4-3
CV10CTX
8.Remove propeller cover
propeller cover
9.Remove supporting board1
supporting board1
10.Remove connection pipe
welding joint
11.Remove evaporator assy
evaporator
Steps
Procedure
Remove the screws fixing propeller cover, to
remove the propeller cover.
Remove the screw fixing supporting board to
remove the board1.
Welding cut the joints on the connection pipe, to
remove the connection pipe. (Discharge the
refrigerant clearly before welding cutting.)
Remove the screws fixing evaporator assy, to
remove the evaporator assy.
