MICROWAVE DRAWER PARTS LIST
Note: The parts marked “∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V. "§" MARK: PARTS DELIVERY SECTION
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
3- 1 RTRN-B084MRE0 M Transformer 1 BE
3- 2 RV-MZA288WRE0 M Magnetron 1 BK
3- 3 FDTCTA234WRKZ M Sensor assy 1 AP
3- 4 FFS-BA018/KIT M Monitor switch (V-16G-2C25) with fuse (20A) assembly 1 AF
3- 5 TMAPCB110MRR0 M Schematic 1 AB
3- 6 TCAUAB050MRR0 M Monitor caution label 2 AD
3- 7 LHLD-B034MRF0 M Power supply unit holder 1 AC
3- 8 DPWBFB137MRU0 M Power supply 2 AZ
3- 9 LANGTB122MRP0 M Oven lamp angle 1 AK
3-10 LX-CZ0052WRE0 M Screw/washer 6 AA
3-11 GCABDB012MRP0A M Back plate 1 AW
3-12 PDUC-B141MRP0 M Mag duct 1 AE
3-13 PDUC-B142MRP0 M Sensor duct 1 AK
3-14 PDUC-B161MRP0A M Exhaust duct A 1 AK
3-15 PDUC-B162MRP0 M Exhaust duct B 1 AH
3-16 FCOVPB002MRY0 M Stir cover assy 1 AM
3-17 PCLICB003MRE0 M Canoe clip 3 AB
3-18 MSLIFB001/KIT M Slide rail 3 AV
3-19 LANGTB120MRP0A M Door support angle A 2 AS
3-20 LANGTB187MRP0 M Door support angle B 1 AN
3-21 GCOVHB060MRF0 M Door support cover 2 AH
3-22 PSKR-B018MRP0 M Magnetron air guide 1 AC
3-23 PFILWB005MRP0 M Lamplter 1 AB
3-24 PDUC-B162MRP0 M Partition angle 1 AH
3-25 FC-QZB048MRK0 M HVC assy 1 AP
3-26 LBNDKB007MRP0 M HVC band 1 AB
3-27 XCBS730P08000 M Screw 3 AB
3-28 XOTS740P12000 M Screw 79 AA
3-29 PCOVPB169MRP0A M Top cover 1 AE
3-30 TLAB-B060MRR0 M Menu label 1 AC
3-31 XOTSD40P12RV0 M Screw 4 AA
3-32 XEPS730P10XS0 M Power unit assy screw 2 AC
3-33 DDORFB117MRK0 M Door assy [KB6014LS] 1 BR
3-33 DDORFB120MRK0 M Door assy [KB6014LK] 1 BS
3-33 DDORFB121MRK0 M Door assy [KB6014LW] 1 BS
3-34 PSHEPB184MRE0 M Sealerlm 1 AQ
3-35 FFAN-B008MRK0 M Stirrer fan assy 1 AK
3-36 FANGTB015MRK0 M Latch angle assy R 1 AL
3-37 FANGTB016MRK0 M Latch angle assy L 1 AL
3-38 GCABUB158MRP0 M Side cabinet L 1 AN
3-39 GCABUB157MRP0 M Side cabinet R 1 AN
3-40 PCOVPB143MRP0 M Air cover 1 AE
3-41 LX-NZB006MRE0 M Cap nut 6 AA
3-42 XHTSD40P08RV0 M Screw 4 AA
3-43 TCAUKB001MRR0 M Stirrer cover cleaning label 1 AA
3-44 FMOTEA499WRKZ M Fan motor 1 AY
3-45 LANGTB155MRP0 M Fan motor angle 1 AK
3-46 RTHM-A135WRZZ M Thermal cut-out 2 AD
3-47 FW-VZB312MRE0 M Harness assy 1 AW
3-48 PHOK-A079WRF0 M Latch hook R 1 AH
3-49 PCUSGB066MRP0 M Cushion 1 AB
3-50 PHOK-A080WRF0 M Latch hook L 1 AF
3-51 MLEVPA214WRF0 M Switch lever L 1 AK
3-52 QSW-MA---WRE0 M Monitor switch - must replace by assy. (3-4) 1 AE
3-53 QSW-MA085WRE0 M Switch 4 AE
3-54 QSOCLB010MRE0 M Lamp socket 1 AG
3-55 XEPS730P10XS0 M Screw 4 AC
3-56 FPWBFA380WRKZ M Noiselterunit 1 AM
3-57 RLMPTA093WRZZ M Oven lamp 1 AD
3-58 JHNDPB071MRT0 M Door handle [KB6014LS] 1 AY
3-58 JHNDPB072MRF0 M Door handle [KB6014LK] 1 AY
3-58 JHNDPB073MRF0 M Door handle [KB6014LW] 1 BB
∆
*
