CONTROL PANEL DISPLAY & OPERATING INSTRUCTIONS
CONTROL PANEL & DISPLAY
OPERATING INSTRUCTIONS
Whenpressingkey,buzzermakesasound,indicatorlampshowsrelevant
state for 2 seconds.
1. ON/OFF Button
Press the button once to manually turn the unit on. Press once more to turn the unit off.
2. "+" , "-" Button
InCOOLmode,press"-"once,thesettemperaturewilldecrease1ºC(F),press"+"once,
thesettemperaturewillincrease1ºC(F).Thesettemperaturerangefrom16ºCto30ºC(61º
Fto86ºF).
3. MODEButton
PressMODEButtonrepeatedlytocyclebetweenthemodes:Cooling,Dry(Dehumidica-
tion),andFanonlymode.EachpressoftheMODEbuttonwilllightupadifferentlamponthe
control panel. The exhaust hose and window kit must be installed when the unit is in Cool or
Dehumidicationmode.Whenusingtheunitasafan,itisunnecessarytokeeptheexhaust
hose and window kit connected to the unit.
4. Fan Speed Button
WhentheunitisrunninginCoolorFanmode,presstheFanSpeedButtontoselectthefan
speed in High, Middle, Low, Auto.
5. Water Full
WhenCOOLorDRY(Dehumidication)isrunning,condensationwilldraintothewatertank.
Whenwatertankisfull.buzzerwillsound8times,andLEDscreenwillshowerrorcode‘H8’.
In this case, drain out water tank.
6. Louver Direction
Thisunithas4-Waydirectionallouvers.Usethe
louver guides to direct air where cooling or fanning is
neededmost.Holdthelouverandadjusttheairow
direction, as show in the right diagram.
Hold this hand grip to adjust the
direction of Horizontal Louvers
Hold this hand grip to adjust the
direction of Vertical Louvers
Receiver windowLED window
DRY
mode lamp
Temperature selection button COOL mode lamp
MODE button
FAN mode lampFAN Speed lamp ON/OFF button
Fan speed button
