Table
No.
File name
RECORD BLOCK
Label
size
Data
size
MRS Max. #1 MRS Max. #2
21 TEXT 4 99 (19) 1 1 0 8
22 Cashier transaction LABEL 41 41 4 99 (19) 2 0
23 DAILY 41 41 (22) 4 99 (19) 0 8
24 TERM 41 41 (22) 4 99 (19) 0 8
25 Reset Csr Transaction LABEL 41 41 1 1 2 0
26 DAILY 41 41 (25) 1 1 0 8
27 Total cashier (Buffer) LABEL 41 41 1 1 2 0
28 TOTAL 41 41 (27) 1 1 0 8
29 Clerk PRESET 0 99 0 1 1 3
30 FLAG 0 99 (29) 0 1 0 2
31 TEXT 0 99 (29) 0 1 0 8
32 Clerk transaction LABEL 0 11 0 99 (29) 2 0
33 DAILY 0 11 (32) 0 99 (29) 0 8
34 TERM 0 11 (32) 0 99 (29) 0 8
35 Reset CLK Transaction LABEL 0 11 0 1 2 0
36 DAILY 0 11 (35) 0 1 0 8
37 Total CLK (Buffer) LABEL 0 11 0 1 2 0
38 TOTAL 0 11 (37) 0 1 0 8
39 Hourly LABEL 48 48 1 1 1 0
40 DAILY 48 48 (39) 1 1 0 8
41 Daily net LABEL 32 32 1 1 3 0
42 TOTAL 32 32 (41) 1 1 0 8
43 Reg. buffer 80 255 1 1 0 38
44 Overlapped Cashier 0 255 (43) 0 99 (20) 0 38
[JOB#996, 998] RAM DATA BACKUP function
(ECR
↔ ECR, ECR↔ ER-02FD)
[JOB#996] RAM data send
X : SSP = 0
Standard RAM (64KB) = 1
Optional RAM: ER-03RA (512KB) = 2
[JOB#998] RAM data receive
996
X
All data
Send to ECR or ER-02FD
(Baud rate setting:#903-A)
Send to ECR
(Auto baud rate setting)
TL
ST
998
Receive from ECR or ER-02FD
(Baud rate setting:#903-A)
Receive from ECR
(Auto baud rate setting)
TL
ST
1 – 14
