Sharp JW Series User Manual

JW Series Computer Link SIO Driver
GP-Pro EX Device/PLC Connection Manual
73
Cable Diagram 8
Display
(Connection Port)
Cable Remarks
GP
*1
(COM1)
AGP-3302B (COM2)
*1 All GP models except AGP-3302B
A
COM port conversion adapter by Pro-face
CA3-ADPCOM-01
+
Terminal block conversion adapter by Pro-face
CA3-ADPTRM-01
+
Your own cable
Cable length:
1000m or less
B Your own cable
GP
*2
(COM2)
*2 All GP models except GP-3200 series and AGP-3302B
C
Online adapter by Pro-face
CA4-ADPONL-01
+
Terminal block conversion adapter by Pro-face
CA3-ADPTRM-01
+
Your own cable
D
Online adapter by Pro-face
CA4-ADPONL-01
+
Your own cable
IPC
*3
*3 Only the COM port which can communicate by RS-422/485 (2 wire) can be used.
) COM Port of IPC (page 6)
E
COM port conversion adapter by Pro-face
CA3-ADPCOM-01
+
Terminal block conversion adapter by Pro-face
CA3-ADPTRM-01
+
Your own cable
F Your own cable
