Sharp DV-SL10S - Page 36

1-8-5
E5753PL
Q1003 TRANSISTOR 2SC1815-BL(TPE2) 9HSQS202SC1815 ---
Q1050 Not used
Q1521 Not used
Q1522 Not used
R1005 CARBON RES. 1/4W J 2.7M Ω 9HSCX4JATZ0275 ---
R1006 CARBON RES. 1/4W J 2.7M Ω 9HSCX4JATZ0275 ---
R1008 CARBON RES. 1/4W J 910 Ω 9HSCX4JATZ0911 ---
R1011 METAL OXIDE FILM RES. 1W J 1.8 Ω 9HSN011R8ZU001 ---
R1011 METAL OXIDE FILM RES. 1W J 1.8 Ω 9HSN011R8KE009 ---
R1015 Not used
R1016 Not used
R1023 CHIP RES. 1/16W F 3.9k Ω 9HSRXGFR5Z0392 ---
R1023 CHIP RES.(1608) 1/10W F 3.9k Ω 9HSRXAFR5Z3901 ---
R1029 CARBON RES. 1/4W J 470k Ω 9HSCX4JATZ0474 ---
R1034 PCB JUMPER D0.6-P5.0 9HSJW5.0T ---
R1072 CHIP RES.(1608) 1/10W J 1k Ω 9HSRXAJR5Z0102 ---
R1074 RECTIFIER DIODE 1N4005 9HSDQZ001N4005 ---
R1096 METAL OXIDE FILM RES. 2W J 150k Ω 9HSN02154ZU001 ---
R1096 METAL OXIDE FILM RES. 2W J 150k Ω 9HSN02154KE010 ---
R1097 Not used
R1098 Not used
R1256 Not used
R1257 Not used
R1371 CHIP RES.(1608) 1/10W 0 Ω 9HSRXAZR5Z0000 ---
R1405 Not used
R1443 CHIP RES.(1608) 1/10W J 75 Ω 9HSRXAJR5Z0750 ---
R1462 CHIP RES.(1608) 1/10W J 75 Ω 9HSRXAJR5Z0750 ---
R1463 Not used
R1482 CHIP RES.(1608) 1/10W J 75 Ω 9HSRXAJR5Z0750 ---
R1483 Not used
R1491 Not used
R1492 Not used
R1522 Not used
R1523 CHIP BEAD MMZ1608Y121CT 9HSL06001TE004 ---
R1524 CHIP INDUCTOR BK1608HS121-T 9HSLC121NTU017 ---
R1525 CHIP INDUCTOR BK1608HS121-T 9HSLC121NTU017 ---
R1526 Not used
R1530 Not used
R1531 Not used
R1558 Not used
R1613 CHIP RES.(1608) 1/10W J 2.2k Ω 9HSRXAJR5Z0222 ---
R1614 Not used
T1001! POWER TRANSFORMER CSA-SW0308A 9HSTT00ZPSA144 AH
W1601 16P FFC 9HSX1E57S0-001 AF
W2101 Not used
FUNCTION CBA 9HS0VSA14186B ---
SW2007 PCB JUMPER D0.6-P6.5 9HSJW6.5T ---
Mechanical Parts
2B23 SHEET, INSULATOR E57S7RD 9HS0VM415311 AE
A17 REAR PANEL E5756AD 9HS0VM204231 AR
A21! LABEL, RATING E5756AD ---------- ---
A22 LABEL, BAR CODE E5756AD ---------- ---
A30 CASE MARK LABEL E5756AD ---------- ---
S1 GIFT BOX CARTON E5756AD 9HS0VM306334 AV
S2 STYROFOAM E5714BD 9HS0VM101289 AE
DV-SL10X
Ref. No. Description Part No. Code
Ref. No. Description Part No. Code
