KB-6524PSY
KB-6525PSY
SHARP ELECTRONICS CORPORATION
SHARP PLAZA, MAHWAH,
NEW JERSEY 07430-2135
SERVICE MANUAL
MICROWAVE DRAWERS
KB-6524PSY
KB-6525PSY
FOREWORD
This Manual has been prepared to provide Sharp Electronics Corp.
Service Personnel and Service Information for the MICROWAVE
DRAWERS using the Standby Power Circuit.
It is recommended that service personnel carefully study the entire
text of this manual so that they will be qualified to render satisfactory
customer service.
Check the interlock switches and the door seal carefully. Special
attention should be given to avoid electrical shock and microwave
radiation hazard.
WARNING
Never operate the oven until the following points are ensured.
(A) The door is tightly closed.
(B) The door brackets and hinges are not defective.
(C) The door packing is not damaged.
(D) The door is not deformed or warped.
(E) There is not any other visible damage with the oven.
Servicing and repair work must be carried out only by trained service
personnel.
DANGER
Certain initial parts are intentionally not grounded and pre-
sent a risk of electrical shock only during servicing. Service
personnel - Do not contact the following parts while the ap-
pliance is energized:
High Voltage Capacitor, Power Transformer, Magnetron, High
Voltage Rectifier Assembly, High Voltage Harness.
If provided: Vent Hood, Fan assembly, Cooling Fan Motor.
All the parts marked “*” on parts list are used at voltages more
than 250V.
Removal of the outer wrap gives access to voltage above 250V.
All the parts marked “ ” on parts list may cause undue microwave
exposure, by themselves, or when they are damaged, loosened
or removed.
PRODUCT DESCRIPTION
SCHEMATICS
TEST PROCEDURE
MICROWAVE DRAWER
DISSASSEMBLY AND
ADJUSTMENT PROCEDURE
WIRING DIAGRAM
PARTS LIST
∆
