NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
★
NO. PART CODE
PRICE
RANK
★
DESCRIPTION
GX-CD30/30C/130/130C
C801 VCTYMN1CY103N J AA 0.01 µF,16V
C802 RC-GZA476AF1A J AB 47 µF,10V,Electrolytic
C803 RC-GZA104AF1H J AB 0.1 µF,50V,Electrolytic
C804 VCKYMN1HB102K J AA 0.001 µF,50V
C805,806 VCTYPA1CX333K J AA 0.033 µF,16V
C807 RC-GZA104AF1H J AB 0.1 µF,50V,Electrolytic
C808 VCTYPA1CX683K J AA 0.068 µF,16V
C809 VCTYPA1CX473K J AA 0.047 µF,16V
C810 VCKYMN1HB181K J AA 180 pF,50V
C811 VCTYPA1CX104K J AB 0.1 µF,16V
C812 VCKYMN1HB331K J AA 330 pF,50V
C813 VCTYPA1CX104K J AB 0.1 µF,16V
C814 VCTYMN1CY103K J AA 0.01 µF,16V
C815 VCTYMN1CX472K J AA 0.0047 µF,16V
C816 VCKYMN1HB102K J AA 0.001 µF,50V
C817 RC-GZA474AF1H J AA 0.47 µF,50V,Electrolytic
C818 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C819 RC-GZA476AF1A J AB 47 µF,10V,Electrolytic
C820 VCTYMN1CX332K J AA 0.0033 µF,16V
C821 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C822 VCKYMN1HB221K J AA 220 pF,50V
C830 VCCSMN1HL2R2C J AB 2.2 pF,50V
C831 VCTYMN1CX272K J AA 0.0027 µF,16V
C832 VCCSMN1HL270J J AA 27 pF,50V
C833 VCKYMN1HB102K J AA 0.001 µF,50V
C834 VCTYPA1CX333K J AA 0.033 µF,16V
C835 RC-GZA104AF1H J AB 0.1 µF,50V,Electrolytic
C837 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C838 VCTYMN1CY103K J AA 0.01 µF,16V
C839 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C840 RC-GZA334AF1H J AA 0.33 µF,50V,Electrolytic
C841,842 VCTYPA1CX473K J AA 0.047 µF,16V
C843 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C844 RC-GZA337AF1A J AB 330 µF,10V,Electrolytic
C845 RC-GZA475AF1H J AB 4.7 µF,50V,Electrolytic
C846 RC-GZA337AF1A J AB 330 µF,10V,Electrolytic
C847 VCTYMN1CY103K J AA 0.01 µF,16V
C848 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C849 VCTYMN1EF223Z J AA 0.022 µF,25V
C850 VCTYPA1EF104Z J AA 0.1 µF,25V
C851 VCTYMN1EF223Z J AA 0.022 µF,25V
C867,868 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C869,870 VCTYMN1CX222K J AA 0.0022 µF,16V
C873 VCTYMN1CY103K J AA 0.01 µF,16V
C887 VCTYMN1EF223Z J AA 0.022 µF,25V
C889 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C890 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
RESISTORS
VRD-MN2BD000C J AA 0 ohm,Jumper,ø1.4×3.5mm,Ivory
R1 VRD-ST2EE100J J AA 10 ohm,1/4W
R2 VRD-MN2BD330J J AA 33 ohms,1/8W
R3 VRD-MN2BD470J J AA 47 ohms,1/8W
R5 VRD-ST2EE334J J AA 330 kohms,1/4W
R6 VRD-ST2EE824J J AA 820 kohms,1/4W
R7 VRD-ST2EE391J J AA 390 ohms,1/4W
R9 VRD-MN2BD223J J AA 22 kohms,1/8W
R25 VRD-ST2EE121J J AA 120 ohms,1/4W
R26 VRD-MN2BD392J J AA 3.9 kohms,1/8W
R27 VRD-MN2BD333J J AA 33 kohms,1/8W
R29 VRD-MN2BD153J J AA 15 kohms,1/8W
R30 VRD-MN2BD122J J AA 1.2 kohms,1/8W
R35 VRD-ST2EE182J J AA 1.8 kohms,1/4W
R201 VRD-ST2CD102J J AA 1 kohm,1/6W
R202ç204 VRD-MN2BD102J J AA 1 kohm,1/8W
R205 VRD-MN2BD151J J AA 150 ohms,1/8W
R206 VRD-ST2CD151J J AA 150 ohms,1/6W
R207,208 VRD-MN2BD103J J AA 10 kohm,1/8W
R211,212 VRD-MN2BD682J J AA 6.8 kohms,1/8W
R213,214 VRD-MN2BD272J J AA 2.7 kohms,1/8W
R219,220 VRD-MN2BD273J J AA 27 kohms,1/8W
R221,222 VRD-MN2BD822J J AA 8.2 kohms,1/8W
R223,224 VRD-MN2BD682J J AA 6.8 kohms,1/8W
R225,226 VRD-MN2BD561J J AA 560 ohms,1/8W
R227,228 VRD-MN2BD470J J AA 47 ohms,1/8W
R229,230 VRD-MN2BD103J J AA 10 kohm,1/8W
R231,232 VRD-ST2EE103J J AA 10 kohm,1/4W
R238 VRD-MN2BD684J J AA 680 kohms,1/8W
R241 VRD-MN2BD123J J AA 12 kohms,1/8W
R243 VRD-MN2BD563J J AA 56 kohms,1/8W
R250 VRD-ST2EE101J J AA 100 ohm,1/4W
R254 VRD-MN2BD223J J AA 22 kohms,1/8W
R262 VRD-MN2BD472J J AA 4.7 kohms,1/8W
R264 VRD-MN2BD104J J AA 100 kohm,1/8W
R265 VRD-MN2BD472J J AA 4.7 kohms,1/8W
R351 VRD-MN2BD473J J AA 47 kohms,1/8W
R352 VRD-MN2BD104J J AA 100 kohm,1/8W
R353 VRD-MN2BD220J J AA 22 ohms,1/8W
R354ç356 VRD-ST2EE470J J AA 47 ohms,1/4W
R401 VRD-ST2EE4R7J J AA 4.7 ohms,1/4W
R402 VRD-MN2BD561J J AA 560 ohms,1/8W
R403 VRD-ST2EE271J J AA 270 ohms,1/4W
R410 VRD-RT2HD1R5J J AB 1.5 ohms,1/2W
R433,434 VRD-ST2EE332J J AA 3.3 kohms,1/4W
R441,442 VRD-MN2BD222J J AA 2.2 kohms,1/8W
R455,456 VRD-MN2BD103J J AA 10 kohm,1/8W
R457,458 VRD-MN2BD102J J AA 1 kohm,1/8W
R461 VRD-ST2EE680J J AA 68 ohms,1/4W
R517,518 VRD-MN2BD223J J AA 22 kohms,1/8W [130/130C Only]
R561,562 VRD-ST2EE272J J AA 2.7 kohms,1/4W
R565,566 VRD-MN2BD272J J AA 2.7 kohms,1/8W
R570ç572 VRD-MN2BD102J J AA 1 kohm,1/8W
R573,574 VRD-MN2BD472J J AA 4.7 kohms,1/8W
R575 VRD-MN2BD104J J AA 100 kohm,1/8W
R576 VRD-MN2BD102J J AA 1 kohm,1/8W
R577,578 VRD-ST2EE121J J AA 120 ohms,1/4W
R579 VRD-MN2BD103J J AA 10 kohm,1/8W
R581,582 VRD-ST2EE3R3J J AA 3.3 ohms,1/4W
R601 VRD-ST2EE2R7J J AA 2.7 ohms,1/4W
R708,709 VRD-MN2BD102J J AA 1 kohm,1/8W
R710 VRD-MN2BD103J J AA 10 kohm,1/8W
R711 VRD-MN2BD272J J AA 2.7 kohms,1/8W
R712 VRD-MN2BD102J J AA 1 kohm,1/8W [130/130C Only]
R713 VRD-MN2BD102J J AA 1 kohm,1/8W
R714 VRD-MN2BD103J J AA 10 kohm,1/8W
R715 VRD-MN2BD153J J AA 15 kohms,1/8W
R716 VRD-MN2BD103J J AA 10 kohm,1/8W
R718ç720 VRD-ST2EE153J J AA 15 kohms,1/4W
R721 VRD-MN2BD153J J AA 15 kohms,1/8W
R722,723 VRD-ST2EE153J J AA 15 kohms,1/4W
R724 VRD-MN2BD153J J AA 15 kohms,1/8W
R725 VRD-ST2EE153J J AA 15 kohms,1/4W
R726ç735 VRD-MN2BD102J J AA 1 kohm,1/8W
R740 VRD-MN2BD472J J AA 4.7 kohms,1/8W
R741 VRD-MN2BD332J J AA 3.3 kohms,1/8W
R742 VRD-MN2BD102J J AA 1 kohm,1/8W
R743 VRD-MN2BD104J J AA 100 kohm,1/8W
R771 VRD-MN2BD392J J AA 3.9 kohms,1/8W
R772 VRD-MN2BD272J J AA 2.7 kohms,1/8W
R773 VRD-MN2BD182J J AA 1.8 kohms,1/8W
R774 VRD-MN2BD152J J AA 1.5 kohms,1/8W
R776 VRD-MN2BD103J J AA 10 kohm,1/8W
R779 VRD-MN2BD470J J AA 47 ohms,1/8W [130/130C Only]
R801 VRD-MN2BD102J J AA 1 kohm,1/8W
R802 VRD-MN2BD104J J AA 100 kohm,1/8W
R803 VRD-MN2BD153J J AA 15 kohms,1/8W
R804 VRD-MN2BD222J J AA 2.2 kohms,1/8W
R805 VRD-MN2BD682J J AA 6.8 kohms,1/8W
R806 VRD-MN2BD101J J AA 100 ohm,1/8W
R807 VRD-MN2BD102J J AA 1 kohm,1/8W
R808 VRD-MN2BD123J J AA 12 kohms,1/8W
R809 VRD-MN2BD273J J AA 27 kohms,1/8W
R810 VRD-MN2BD823J J AA 82 kohms,1/8W
R811 VRD-MN2BD332J J AA 3.3 kohms,1/8W
R812 VRD-MN2BD153J J AA 15 kohms,1/8W
R813 VRD-MN2BD333J J AA 33 kohms,1/8W
R814 VRD-MN2BD103J J AA 10 kohm,1/8W
R815 VRD-MN2BD473J J AA 47 kohms,1/8W
R816 VRD-MN2BD152J J AA 1.5 kohms,1/8W
R817 VRD-MN2BD823J J AA 82 kohms,1/8W
R819 VRD-MN2BD393J J AA 39 kohms,1/8W
R820 VRD-MN2BD103J J AA 10 kohm,1/8W
R821 VRD-MN2BD563J J AA 56 kohms,1/8W
R822 VRD-MN2BD682J J AA 6.8 kohms,1/8W
R823 VRD-MN2BD122J J AA 1.2 kohms,1/8W
R824 VRD-MN2BD103J J AA 10 kohm,1/8W
R825 VRD-MN2BD122J J AA 1.2 kohms,1/8W
R826,827 VRD-MN2BD224J J AA 220 kohms,1/8W
R828,829 VRD-ST2EE102J J AA 1 kohm,1/4W
R830 VRD-ST2EE102J J AA 1 kohm,1/4W
R831 VRD-MN2BD102J J AA 1 kohm,1/8W
R832 VRD-MN2BD563J J AA 56 kohms,1/8W
R833 VRD-MN2BD562J J AA 5.6 kohms,1/8W
– 2 –
