Sharp GX-CD30 User Manual

PRICE
RANK
DESCRIPTIONNO.
PART CODE
★
NO. PARTS CODE
PRICE
RANK
★
DESCRIPTION
GX-CD30/30C/130/130C
CAPACITORS
C2 VCKYMN1HB102K J AA 0.001 µF,50V
C4 VCCCPA1HH220J J AA 22 pF (CH),50V
C5 VCCCPA1HH330J J AA 33 pF (CH),50V
C6 VCCRPA1HH150J J AA 15 pF (RH),50V
C8 VCCCPA1HH4R0C J AA 4 pF (CH),50V
C9 VCTYPA1EX472M J AA 0.0047 µF,25V
C10 VCTYPA1EX223M J AA 0.022 µF,25V
C11 VCKYPA1HB221K J AA 220 pF,50V
C14 VCTYMN1EF223Z J AA 0.022 µF,25V
C15 VCTYPA1EX223M J AA 0.022 µF,25V
C16 VCTYPA1EX472M J AA 0.0047 µF,25V
C17 VCTYMN1EF223Z J AA 0.022 µF,25V
C20,21 VCTYMN1EF223Z J AA 0.022 µF,25V
C22 VCTYMN1CX222K J AA 0.0022 µF,16V
C23 VCTYPA1EX822M J AA 0.0082 µF,25V
C24 VCKYMN1HB471K J AA 470 pF,50V
C25 RC-GZA335AF1H J AB 3.3 µF,50V,Electrolytic
C26 RC-GZA226AF1C J AB 22 µF,16V,Electrolytic
C27 RC-GZA335AF1H J AB 3.3 µF,50V,Electrolytic
C28 92LCPU100V1500 J AC 0.0015 µF,100V,Polypropylene
C29 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C31,32 VCTYPA1EX223M J AA 0.022 µF,25V
C33ç35 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C36 VCTYPA1EX223M J AA 0.022 µF,25V
C37 RC-GZA227AF1A J AB 220 µF,10V,Electrolytic
C38,39 VCTYMN1EF223Z J AA 0.022 µF,25V
C201,202 VCKYMN1HB681K J AA 680 pF,50V
C203,204 VCKYMN1HB151K J AA 150 pF,50V
C205,206 VCKYMN1HB681K J AA 680 pF,50V
C207ç210 VCKYPA1HB331K J AA 330 pF,50V
C211,212 VCKYPA1HB151K J AA 150 pF,50V
C213,214 VCKYMN1HB151K J AA 150 pF,50V
C215,216 RC-GZA226AF1C J AB 22 µF,16V,Electrolytic
C217,218 VCTYPA1EX183J J AB 0.018 µF,25V
C219,220 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C227,228 VCKYPA1HB471K J AA 470 pF,50V
C229,230 VCKYPA1HB102K J AA 0.001 µF,50V
C231,232 VCKYMN1HB102K J AA 0.001 µF,50V
C233,234 RC-GZA226AF1C J AB 22 µF,16V,Electrolytic
C235,236 VCTYPA1CX473K J AA 0.047 µF,16V
C237,238 VCTYMN1CX332K J AA 0.0033 µF,16V
C239,240 RC-GZA225AF1H J AB 2.2 µF,50V,Electrolytic
C241 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C242 VCTYPA1EX823K J AB 0.082 µF,25V
C243 RC-GZA336AF1C J AB 33 µF,16V,Electrolytic
C244 RC-GZA226AF1C J AB 22 µF,16V,Electrolytic
C249 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C250 RC-GZA227AF1A J AB 220 µF,10V,Electrolytic
C351 VCKYMN1HB561K J AA 560 pF,50V
C353 VCQPKA2AA392J J AB 0.0039 µF,100V,Polypropylene
C354 RC-QZA273AFYJ J AB 0.027 µF,50V,Mylar
C356 RC-GZA476AF1A J AB 47 µF,10V,Electrolytic
C393 VCTYMN1EF223Z J AA 0.022 µF,25V
C401 VCTYMN1EF223Z J AA 0.022 µF,25V
C402 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C404 VCTYMN1CY103K J AA 0.01 µF,16V
C406 RC-GZA337AF1C J AC 330 µF,16V,Electrolytic
C407 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C509,510 VCTYPA1CX273K J AA 0.027 µF,16V
C561,562 VCTYPA1CX273K J AA 0.027 µF,16V [130/130C Only]
C565,566 RC-GZA104AF1H J AB 0.1 µF,50V,Electrolytic
C567,568 VCTYMN1CX272K J AA 0.0027 µF,16V
C569,570 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C571,572 VCKYMN1HB102K J AA 0.001 µF,50V
C573,574 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C575 RC-GZA227AF1E J AB 220 µF,25V,Electrolytic
C576 VCKZPA1HF223Z J AA 0.022 µF,50V
C577 92LCEU20W4700M J AH 4700µF,20V
C579,580 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C581,582 RC-QZA104AFYK J AB 0.1 µF,50V,Mylar
C583,584 RC-GZS108AF1A J AC 1000 µF,10V,Electrolytic
C586 RC-GZA474AF1H J AA 0.47 µF,50V,Electrolytic
C588 RC-GZA107AF1E J AB 100 µF,25V,Electrolytic
C589 RC-GZA225AF1H J AB 2.2 µF,50V,Electrolytic
C651ç654 VCKZPA1HF103Z J AA 0.01 µF,50V
C701,702 VCTYMN0JY223N J AA 0.022 µF,6.3V
C704 RC-EZY107AF1A J AB 100 µF,10V,Electrolytic
C705 VCTYMN0JY223N J AA 0.022 µF,6.3V
C740 VCTYMN1CY103K J AA 0.01 µF,16V
C741 RC-EZY335AF1H J AB 3.3 µF,50V,Electrolytic
INTEGRATED CIRCUITS
IC1 VHILA1186N/-1 J AE FM Front End,LA1186N
IC2 VHILA1805//-1 J AM FM/AM IF MPX.,LA1805
IC201 VHIANT345K/-1 J AM Playback and Record/ Playback
Amp.,LA7345K
IC501 VHILA4597//-1 J AH Power Amp.,LA4597
IC701 RH-IX0105AWZZ J BA System Microcomputer,
IX0105AW
IC801 VHILA9240M/-1 J AV Servo Amp.,LA9240M
IC802 VHILC78622E-1 J BA Servo/Signal Control,LC78622E
IC804 VHIBA5920FP-1 J AR Focus/Tracking/Spin/Slide
Driver,BA5920FP
TRANSISTORS
Q252 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q351 VS2SC2001-K-1 J AD Silicon,NPN,2SC2001 K
Q401 VS2SD468-C/-1 J AD Silicon,NPN,2SD468 C
Q403 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q404 VSKRA102M//-1 J AC Digital,PNP,KRA102 M
Q405 VS2SD2394F/-1 J AE Silicon,NPN,2SD2394 F
Q551,552 VSKTC3199GR-1 J AB Digital,NPN,KTC3199 GR
Q554 VSKRA102M//-1 J AC Digital,PNP,KRA102 M
Q740 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q804 VS2SD468-C/-1 J AD Silicon,NPN,2SD468 C
Q805 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
DIODES
D203 VHD1SS133//-1 J AA Silicon,1SS133
D251 VHD1SS133//-1 J AA Silicon,1SS133
D254 VHD1SS133//-1 J AA Silicon,1SS133
D401 VHERD8R2JB1-1 J AB Zener,8.2V,RD8.2JB1
D405,406 VHD1SS133//-1 J AA Silicon,1SS133
D501 VHD1SS133//-1 J AA Silicon,1SS133
D572ç575 VHD1SS133//-1 J AA Silicon,1SS133
îD651ç654 VHDRL104A//-1 J AB Silicon,RL104A
D740,741 VHD1SS133//-1 J AA Silicon,1SS133
D802 VHD1SS133//-1 J AA Silicon,1SS133
ZD801 VHEMTZJ5R6B-1 J AD Zener,5.6V,MTZJ5.6B
FILTERS
CF2 92LFILT-F1342A J AD FM IF
CF3 RFILA0006AWZZ J AG AM IF
F1 92LFILTF1759A J AD FM Band Pass Filter
TRANSFORMERS
T1 RCILI0007AWZZ J AD FM IF
T2 RCILI0008AWZZ J AF FM Detection
T3 RCILI0014AWZZ J AE AM IF
îT651 RTRNP0054AWZZ J AX Power
COILS
L1 RCILR0364AFZZ J AA FM RF
L2 RCILB0020AWZZ J AA FM Oscillation
L3 RCILA0053AWZZ J AK AM Bar Antenna
L4 RCILB0051AWZZ J AE AM Oscillation
L351 VP-MK331K0000 J AB 330 µH,Choke
L801 VP-XHR82K0000 J AC 0.82 µH,Choke
VARIABLE RESISTORS
VR1 92LVRS682NBUT J AC 6.8 kohms (B),Semi-VR [VCO]
VR531 92LVR-524A J AH 20 kohms (B),Semi-VR [Volume]
VR532 92LVR-524B J AG 50 kohms (A),Semi-VR [Tone]
VARIABLE CAPACITORS
VC1-4 92LVC-1455A J AN Variable Capacitor with Trimmer
(TC1-4)
VIBRATORS
X701 RCRM-0009AWZZ J AF Ceramic,4.000 MHz
XL801 RCRM-0008AWZZ J AF Ceramic,16.93 MHz
