1 System Configuration
The system configuration in the case when the External Device of Sharp Manufacturing Systems Corporation and the
Display are connected is shown.
Series CPU Link I/F SIO Type
Setting
Example
Cable
Diagram
JW20H
JW-21CU JW-21CM
*1
RS422/485
(4wire)
Setting
Example 1
(page 9)
Cable
Diagram 1
(page 50)
RS422/485
(2wire)
Setting
Example 2
(page 11)
Cable
Diagram 2
(page 54)
JW-22CU
Communication
port on the CPU
unit
RS232C
Setting
Example 3
(page 13)
Cable Dia-
gram 3 (page
59)
RS422/485
(4wire)
Setting
Example 4
(page 15)
Cable Dia-
gram 4 (page
60)
JW-21CM
*1
RS422/485
(4wire)
Setting
Example 1
(page 9)
Cable
Diagram 1
(page 50)
RS422/485
(2wire)
Setting
Example 2
(page 11)
Cable
Diagram 2
(page 54)
JW30H
JW-31CUH1 JW-21CM
*1
RS422/485
(4wire)
Setting
Example 1
(page 9)
Cable Dia-
gram 1 (page
50)
RS422/485
(2wire)
Setting
Example 2
(page 11)
Cable
Diagram 2
(page 54)
JW-32CUH1
JW-32CUM1
JW-32CUM2
JW-33CUH1
JW-33CUH2
JW-33CUH3
PG/COMM1 on
the CPU unit
RS422/485
(4wire)
Setting
Example 5
(page 17)
Cable
Diagram 5
(page 64)
PG/COMM2 on
the CPU unit
RS232C
Setting
Example 6
(page 19)
Cable
Diagram 6
(page 68)
RS422/485
(4wire)
Setting
Example 7
(page 21)
Cable
Diagram 5
(page 64)
JW-21CM
*1
RS422/485
(4wire)
Setting
Example 1
(page 9)
Cable
Diagram 1
(page 50)
RS422/485
(2wire)
Setting
Example 2
(page 11)
Cable
Diagram 2
(page 54)
