Sharp Eco Inverter AH-XPC9RV - Part Names

2
1 Inlet (Air)
2 Open Panel
3 Air Filter
4 AUX Button
5 Receiver Window
6 Vertical Airflow Louvre
7 Horizontal Airflow Louvre
8 Outlet (Air)
9 PLASMACLUSTER Lamp
(blue)
10 OPERATION Lamp (red
)
11 TIMER Lamp (orange
)
12 POWERFUL JET Lamp
(green
)
NOTE:
Actual units might vary slightly
from those shown above.
1
2
3
4
5
6
7
8
9
10
11
12
PART NAMES
INDOOR UNIT
