Sharp GX-CD1200W BK User Manual

GX-CD1200W
– 16 –
A
B
C
D
E
F
G
H
1
2
34 5
6
Figure 16 WIRING SIDE OF P.W.BOARD (3/4)
C654
C653
D651
C652
C651
BATTERYS
DC15V
["D" SIZE (UM / SUM-1,
R20 or HP2) battery x 10]
TERMINAL A
PWB-A5
TERMINAL B
PWB-A6
POWER
PWB-A7
1
2
CNP601
CNS601
WH
WH
RD
RD
RD
BK
BL
SW601
VOLTAGE SELECTOR
AC220V-240V AC110V-127V
OR
OR
BK
SO601
AC SOCKET
AC110V-127V/
AC220V-240V,
50/60Hz
T601
POWER
TRANSFORMER
(250)
(237)
(251)
(251)
TO MAIN PWB
P14 1-D
F601
T4A L 250V
BR
COLOR TABLE
RD(R)
OR
YL
GR
BL
VL
GY
WH(W)
BK
PK
BROWN
RED
ORANGE
YELLOW
GREEN
BLUE
VIOLET
GRAY
WHITE
BLACK
PINK
BK
