1-8-3
E5753PL
R1029 CARBON RES. 1/4W J 470k Ω 9HSCX4JATZ0474 ---
R1034 PCB JUMPER D0.6-P5.0 9HSJW5.0T ---
R1072 CHIP RES.(1608) 1/10W J 1k Ω 9HSRXAJR5Z0102 ---
R1074 RECTIFIER DIODE 1N4005 9HSDQZ001N4005 ---
R1096 METAL OXIDE FILM RES. 2W J 150k Ω 9HSN02154ZU001 ---
R1096 METAL OXIDE FILM RES. 2W J 150k Ω 9HSN02154KE010 ---
R1097 Not used
R1098 Not used
R1256 Not used
R1257 Not used
R1371 CHIP RES.(1608) 1/10W 0 Ω 9HSRXAZR5Z0000 ---
R1405 Not used
R1443 CHIP RES.(1608) 1/10W J 75 Ω 9HSRXAJR5Z0750 ---
R1462 CHIP RES.(1608) 1/10W J 75 Ω 9HSRXAJR5Z0750 ---
R1463 Not used
R1482 CHIP RES.(1608) 1/10W J 75 Ω 9HSRXAJR5Z0750 ---
R1483 Not used
R1491 Not used
R1492 Not used
R1522 Not used
R1523 CHIP BEAD MMZ1608Y121CT 9HSL06001TE004 ---
R1524 CHIP INDUCTOR BK1608HS121-T 9HSLC121NTU017 ---
R1525 CHIP INDUCTOR BK1608HS121-T 9HSLC121NTU017 ---
R1526 Not used
R1530 Not used
R1531 Not used
R1558 Not used
R1613 CHIP RES.(1608) 1/10W J 2.2k Ω 9HSRXAJR5Z0222 ---
R1614 Not used
T1001! POWER TRANSFORMER CSA-SW0308A 9HSTT00ZPSA144 AH
W1601 16P FFC 9HSX1E57S0-001 AF
W2101 Not used
FUNCTION CBA 9HS0VSA14186B ---
SW2007 PCB JUMPER D0.6-P6.5 9HSJW6.5T ---
Mechanical Parts
2B23 SHEET, INSULATOR E57S7RD 9HS0VM415311 AE
A17 REAR PANEL E5754HD 9HS0VM204230 AK
A21! LABEL, RATING E5755PD ---------- ---
A22 LABEL, BAR CODE E5755PD ---------- ---
A30 CASE MARK LABEL E5755PD ---------- ---
S1 GIFT BOX CARTON E5755PD 9HS0VM306333 AM
S2 STYROFOAM E57S0UD 9HS0VM101231 AE
X5 AV CORD 9HSX1E56B5-001 AL
X10! OWNER'S MANUAL E5754HD 9HS0VMN03662 AG
X17 Not used
Electrical Parts
DVD MAIN CBA UNIT 9HSN79SFGHP
CN601 FFC/FPC CONNECTOR, 16P 04 6232 116 103 800 9HSC62D16TM003 AE
CN601 FFC/FPC CONNECTOR, 16P 10008HR-16 9HSCHRD16YEE02 ---
IC102 IC(SDRM) P2V64S50DTP-75 9HSSZBA0R0M002 AZ
IC102 IC(SDRM) 2X32Y3VTW-6 9HSSZBA0R3S001 AX
L616 CHIP BEAD MMZ1608Y121CT 9HSL06001TE004 ---
R608 Not Used
AV CBA ASSEMBLY 9HS0VSA14189 BW
DV-SL10
Ref. No. Description Part No. Code
Ref. No. Description Part No. Code
