Up/Down Loading]
M901 92LMTR1810A J AK Motor,Air Cooling Fan
MM1(260-7) RMOTV0006AWM1 J AR Motor with Pulley [Tape]
PHM1 VHPI31535CD-1 J AG Photo Interrupter
RL801 RRLYD0011AWZZ J AE Relay
RL901,902 RRLYD0004AWZZ J AP Relay
RX701 VHLN63H380A-1 J AK Remote Sensor,N63H380A
SO301 QTANC0101AWZZ J AF Terminal,Antenna
SO901 QTANA1001AWZZ J AC Terminal,Speaker [PC651H]
SO901 QTANA1201AWZZ J AM Terminal,Speaker [PC671H]
SOLM1(260-8) RPLU-0002AWZZ J AH Solenoid Ass’y [Tape]
SOLM2 RPLU-0002AWZZ J AH Solenoid Ass’y [CD]
SW1 QSW-P0004AWZZ J AE Switch,Push Type [Open/Close]
SW2 QSW-F0001AWZZ J AD Switch,Leaf/Skeleton Type
[Mecha Up]
SW3 QSW-P0005AWZZ J AD Switch,Push Type [Disc Number]
SW4 QSW-F9001AW01 J AD Switch,Leaf Type [Pickup In]
SW701 92LSWICH1401AT J AC Switch,Key Type [ON/Stand-by]
SW702 92LSWICH1401A J AD Switch,Key Type [STATION]
SW703 92LSWICH1401AT J AC Switch,Key Type [CLOCK]
SW704 92LSWICH1401AT J AC Switch,Key Type
[TIMER/SLEEP]
SW705 92LSWICH1401AT J AC Switch,Key Type [DISC 1]
SW706 92LSWICH1401AT J AC Switch,Key Type [DISC 2]
SW707 92LSWICH1401AT J AC Switch,Key Type [DISC 3]
SW708 92LSWICH1401AT J AC Switch,Key Type [DISC SKIP]
SW709 92LSWICH1401AT J AC Switch,Key Type
[OPEN/CLOSE]
SW710 92LSWICH1401AT J AC Switch,Key Type [REW]
SW711 92LSWICH1401AT J AC Switch,Key Type [REC PAUSE]
SW712 92LSWICH1401AT J AC Switch,Key Type
[MEMORY/SET]
SW713 92LSWICH1401AT J AC Switch,Key Type [STOP]
SW714 92LSWICH1401AT J AC Switch,Key Type
[TUNER/BAND]
SW715 92LSWICH1401AT J AC Switch,Key Type [VIDEO]
SW716 92LSWICH1401AT J AC Switch,Key Type [TAPE]
SW717 92LSWICH1401AT J AC Switch,Key Type [CD]
SW718 92LSWICH1401A J AD Switch,Key Type
[PTY/TI SEARCH]
SW719 92LSWICH1401A J AD Switch,Key Type [EON]
SW720 92LSWICH1401A J AD Switch,Key Type [ASPM]
SW721 92LSWICH1401A J AD Switch,Key Type
[DISPLAY/MODE]
SW722 92LSWICH1401AT J AC Switch,Key Type [FF]
SW723 92LSWICH1401AT J AC Switch,Key Type [TUNING UP]
SW724 92LSWICH1401AT J AC Switch,Key Type
[TUNING DOWN]
SW725 92LSWICH1401AT J AC Switch,Key Type [PLAY]
SW726 92LSWICH1401A J AD Switch,Key Type
[VOLUME DOWN]
[PC651H Only]
SW727 92LSWICH1401A J AD Switch,Key Type [VOLUME UP]
[PC651H Only]
SW728 92LSWICH1401AT J AC Switch,Key Type
[X-BASS/DEMO]
SW729 92LSWICH1401AT J AC Switch,Key Type [EQUALIZER]
SW730 92LSWICH1401AT J AC Switch,Key Type [DIMMER]
SW731 92LSWICH1401AT J AC Switch,Key Type [PHANTOM]
SW732 92LSWICH1401AT J AC Switch,Key Type [NORMAL]
SW733 92LSWICH1401AT J AC Switch,Key Type [BYPASS]
SWM3(260-9) 92LM-SW1676A J AC Switch,Leaf Type [Fool Proof]
SWM4(260-10) QSW-F9003AWZZ J AG Switch,Leaf Type [F.A.S.]
SWM5(260-11) 92LM-SW1658A J AB Switch,Leaf Type [CAM]
VR702 QSW-Z0005AWZZ J AM Switch,Push Type [Volume Jog]
[PC671H Only]
CD MECHANISM PARTS
301 NGERH0011AWZZ J AC Gear,Middle
302 NGERH0012AWZZ J AC Gear,Drive
303 MLEVP0010AWZZ J AC Rail,Guide
304 NSFTM0002AWFW J AE Shaft,Guide
305 92LM-CUSN1524A J AC Cushion
! 306 92LHPC1MASY J BG Pickup Unit Ass’y
306- 1 ———— — Pickup Unit
(Not Replacement Item)
306- 2 NGERR0043AFZZ J AC Gear,Rack
306- 3 MSPRC0961AFZZ J AA Spring,Rack
701 XBSSD26P06000 J AA Screw,ø2.6×6mm
702 XHBSD20P05000 J AA Screw,ø2×5mm
703 XBBSD20P03000 J AA Screw,ø2×3mm
704 LX-WZ1070AFZZ J AA Washer,ø1.5×ø3.8×0.25mm
M1 92LMTR1858CASY J AS Motor with Chassis [Spindle]
M2 92LMTR1854BASY J AP Motor with Gear [Sled]
SW4 QSW-F9001AW01 J AD Switch,Leaf Type [Pickup In]
CABINET PARTS
201 GCAB-1044AWSA J AM CD Player Base
202 92LCAB0355AS1 J Front Panel Ass’y [PC671H]
202 92LCAB3057AS1 J BB Front Panel Ass’y [PC651H]
202- 1 ———— — Front Panel
(Not Replacement Item)
202- 2 JKNBZ0557AWSA J AE Button,Disc No.
202- 3 JKNBZ0558AWSA J AE Button,Open/Close/Disc Skip
202- 4 JKNBZ0628AWSA J AE Button,ON/Stand-by
202- 5 JKNBZ0560AWSA J AE Button,X-BASS/Demo
202- 6 JKNBZ0563AWSA J AG Button,FF/REW/Tuning
202- 7 JKNBZ0565AWSA J AD Button,Timer/Sleep/Clock
202- 8 JKNBZ0570AWSA J AD Button,Dimmer/Equalizer
202- 9 JKNBZ0601AWSA J AE Button,Dolby Pro Logic
202-10 JKNBZ0561AWSA J AF Button,Function [PC651H]
202-10 KNOB3051AASY1 J AK Button,Function [PC671H]
202-11 HDECQ0412AWSA J AC Operation Ring A
202-12 HDECQ0413AWSA J AF Operation Ring B
202-13 HDECQ0414AWSA J AD Cap,Operation Center
202-14 HDECQ0415AWSA J AD Cover,LED
202-15 HDECQ0417AWSA J AE Panel,Center Cap
202-16 HDECQ0418AWSA J AH Panel,Decoration
202-17 HDECQ0419AWSA J AF Decoration,Play Button
202-18 HDECQ0420AWSA J AE Decoration,Stop Button
202-19 HDECQ0478AWSA J AG Panel,AMP.
202-20 HDECQ0457AWSA J AC Panel,Play Decoration
202-21 HDECQ0458AWSA J AC Panel,Stop Decoration
202-22 MLIFP0006AWZZ J AE Damper,Cassette Holder
202-23 PSHEP0031AWZZ J AC Sheet,Reflector [PC671H Only]
202-24 JKNBZ0567AWSA J AF Button,Volume [PC651H Only]
202-25 HDECQ0411AWSA J AE Volume Ring
202-26 JKNBZ0614AWSA J AE Button,RDS Operation
203 92LMEC3022CTS1 J AM Cassette,Holder Ass’y,Tape 1
[PC651H]
203 92LMEC3051CTS1 J AN Cassette,Holder Ass’y,Tape 1
[PC671H]
203- 1 ———— — Cassette Holder,Tape 1
(Not Replacement Item)
203- 2 GCOVA1221AWSA J AH Cassette Cover,Tape 1
[PC651H]
203- 2 GCOVA1221AWSB J AH Cassette Cover,Tape 1
[PC671H]
203- 3 HDECQ0408AWSA J AD Panel,Cassette,Tape 1
204 92LMEC3022CTS2 J AM Cassette,Holder Ass’y,Tape 1
[PC651H]
204 92LMEC3051CTS2 J AN Cassette,Holder Ass’y,Tape 2
[PC671H]
204- 1 ———— — Cassette Holder,Tape 2
(Not Replacement Item)
204- 2 GCOVA1222AWSA J AH Cassette Cover,Tape 2
[PC651H]
204- 2 GCOVA1222AWSB J AH Cassette Cover,Tape 2
[PC671H]
204- 3 HDECQ0409AWSA J AD Panel,Cassette,Tape 2
205 KNOB3051BASY1 J AG Button,Volume Ass’y
[PC671H Only]
205- 1 ———— — Button,Volume [PC671H Only]
(Not Replacement Item)
– 7 –
