Sharp CV-P09LX User Manual

CVP09LX
5
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[2] CV-P09LX (Inside parts)
1-8 CCHS-A914JBKZ AZ Base pan ass'y
1-9 DCHS-A536JBTA BB Base pan ass'y
1-10 NKOM-A001JBEZ AG Caster
1-11 PGUM-A164JBEZ AE Motor cushion
1-12 PGUM-A165JBEZ AE Motor cushion B
1-13 PGUM-A166JBEZ AE Motor cushion C
1-14 CGUM-A001JBKZ Drain plug
1-15 PSEL-C875JBEZ AC Insulator
1-16 PSRA-A172JBFA AX Drain tray
1-17 CKES-A162JB KZ AT Orifice ass'y
1-18 MJNT-A023JBFA AF Louver link
1-19 MLOV-A409JBFA AF Vertical louver A
1-20 MLOV-A410JBFA AF Vertical louver B
1-21 PFPFPC765JBEZ AE Evaporator insulator
1-22 PFPFPC826JBEZ AC Orifice insulator A
1-23 PFPFPC827JBEZ AC Orifice insulator B
1-24 PFPFPC828JBEZ AC Orifice insulator C
1-25 PFPFPC829JBEZ AC Orifice insulator D
1-26 PKESSA090JBFA AX Orifice
1-27 CPMP-A00 5JBKZ AN Drain pump ass'y
1-28 LBND-A042JBE0 AC Wire fixing band
1-29 LBNDKA132JBEZ AE Band
1-34 PHOS-A045JBEZ AM Drain hose A
1-44 CVLV-A755JBKZ BE Drain valve ass'y
1-45 LANG-A615JBWZ AK Stay angle L
1-46 PCOV-B297JBEZ AK Cover F
1-48 LPL T MA210JBWZ AQ Bulkhead R
1-50 PCOV-B298JBEZ AK Cover R
1-51 LPL T MA211JBWZ AQ Bulkhead L
1-52 PCOV-B299JBEZ AN Cover
1-53 LPL T MA207JBWZ AL Half plate
1-54 PCOV-B300JBEZ AN Cover T
1-82 DANG-A049JBKZ AZ Stay angle L ass'y
1-85 DPLT -A074JBKZ AV
Bulkhead R ass'y
1-86 DPLT -A075JBKZ AX Bulkhead L ass'y
1-87 DPLT -A076JBKZ A Z Half plate ass'y
1-88 CMOT-A439JBKZ BL Fan motor sub ass'y
1-89 NFANSA045JBFZ AX Centrifugal fan-OUT
1-90 LANG-A617JBWZ AL Motor cover
1-91 LHLDW0364JBE0 AA Wire holder
1-92 LHLDW0370JBE0 AA Wire holder
1-97 PKESSA092JBFA AX Out casing A
1-98 PKESSA093JBFA AX Out casing B
1-99 PKESSA094JBFA AX Out casing C
1-100 CMOT-A440JBKZ BG Fan motor sub ass'y
1-101 NFANSA049JBFZ AV Centrifugal fan-IN
1-102 LANG-A606 JBFZ AM Fan motor angle
1-103 LANG-A614 JBPZ AK Casing cover
1-104 LANG-A618 JBPZ AK Motor cover IN
1-106 PKESSA091JBFZ AX In casing
1-107 DSW-MA003JBKZ AS Float switch ass'y
1-108 CFLO-A00 1JBKZ AK Float ass'y
1-111 LHLD-A739JBFA AZ SW stay
1-112 PCOV-B112JBFZ AF SW cover
1-113 PFLO-A006JBFZ AE Float C
1-114 QSW-MA009JBZZ AL Micro switch
1-117 LANG-A613 JBWZ AR Stay angle R
1-121 LHLDWA04 2JBEZ AE Wire holder
1-122 LHLDW0366JBE0 AA Wire holder
1-123 LHLDW0368JBE0 AA Wire holder
2-18 PCOV-B105JBFZ AG LED guide
2-19 DPWBFA395JBKZ AS D-F-S board unit
2-21 PSHE-A230JBEZ AF Sheet
6-2 LX-BZA360JBEZ AF Special screw
6-3 LX-NZA316JBEZ AF Special nut
6-5 LX-WZA048JBEZ AD Washer
6-8 XCTS740P10000 AC Tapping screw
6-9
XHTS740P08000 AC Tap tight screw
6-15 XTPS723P14000 AC Tapping screw
6-17 XTPS740P12000 AC Tapping screw
6-19 XTTS740P12 000 AC Tapping screw
6-20 XTTS740P14 000 AC Tapping screw
6-21 XTTS740P16 000 AC Tapping screw
6-23 XWSS700-25000 AC Spring washer
6-24 XTTS740P10 000 AC Tapping screw
