Terminals
How to Fix the Cables
Pull the cables connected to each terminal. Insert the cables into the stand hole and fix the cables.
Part Names of Main Unit (Continued)
Stand hole
AUDIO (R)
INPUT1
INPUT1
P
R
P
B
Y
AUDIO (L)
AUDIO (L)
S-VIDEO
VIDEO
AUDIO (R)
AUDIO (L)
AUDIO (R)
AUDIO OUT
INPUT2
ANT. (Antenna terminal)
Headphone jack
Stand
POWER INPUT
terminal
Rear View
Round lock for Kensington
Security Standard slot*
*
Using the Kensington Lock
• This LCD TV set has a
Kensington Security Standard
slot for use with a Kensington
MicroSaver Security System.
Refer to the information that
came with the system for
instructions on how to use it to
secure the LCD TV set.
