Sharp KB-6524PSY - Parts List - Key Categories; Electrical Parts List; Cabinet Parts List; Control Panel Parts List

33
KB-6524PSY KB-6525PSY
PARTS LIST
REF. NO. PART NO. DESCRIPTION Q'TY CODE
ELECTRICAL PARTS
1-1 FC-QZA637WRKZ HVC ASSY 1 AM
1-2 DPWBFB233MRU0 PSU- Drawer 1 BA
1-3 DPWB-B383DRKZ SW PSU- Drawer 1 BE
1-4 FACCDB021MRE0 POWER SUPPLY CORD 1 AP
1-5 FDTCTA240WRKZ SENSOR ASSY 1 AQ
1-6 FMOTEB062MRK0 FAN MOTOR ASSY 1 AD
1-7 FPWBFA512WRKZ Noise Filter Unit 1 AN
1-8 FFS-BA018/KIT MONITOR FUSE (V-5220Q) WITH FUSE (20A) ASSEMBLY 1 AF
1-9 RLMPTA099WRZZ OVEN LAMP WITH SOCKET 1 AE
1-10 RMOTDA283WRZZ STIRRER MOTOR 1 AM
1-11 QFS-TA013WRE0 Oven thermal cut-out / MG thermal cut-out 2 AF
1-12 RTRN-B101MRE0 TRANSFORMER 1 BD
1-13 RV-MZA365WRZZ MAGNETRON 1 AZ
1-14 FW-VZC422WREZ DRAWER HARNESS 1 BC
1-15 QSW-MA168WRZZ Secondary interlock switch / Door sensing switch 2 AE
1-16 FANGTB020MRK1 AUTO DRAWER GEAR ASSY 1 BL
CABINET PARTS
2-1 GCABUB218WRPZ OUTER CASE CABINET 1 AM
2-2 LANGQA830WRPZ AC CORD MOUNT ANGLE 1 AM
2-3 LANGTB363MRT0 SIDE ANGLE L 24” [KB-6524PSY] 1 AM
2-3 LANGTB364MRT0 SIDE ANGLE R 24” [KB-6524PSY] 1 AM
2-3 LANGTB346MRT0 SIDE ANGLE L 30” [KB-6525PSY] 1 AM
2-3 LANGTB347MRT0 SIDE ANGLE R 30” [KB-6525PSY] 1 AM
2-4 LBSHCA014WRE0 CORD BUSHING 1 AB
2-5 PCOVPA670WRPZ LATCH COVER PLATE 2 AB
CONTROL PANEL PARTS
3-1 DPWBFB234MRU0 CPU- Drawer 1 AZ
3-2 FPNLCB669MRK0 C/P FRAME ASSY 24”[KB-6524PSY] 1 BD
3-2 FPNLCB672MRK0 C/P FRAME ASSY 30” [KB-6525PSY] 1 BD
3-3 FUNTKB513MRE0 KEY UNIT [KB-6524PSY] 1 AQ
3-3 FUNTKB515MRE0 KEY UNIT [KB-6525PSY] 1 AQ
3-4 PCUSGB104MRP0 C/P CUSHION (Required) 1 AB
3-5 XEPS730P10XS0 M3 X 10 SCREW - STEEL P-TIGHT 2 AC
OVEN PARTS
4-1 LSTPPA332WRFZ DOOR STOPPER 2 AK
4-2 FGLSPB005MRY0 OVEN TRAY ASSY 1 BB
4-3 ************* CAVITY ASSEMBLY (not replaceable parts) 1 -
4-4 FPLT-B002MRY0A ANTENNA ASSY 1 AS
4-5 GCABDA205WRWZ BACKPLATE 1 AR
4-6 GCOVHB066MRF0 DOOR SUPPORT COVER 2 AM
4-7 GDAI-A474WRWZ BASE PLATE 1 AX
4-8 LANGTA584WRTZ DOOR SUPPORT ANGLE A 2 AM
4-9 LANGTA585WRTZ DOOR SUPPORT ANGLE B 1 AM
4-10 LBNDKA186WRPZ HVC BAND 1 AB
4-11 LHLD-A352WRFZ PSU HOLDER 1 AH
4-12 LHLD-A387WRFZ SW PSU HOLDER 1 AL
4-13 MSLIFB006MRE0 SLIDE RAIL 3 AY
4-14 NGERRB006MRF0 RACK GEAR 1 AP
4-15 PCLICA044WREZ CANOE CLIP 4 AV
4-16 PCOVPA591WRPZ C/P REAR COVER 1 AM
4-17 PCOVPA597WREZ ANTENNA COVER 1 AB
4-18 PCOVPA590WRPZ OVEN LAMP COVER 1 AM
4-19 PCUSGA807WRPZ INLET CUSHION 2 AB
4-20 PCUSGA808WRPZ HVT CUSHION 1 AC
4-21 PCUSGA809WRPZ EXHAUST DUCT CUSHION 1 AR
4-22 PCUSGA851WRPZ FAN MOTOR SUPPORT CUSHION 1 AC
4-23 PCUSGA810WRPZ AIR FLOW CUSHION 1 AT
4-24 PCUSUA687WRPZ CUSHION 1 AD
4-25 PDMP-B003MRE0 OIL DAMPER 1 AC
4-26 PDUC-B141MRP0A MAG DUCT 1 AE
