116
DV-NC65H/S
DV-NC70H
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
FB3505
RBLN-0077TAZZY V Balun, BLN-0077TA AB
FB3507
RBLN-0077TAZZY V Balun, BLN-0077TA AB
FB3508
RBLN-0077TAZZY V Balun, BLN-0077TA AB
FB3509
RBLN-0077TAZZY V Balun, BLN-0077TA AB
FB3510
RBLN-0077TAZZY V Balun, BLN-0077TA AB
FB3511
RBLN-0077TAZZY V Balun, BLN-0077TA AB
FB3512
RBLN-0077TAZZY V Balun, BLN-0077TA AB
FB3513
RBLN-0077TAZZY V Balun, BLN-0077TA AB
FB3514
RBLN-0077TAZZY V Balun, BLN-0077TA AB
FB3515
RBLN-0077TAZZY V Balun, BLN-0077TA AB
FB3516
RBLN-0077TAZZY V Balun, BLN-0077TA AB
FB3517
RBLN-0077TAZZY V Balun, BLN-0077TA AB
FB3518
RBLN-0077TAZZY V Balun, BLN-0077TA AB
FB3520
RBLN-0077TAZZY V Balun, BLN-0077TA AB
FB3521
RBLN-0077TAZZY V Balun, BLN-0077TA AB
FB3522
RBLN-0077TAZZY V Balun, BLN-0077TA AB
FB3523
RBLN-0077TAZZY V Balun, BLN-0077TA AB
FB3524
RBLN-0077TAZZY V Balun, BLN-0077TA AB
FB3601
RBLN-0061TAZZY V Balun, BLN-0061TA AD
FB3602
RBLN-0061TAZZY V Balun, BLN-0061TA AD
FB3603
RBLN-0061TAZZY V Balun, BLN-0061TA AD
FB3604
RBLN-0061TAZZY V Balun, BLN-0061TA AD
FB3701
RBLN-0061TAZZY V Balun, BLN-0061TA AD
FB3702
RBLN-0061TAZZY V Balun, BLN-0061TA AD
FB3703
RBLN-0061TAZZY V Balun, BLN-0061TA AD
FB3801
RBLN-0061TAZZY V Balun, BLN-0061TA AD
FB3802
RBLN-0061TAZZY V Balun, BLN-0061TA AD
R3639 RBLN-0061TAZZY V Balun, BLN-0061TA AD
R3642 RBLN-0061TAZZY V Balun, BLN-0061TA AD
R3805 RBLN-0061TAZZY V Balun, BLN-0061TA AD
R3806 RBLN-0061TAZZY V Balun, BLN-0061TA AD
R3809 RBLN-0061TAZZY V Balun, BLN-0061TA AD
R3810 RBLN-0061TAZZY V Balun, BLN-0061TA AD
R3813 RBLN-0061TAZZY V Balun, BLN-0061TA AD
MISCELLANEOUS PARTS
CN3201
QPLGN0964TAZZY V Plug, 9Pin AF
CN3202
QSOCN1136TAZZY V Socket, 11Pin AE
CN3301
QSOCN2336TAZZY V Socket, 23Pin AF
CN3501
QSOCN2936TAZZY V Socket, 29Pin AF
CN3701
QPLGN0664TAZZY V Plug, 6Pin AD
CN3702
QPLGN0564TAZZY V Plug, 5Pin AC
DUNTKB210TEV4(NC70H)
DUNTKB210TEV5(NC65H)
DUNTKB210TEV7(NC65S)
VCR MAIN PWB UNIT
TUNER
TU101 VTUATMDB2-633 V
VHF Tuner(NC65H/NC70H)
BD
TU101 VTUATMDG2-836 V
VHF Tuner(NC65S)
BE
INTEGRATED CIRCUITS
IC201 VHiHA8617F/-1 V HA8617F, AX
Y/C Audio Processor
IC601 VHiTC4S66F/-1Y V TC4S66F AD
IC651 VHiAN3651FB-1 V AN3651FB, AU
Hifi Audio Processor
IC701 RH-iXA213WJZZQ V IXA213WJ
IC703 VHiPST3225N1EY V PST3225N AD
IC710 VHiBR2416E2-1Y V BR2416E2, E
2
PROM AK
IC801 RH-iX1539CEZZY V IX1539CE AE
IC2002 VHiMM1501XN-1Y V
MM1501XN, Dub Video SW
AE
IC2003 VHiMM1508XN-1Y V MM1508XN, Comp. Driver AE
IC6004 VHiNJM4565M-1Y V NJM4565M, Audio Amp AE
TRANSISTORS
Q201 VS2PD601AR/-1Y V 2PD601AR AB
Q251 VS2PB709AR/-1Y V 2PB709AR AB
Q303 VS2PD601AR/-1Y V 2PD601AR AB
Q401 VSKRC102S//-1Y V KRC102S AA
Q402 VS2SK1826++-1Y V 2SK1826++ AC
Q403 VSKRC102S//-1Y V KRC102S AA
Q501 VS2PD601AR/-1Y V 2PD601AR AB
Q502 VSKRA102S//-1Y V KRA102S AA
Q503 VSKRC102S//-1Y V KRC102S AA
Q602 VS2SC3203Y/-1+ V 2SC3203Y AC
Q603 VS2PD601AR/-1Y V 2PD601AR AB
Q604 VSKRA103S//-1Y V KRA103S AA
Q605 VS2PD601AR/-1Y V 2PD601AR AB
Q606 VS2PD601AR/-1Y V 2PD601AR AB
Q613 VS2PD601AR/-1Y V 2PD601AR AB
Q651 VS2PD601AR/-1Y V 2PD601AR AB
Q652 VS2PD601AR/-1Y V 2PD601AR AB
Q658 VSKRA104S//-1Y V KRA104S AA
Q659 VSKRA104S//-1Y V KRA104S AA
Q660 VSKRC104S//-1Y V KRC104S AA
Q704 VS2PB709AR/-1Y V 2PB709AR AB
Q705 VS2PD601AR/-1Y V 2PD601AR AB
Q706 VS2PB709AR/-1Y V 2PB709AR AB
Q710 VS2PD601AR/-1Y V 2PD601AR AB
Q711 VS2PD601AR/-1Y V 2PD601AR AB
Q712 VSKRC102S//-1Y V KRC102S AA
Q850 VS2PD601AR/-1Y V 2PD601AR AB
Q851 VSKRC102S//-1Y V KRC102S AA
Q852 VSKRC102S//-1Y V KRC102S AA
Q853 VSKRA103S//-1Y V KRA103S AA
Q854 VSKRA103S//-1Y V KRA103S AA
Q859 VS2PB709AR/-1Y V 2PB709AR AB
Q860 VSKRC102S//-1Y V KRC102S AA
Q861 VS2PD601AR/-1Y V
2PD601AR, LCD Back Light
AB
Q1901 VS2SC3852A/-1 V 2SC3852A, M_27V AH
Q1904 VSKRC102S//-1Y V KRC102S AA
Q1905 VS2SA1271-Y-1+ V
2SA1271-Y, PC_5V(3) SW
AC
Q1907 VS2SA1271-Y-1+ V
2SA1271-Y, PC_5V(3) SW
AC
Q1908 VS2SA1271-Y-1+ V
2SA1271-Y, PC_5V(2) SW
AC
Q1910 VSKRC102S//-1Y V KRC102S AA
Q1911 VSKRC102S//-1Y V KRC102S AA
Q1912 VSKRC103S//-1Y V KRC103S AA
Q1913 VSKRC102S//-1Y V KRC102S AA
Q1914 VS2SB1443TV1E+ V 2SB1443TV, PC_13V SW AE
Q1915 VS2SA1015Y/1E+ V 2SA1015Y, PC_40V SW AB
Q1916 VSKRC103S//-1Y V KRC103S AA
Q1918 VS2SC3203Y/-1+ V 2SC3203Y AC
Q6003 VSKRC104S//-1Y V KRC104S AA
Q6004 VSKRA103S//-1Y V KRA103S AA
Q6005 VSKRC104S//-1Y V KRC104S AA
Q6006 VSKRA103S//-1Y V KRA103S AA
Q6007 VS2SD1306-E-1Y V 2SD1306-E AC
Q6008 VS2SD1306-E-1Y V 2SD1306-E AC
Q6009 VSKRC104S//-1Y V KRC104S AA
Q6010 VSKRC104S//-1Y V KRC104S AA
Q6101 VS2PD601AR/-1Y V 2PD601AR AB
Q6102 VS2PD601AR/-1Y V 2PD601AR AB
DIODES AND LED’S
D101 RH-EX0627GEZZY V Zener AA
D102 RH-EX0627GEZZY V Zener AA
D351 VHD1SS119//-1Y V 1SS119 AA
D691 VHD1SS119//-1Y V 1SS119 AA
D692 VHD1SS119//-1Y V 1SS119 AA
D701 RH-PX0270GEZZ+ V PhotoDiode, Cassette LED AC
D702 VHD1SS119//-1Y V 1SS119 AA
D706 RH-PX0252GEZZ V PX0252GE, AF
Supply Reel Sensor
D707 RH-PX0252GEZZ V PX0252GE, AF
Takeup Reel Sensor
D710 VHD1SS119//-1Y V 1SS119 AA
D712 VHD1SS119//-1Y V 1SS119 AA
D721 VHD1SS119//-1Y V 1SS119 AA
D731 VHD1SS119//-1Y V 1SS119 AA
D801 VHD1SS119//-1Y V 1SS119 AA
D823 RH-EX0634GEZZY V Zener AB
D1901 RH-EX0670GEZZY V Zener AB
D1902 VHD1SS119//-1Y V 1SS119 AA
DUNTKB209TE6H
DVD MAIN PWB UNIT(Continued)
To Next Page
