18
LC-15AV6U
Page No. Item
Initial Value
Function
Response precautions on servicing
(Do not change other items than designated.)
AUDIO ADJUSTMENT
SOUND3 BAND1 MIN TV -0400
EQUALIZER SETTING (WITH TV INPUT)
NOT USED
OTHER
-0400
EQUALIZER SETTING (WITH OTHER INPUT THAN TV)
NOT USED
BAND1 CNT TV +0400
EQUALIZER SETTING (WITH TV INPUT)
NOT USED
OTHER
+0400
EQUALIZER SETTING (WITH OTHER INPUT THAN TV)
NOT USED
BAND1 MAX TV +1200
EQUALIZER SETTING (WITH TV INPUT)
NOT USED
OTHER
+1200
EQUALIZER SETTING (WITH OTHER INPUT THAN TV)
NOT USED
BAND2 MIN TV -0400
EQUALIZER SETTING (WITH TV INPUT)
NOT USED
OTHER
-0400
EQUALIZER SETTING (WITH OTHER INPUT THAN TV)
NOT USED
BAND2 CNT TV -0100
EQUALIZER SETTING (WITH TV INPUT)
NOT USED
OTHER
-0100
EQUALIZER SETTING (WITH OTHER INPUT THAN TV)
NOT USED
BAND2 MAX TV +0200
EQUALIZER SETTING (WITH TV INPUT)
NOT USED
OTHER
+0200
EQUALIZER SETTING (WITH OTHER INPUT THAN TV)
NOT USED
BAND3 MIN TV -0250
EQUALIZER SETTING (WITH TV INPUT)
NOT USED
OTHER
-0250
EQUALIZER SETTING (WITH OTHER INPUT THAN TV)
NOT USED
AUDIO ADJUSTMENT
SOUND4 BAND4 MIN TV +0150
EQUALIZER SETTING (WITH TV INPUT)
NOT USED
OTHER
+0150
EQUALIZER SETTING (WITH OTHER INPUT THAN TV)
NOT USED
BAND4 CNT TV +0450
EQUALIZER SETTING (WITH TV INPUT)
NOT USED
OTHER
+0450
EQUALIZER SETTING (WITH OTHER INPUT THAN TV)
NOT USED
BAND4 MAX TV +0750
EQUALIZER SETTING (WITH TV INPUT)
NOT USED
OTHER
+0750
EQUALIZER SETTING (WITH OTHER INPUT THAN TV)
NOT USED
BAND5 MIN TV -0525
EQUALIZER SETTING (WITH TV INPUT)
NOT USED
OTHER
-0525
EQUALIZER SETTING (WITH OTHER INPUT THAN TV)
NOT USED
BAND5 CNT TV +0275
EQUALIZER SETTING (WITH TV INPUT)
NOT USED
OTHER
+0275
EQUALIZER SETTING (WITH OTHER INPUT THAN TV)
NOT USED
BAND5 MAX TV +1075
EQUALIZER SETTING (WITH TV INPUT)
NOT USED
OTHER
+1075
EQUALIZER SETTING (WITH OTHER INPUT THAN TV)
NOT USED
Page No. Item Initial Value Function
Response precautions on servicing
(Do not change other items than designated.)
AUDIO ADJUSTMENT PROCESS SPECIFICATIONS
VIDEO ADJUSTMENT
DVP1 DVP DATA 0000 F0 ------(----)
—
DVP-RELATED GENERAL-PURPOSE VARIABLE SETTINGS
NOT USED
DVP TEST PATTERN 0 TEST PATTERN SELECT
SEE THE ADJUSTMENT PROCESS MODE TEST PATTERNS.
VCDOFFSET 15
VERTICAL COUNT-DOWN MINIMUM OSCILLATION CYCLE
NOT USED
VCDWINDOW 30
VERTICAL COUNT-DOWN SYNC RANGE
NOT USED
VIDEO ADJUSTMENT
DVP3 N358 TV CONTRAST 128 IMAGE SETTING (TV) NOT USED
N358 AV CONTRAST 128
IMAGE SETTING (COMPOSITE, S VIDEO)
NOT USED
N358 TV BRIGHT 118 BRIGHTNESS SETTING (TV) NOT USED
N358 AV BRIGHT 118
BRIGHTNESS SETTING (COMPOSITE, S VIDEO)
NOT USED
N358 TV COLOR 40 COLOR DENSITY SETTING (TV) NOT USED
N358 AV COLOR 40
COLOR DENSITY SETTING (COMPOSITE, S VIDEO)
NOT USED
N358 TV TINT 140 TINT SETTING (TV) NOT USED
N358 AV TINT 155
TINT SETTING (COMPOSITE, S VIDEO)
NOT USED
N358 TV SHRAP V 100
V PICTURE QUALITY SETTING (TV)
NOT USED
N358 AV SHARP V 100
V PICTURE QUALITY SETTING (COMPOSITE, S VIDEO)
NOT USED
N358 TV SHRAP H1 150
H PICTURE QUALITY SETTING 1 (TV)
NOT USED
N358 AV SHARP H1 150
H PICTURE QUALITY SETTING 1 (COMPOSITE, S VIDEO)
NOT USED
N358 TV SHRAP H2 130
H PICTURE QUALITY SETTING 2 (TV)
NOT USED
N358 AV SHARP H2 150
H PICTURE QUALITY SETTING 2 (COMPOSITE, S VIDEO)
NOT USED
To Next Page
