Sharp HT-SB60 Quick Start Guide

TV
DVD, Blu-Ray disc
player or similar
To HDMI OUT (
TV ARC) Output terminal
Connecting a TV without Audio Return Channel
To audio output terminals
To optical digital
audio output
terminal
Audio cable
(commercially available)
Optical digital audio cable
(commercially available)
Connecting a TV with Audio Return Channel
HDMI Connection
Others Connection
Blu-Ray/DVD Player/Digital
tuner
Sound Bar
TV
DVD, Blu-Ray
disc player or
similar
To HDMI Output
terminal
Sound Bar
To HDMI OUT (
TV ARC) Output terminal
TV
or
To HEADPHONE
terminal
To OPTICAL IN
(optical) input
terminal
To HDMI Input terminal
To
HDMI input terminal
To AUDIO IN
input terminals
Sound Bar
To
HDMI (TV ARC) input terminal
Audio signal
To audio output terminal
To HEADPHONE
terminal
Caution: Turn off all other equipment before making this connection.
To HDMI Output
terminal
To HDMI Input terminal
Ferrite core
Note:
Make sure that the audio cable end
with ferrite core is connected to the
sound bar AUDIO IN terminal.
HT-SB60 ENUK QG.indd 2HT-SB60 ENUK QG.indd 2 9/11/2012 2:10:28 PM9/11/2012 2:10:28 PM

Sharp HT-SB60 Specifications

General

Audio decoders	Dolby Digital, DTS
RMS rated power	310 W
Audio output channels	2.1 channels
Soundbar speaker RMS power	160 W
Subwoofer included	Yes
Subwoofer connectivity	Wireless
Receiver included	No
Product color	Black
Apple docking compatibility	Not supported
HDMI ports quantity	3
USB 2.0 ports quantity	0
Connectivity technology	Wired & Wireless
Digital audio optical in	1
