29
KB-6525PS
KB-6525PK
KB-6525PW
PARTS LIST
REF. NO. PART NO. DESCRIPTION Q'TY CODE
ELECTRICAL PARTS
1-1 FC-QZB054MRK0 HVC ASSY 1 AM
1-2 DPWBFB171MRU0 PSU- Drawer 1 BH
1-3 DPWBFC595WRKZ SW PSU- Drawer 1 BC
1-4 FACCDB021MRE0 POWER SUPPLY CORD 1 AP
1-5 FDTCTA240WRKZ SENSOR ASSY 1 AQ
1-6 FMOTEB062MRK0 FAN MOTOR ASSY 1 AD
1-7 FPWBFA437WRKZ Noise Filter Unit 1 AM
1-8 FFS-BA018/KIT MONITOR FUSE (V-5220Q) WITH FUSE (20A) ASSEMBLY 1 AF
1-9 RLMPTA099WRZZ OVEN LAMP WITH SOCKET 1 AE
1-10 RMOTDA283WRZZ STIRRER MOTOR 1 AM
1-11 RTHM-A135WRZZ Oven thermal cut-out / MG thermal cut-out 2 AH
1-12 RTRN-B101MRE0 TRANSFORMER 1
BD
1-13 RV-MZA365WRZZ MAGNETRON 1
AZ
1-14 FW-VZB350MRE0 DRAWER HARNESS 1 AY
1-15 QSW-MA085WRE0 Secondary interlock switch / Door sensing switch 2 AE
1-16 FANGTB020MRK0 AUTO DRAWER GEAR ASSY 1 BL
CABINET PARTS
2-1 GCABUB163MRP0 OUTER CASE CABINET 1 AM
2-2 LANGQB085MRP0 AC CORD MOUNT ANGLE 1 AM
2-3 LANGTB250MRT0 SIDE ANGLE 24” [KB-6524PS/PK/PW] 2 AM
2-3 LANGTB260MRT0 SIDE ANGLE 30” [KB-6525PS/PK/PW] 2 AM
2-4 LBSHC0037WRE0 CORD BUSHING 1 AB
CONTROL PANEL PARTS
3-1 DPWBFB172MRU0 CPU- Drawer 1 BK
3-2 FPNLCB625MRK0 C/P FRAME ASSY 24”[KB-6524PS] 1 BD
3-2 FPNLCB626MRK0 C/P FRAME ASSY 24”[KB-6524PK] 1 BD
3-2 FPNLCB627MRK0 C/P FRAME ASSY 24”[KB-6524PW] 1 BD
3-2 FPNLCB628MRK0 C/P FRAME ASSY 30” [KB-6525PS] 1 BD
3-2 FPNLCB629MRK0 C/P FRAME ASSY 30” [KB-6525PK] 1 BD
3-2 FPNLCB630MRK0 C/P FRAME ASSY 30” [KB-6525PW] 1 BD
3-3 FUNTKB513MRE0 KEY UNIT [KB-6524PS/PK] 1 AQ
3-3 FUNTKB514MRE0 KEY UNIT [KB-6524PW] 1 AQ
3-3 FUNTKB515MRE0 KEY UNIT [KB-6525PS/PK] 1 AQ
3-3 FUNTKB516MRE0 KEY UNIT [KB-6525PW] 1 AQ
3-4 PCUSGB104MRP0 C/P CUSHION (Required) 1 AB
3-5 XEPS730P10XS0 M3 X 10 SCREW - STEEL P-TIGHT 2 AC
OVEN PARTS
4-1 LSTPPB061MRF0 DOOR STOPPER 2 AK
4-2 FGLSPB004MRY0 OVEN TRAY ASSY 1 BH
4-3 ************* CAVITY ASSEMBLY (not replaceable parts) 1 -
4-4 FPLT-B002MRY0A ANTENNA ASSY 1 AS
4-5 GCABDB013MRP0 BACKPLATE 1
AM
4-6 GCOVHB066MRF0 DOOR SUPPORT COVER 2 AM
4-7 GDAI-B098MRP0 BASE PLATE 1 AX
4-8 LANGTB248MRT0 DOOR SUPPORT ANGLE A 2 AM
4-9 LANGTB249MRT0 DOOR SUPPORT ANGLE B 1 AM
4-10 LBNDKB009MRP0 HVC BAND - DISC (MRP0A) 1 AB
4-11 LHLD-B028MRF0 PSU HOLDER 1 AH
4-12 LHLD-B043MRF0 SW PSU HOLDER 1 AL
4-13 MSLIFB006MRE0 SLIDE RAIL 3 AY
4-14 NGERRB006MRF0 RACK GEAR 1 AP
4-15 PCLICB003MRE0 CANOE CLIP 4 AV
4-16 PCOVPB212MRP0 C/P REAR COVER 1 AM
4-17 PCOVPB213MRE0 ANTENNA COVER 1 AB
4-18 PCOVPB214MRP0 OVEN LAMP COVER 1 AM
4-19 PCUSGB087MRP0 INLET CUSHION 2 AB
4-20 PCUSGB103MRP0 HVT CUSHION 1 AC
4-21 PCUSGB106MRP0 EXHAUST DUCT CUSHION 1 AR
4-22 PCUSGB107MRP0 SENSOR DUCT CUSHION 1 AC
4-23 PCUSGB108MRP0 AIR FLOW CUSHION 1 AT
4-24 PCUSUB049MRP0 CUSHION (192.5 X 8 X 8) 2 AD
4-25 PDMP-B003MRE0 OIL DAMPER 1 AC
4-26 PDUC-B141MRP0 MAG DUCT 1 AE
