LC-15AV6U
Page No. Item Initial Value Function
Response precautions on servicing
(Do not change other items than designated.)
VIDEO ADJUSTMENT
DVP12 1125I CONT 133 IMAGE SETTING (TV) NOT USED
1125I BRIGHT 128 BRIGHTNESS SETTING (TV) NOT USED
1125ICOLOR 52 COLOR DENSITY SETTING (TV) NOT USED
1125I TINT 128 TINT SETTING (TV) NOT USED
1125I SHARP V 100
V PICTURE QUALITY SETTING (TV)
NOT USED
1125I SHARP H1 100
H PICTURE QUALITY SETTING 1 (TV)
NOT USED
1125I SHARP H2 100
H PICTURE QUALITY SETTING 2 (TV)
NOT USED
750P CONT 133
IMAGE SETTING (COMPOSITE, S VIDEO)
NOT USED
750P BRIGHT 128
BRIGHTNESS SETTING (COMPOSITE, S VIDEO)
NOT USED
750P COLOR 52
COLOR DENSITY SETTING (COMPOSITE, S VIDEO)
NOT USED
750P TINT 128
TINT SETTING (COMPOSITE, S VIDEO)
NOT USED
750P SHARP V 100
V PICTURE QUALITY SETTING (TV)
NOT USED
750P SHARP H1 100
H PICTURE QUALITY SETTING 1 (TV)
NOT USED
750P SHARP H2 100
H PICTURE QUALITY SETTING 2 (TV)
NOT USED
Page No. Item Initial Value Function
Response precautions on servicing
(Do not change other items than designated.)
ADJUSTMENT PROCESS TUNER ITEM DEFAULT TABLE
TUNER SETTINGS
TUNER1 AFT UP 1.80
AFT VOLTAGE REFERENCE LEVEL (ALL BANDS)
NOT USED
AFT DOWN 1.20
AFT VOLTAGE REFERENCE LEVEL (ALL BANDS)
NOT USED
LSYNC2 150
HSYNC2 162
LSYNC 150
SYNC JUDGMENT THRESHOLD (TV)
NOT USED
HSYNC 162
SYNC JUDGMENT THRESHOLD (TV)
NOT USED
AVSYNC
SYNC JUDGMENT THRESHOLD (EXTERNAL INPUT)
NOT USED
COMPSYNC
SYNC JUDGMENT THRESHOLD (COLOR DIFFERENCE INPUT)
NOT USED
EDS TEST 10
DURATION UNTIL JUDGMENT OF NO EDS TIME DATA (SECONDS)
NOT USED
TUNER SETTINGS
TUNER2 AFT FARTIME 50
CHANNEL PRESET TIME ADJUSTMENT 1
NOT USED
AFT NEARTIME 30
3
CHANNEL PRESET TIME ADJUSTMENT 2
NOT USED
AFT NEARMTIME 10
CHANNEL PRESET TIME ADJUSTMENT 3
NOT USED
AFT 1STEPTIME 10
CHANNEL PRESET TIME ADJUSTMENT 4
NOT USED
AFT CSYNCTIME 50
CHANNEL PRESET TIME ADJUSTMENT 5
NOT USED
SYNC
SYNC ON
WIDTH
10
CHANNEL PRESET TIME ADJUSTMENT 6
NOT USED
1
1
CHANNEL PRESET TIME ADJUSTMENT 7
NOT USED
OTHERS
OTHERS1 DAC DATA 00--- —
DAC-RELATED GENERAL-PURPOSE
NOT USED
VARIABLE SETTINGS
L ERROR WAIT 15s
LAMP ERROR DETECT WAIT TIME
NOT USED
L ERROR H TIME 1.0s LAMP ERROR DETECT TIME NOT USED
TV AUTO GAIN OFF UTO GAIN SETTING FOR TV NOT USED
PWM FREQ 150
DIMMER FREQUENCY SETTING (IN HZ)
NOT USED
PWM DUTY 0
DIMMER DUTY SETTING
NOT USED
OPC THRESHOLD 24 INPUT LEVEL THRESHOLD FROM NOT USED
BRIGHTNESS SENSOR STOP
MODE TO OPERATION MODE
HOTEL POWERFIX OFF
USED FOR FIXED HOTEL MODE POWER ON
NOT USED
COMP SYSTEM AUTO
COMPONENT SIGNAL SELECT IN ADJUSTMENT PROCESS
NOT USED
REMOCON CODE DISPLAYED AT THE BOTTOM
OTHERS2 3D Y/C 0 3D ON/OFF SETTING NOT USED
3DY/C DATA 0 3D YC DATA WRITE AND READ NOT USED
3DY/C DATA WAIT WRITE AND READ EXECUTED NOT USED
KIL OFF FORCED KILLER SETTING FOR NOT USED
SIGNAL WITHOUT COLOR BURST
CLOSED CAPTION 15
CLOSED CAPTION THRESH LEVEL
NOT USED
To Next Page
